Presentation Transcript
purpose
Purpose

Hint: Google: “iaqgscmh” and then Bookmark it!

The purpose of this presentation is to introduce Advanced Product Quality Planning to Aerospace Suppliers

Note: The full APQP Introduction presentation is available to the public on the IAQG SCMH website (www.iaqg.org/scmh)

supply chain management handbook scmh
Supply Chain Management Handbook (SCMH)
  • The APQP material is located in Chapter 8.4
  • www.iaqg.org/scmh

APQP Introduction

do cume nt structure
Document structure

Refer to the SCMH for more information

Structure for Aerospace APQP guidance material content:

  • Definition and Benefits
  • Aerospace APQP Model - Pillars
    • Organizational commitment & Management support
    • Cross functional team
    • Effective project planning
  • Aerospace APQP model - Principles
    • Product oriented
    • Structure
      • Phases
      • Elements
      • Deliverables
    • Checklist
    • Production Part Approval Process (PPAP)
  • Implementation and customization
    • Assessments/ratings
    • Reporting
    • Escalation
what is apqp
What is APQP?

APQP is a structured method that deploys the necessary steps to assure that a product satisfies the customer

5-Phase Quality Planning Cycle (PDCA)

Up-front planning (First 3 phases)

Implementation (Last 2 phases)

Success Drivers

Management commitment

Integrated cross-functional teams

Effective project management

Defined deliverables & outputs for each phase

slide6

Background

  • IAQG recognizes that the Aerospace industry is different from other industries and has developed guidance material which is tailored to suit companies working in this industry.
      • Low volumes
      • Long life cycles
      • High levels of regulation
  • The IAQG Guidance material on APQP and PPAP builds on the principles of quality planning as pioneered by Deming from the 1950s and the Automotive industry during the later decades of the 20th Century.
    • GM, Ford & Chrysler published the first combined APQP manual for the automotive industry in June 1994
benefits
Benefits

Products are successfully launched when all functions/disciplines work together to achieve common project objectives. Aerospace APQP encourages cross functional teamwork and early engagement of all functions and suppliers.

  • The APQP approach helps satisfy the customer with:
    • Better product quality by reducing process variation and anticipating risks and defects
    • Shorter lead time by reducing waste and reworks and better manage capacity
    • Lower costs
aerospace apqp model
Aerospace APQP Model

Customer Satisfaction

On-Time, On-Quality, Shorter lead times

Organizational Commitment & Management Support

Cross Functional

Team

Effective Project Planning

APQP PRINCIPLES

organizational commitment management understanding and support

Aerospace APQP main pillars

Organizational commitment & management understanding and support

Full engagement and commitment of top management

from project launch is key.

  • Aerospace APQP brings success when it is embraced by the whole organization
  • Top management demonstrates commitment through:
    • Completing specific APQP training
    • Allocating appropriate resources
    • Leading periodic reviews
    • Standardizing APQP practices
    • Removing Roadblocks
cross functional team

Aerospace APQP main pillars

Cross functional team

Cross functional team approach ensures effective communication across

the business & enables faster product development.

  • Establish a cross functional team including: Engineering, Procurement, Manufacturing, Quality, Sales, Field Service, and others as appropriate
  • The team should consist of representatives from both the supplier and the customer
  • Roles
    • Team leader (project management function) determines the team membership, guides, assigns tasks, escalates issues to management
    • Members complete the required tasks and deliverables
    • Quality (APQP) management arranges for the meetings, ensures on-time and on-quality of deliverables, documents and records
effective project planning

Aerospace APQP main pillars

Effective project planning

Commitment of the project team to Aerospace APQP planning

is key to the project success.

Schedule the tasks defined by the APQP elements and monitor them in order to deliver a product conforming to quality, cost and delivery targets

Aerospace APQP Planning cascades program key targets throughout the value stream; driven from final customer through internal operations and all sub-tiers

This establishes a customer/supplier relationship throughout the value stream

effective planning includes flow down of timing requirements throughout the value stream

AerospaceAPQP main pillars

xx

xx

Q

Q

Representative

Representative

Effective planning includes flow down of timing requirements throughout the value stream

Deliverables

Deliverables

Deliverable

Deliverable

Deliverable

Deliverable

Deliverable

Deliverable

Deliverable

Deliverable

Owner

Owner

Owner

Owner

Owner

Owner

Owner

Owner

Customer

APQP

timeline

Requirements

Progress reports

Supplier

APQP

timeline

aerospace apqp model1
Aerospace APQP model

5 PHASES

ELEMENTS DEFINING ACTIVITIES

KEY DELIVERABLES

slide14

Aerospace APQP model

  • Aerospace APQP enhances the product development process
  • Product Development Process (PDP) specifies activities across functions and suppliers, with associated deliverables and interim approvals at defined points, e.g. gate reviews
  • Aerospace APQP aligns with Product Development Process
    • Ensures that all activities are completed on-time and on-quality
    • Facilitates effective communication
    • Provides timely escalation and resolution of road blocks
slide15

Aerospace APQP model aligns

with PDP

Alignment with Product Development Process (PDP)

  • APQP supports Product Development Process (PDP)
    • Applies to each item of the product breakdown structure
    • Standardizes deliverables for each Aerospace APQP Phase
    • Evaluates maturity based on timing and quality of required deliverables

End of design

Production readiness

Product validation

End of concept

Kick off

Product Development

Process

APQP phases

D

A

E

B

C

APQP milestones

slide16

Aerospace APQP model

Cascade through Product Breakdown Structure (PBS)

3 - Report APQP status at project level

End of design

Production readiness

Product validation

End of concept

Kick off

Product Development

Process

System level

Sub-system level

Components level

1 - Cascade deliverables and align timing for each level

Note: Compressed timeline to support program timing

2 - Bottom up status based on on-time on-quality deliverables

Typical PBS:

system→ sub-system→ component

aerospace apqp principles
Aerospace APQP principles

Aerospace APQP organized into 5 Phases

  • Logical steps to deliver a product from concept to production that can be applied to any product at any level across the supply chain
  • The 5 phases are:
    • Planning
    • Product design and development
    • Process design and development
    • Product and process validation
    • Production
slide19

Aerospace APQP principles

Phase 1 – Planning

  • Identifies and gathers all the inputs applicable to the product
  • Collects the technical and non-technical requirements applicable to the project/product
  • Defines the product and project goals
  • Ensures that the organization has decided what will be made in house and what will be purchased/sub-contract
  • Provides an agreed timing for deliverables attached to each Aerospace APQP elements

Output

      • The product concept is frozen (milestone A) and a pre-design is available
      • Concurrent product design and process design can start
slide20

Aerospace APQP principles

Any design changes after this phase requires change management

Phase 2 - Product design & development

  • Turns product specifications into a robust product definition
  • Provides a verified product design
  • Team commits to product manufacturability

Output

  • Specified prototype testing (e.g. simulation& functional testing) have been completed
  • The product design is verified and validated (milestone B) by the design organization
slide21

Aerospace APQP principles

Phase 3 - Process design & development

  • Creates a robust manufacturing process that meets requirements in terms of quantity and quality of product
  • Defines the means to control the manufacturing process and its outputs

Output

  • The process is defined, established, verified (production readiness review - milestone C) and ready for validation.
slide22

Aerospace APQP principles

Phase 4 - Product & process validation:

  • Launches the significant production run
  • Collects data to demonstrate the manufacturing and assembly processes can produce conforming product at the required rate
  • Management determines process readiness for entry into serial production by reviewing the results of:
    • The product and process design is validated by the organization
    • Production readiness evaluation
    • Corrective actions taken for anyissues identified to date
slide23

Aerospace APQP principles

Phase 4 - Product & process validation:

Output

  • Start of production & FAI (milestone D) verify that the initial product made using all full production means conforms to specified requirements
  • First Article Inspection (FAI) is compiled, approved and available for customer review
  • Production Part Approval Process (PPAP) (milestone E) is compiled, approved and available for customer review
slide24

Aerospace APQP principles

Phase 5 - Production

  • Records Lessons Learned for continuous improvement
  • Ensures robust product realization processes are in place
  • Implements actions to reduce product and process variation in order to achieve quality goals
  • Supports on-going Maintenance Repair and Overhaul (MRO) operations
  • Performs capacity monitoring

Outputs

  • Project goals are achieved, including reliability, quality, and customer satisfaction
  • On-time, on-quality, on-cost production and service
aerospace apqp principles1
Aerospace APQP principles

Elements

Describes key activities accomplished during each Aerospace APQP phase

Assure the health of the project through monitoring on-time,on-quality key deliverables

Encourages a standardized approach

Applicability evaluated for each project

aerospace apqp principles2
Aerospace APQP principles

Element Descriptions coming soon!

Deliverables

Specific outputs defined for each element

Tangible outcomes of the cross functional team activities

Provides the base for assessing the on-quality of the Aerospace APQP elements

Provides standardized content wherever possible (e.g. FMEA, Control plan etc.)

aerospace apqp principles3
Aerospace APQP principles

Checklists coming soon!

Checklist

  • Standardized tool to evaluate on-quality of deliverables and elements
  • Short set of simple, clear questions which will deliver closed answers (Y/N)
    • Provides document references as evidence and records deviations
    • Collects corrective actions to recover deviations
    • Establishes the first level of Red/Yellow/Greenrating
aerospace apqp key milestones
Aerospace APQP key milestones

Production Part Approval Process (PPAP)

PPAP validates that the manufacturing process has the potential to produce product that consistently meets all requirements at the intended production rate.

Success Drivers

Completion of key requirements at the right time during planning process (PPAP is an output of APQP)

Risk mitigation and improved process control

Linkage of DFMEA  PFMEA Control Plan

Process Capability validation

Product verification (FAI)

Process Validation

summary
Summary

Advance Product Quality Planning (APQP) is taking hold in the Aerospace Industry

APQP ensures the delivery of product on-time, on-quality, on cost

PPAP validates the production process

The full APQP Introduction presentation is available in Chapter 8.4 of the SCMH

More information on this topic will be available in November 2013
