Presentation Transcript
2010 aos pss installation
2010 AOS (PSS) Installation

Include SS available sensor Mat into current design. PSS system will be included into STO foam current design minor modifications.

Bolsters not needed

Module repositioned to front and left on the cushion

Math Data Sample

Original Prototype Mat.

AOS Seats. C100/105 2010

slide2

Production intent Mat.

(Top View) sample.

Production intent Mat.

(Bottom View) sample.

AOS Seats. C100/105 2010

slide3

Muck-up of cockpit for SS SI facility.

50 percentile female on muck-up

Patern made by 50 percent female on suppresion mat.

AOS Seats. C100/105 2010
