Presentation Transcript
connections using fresenius medical care products
Connections using Fresenius Medical Care products

This inservice is not intended to replace the advice or training from your physician. Refer to the Instructions For Use (IFU) for detailed device description, instructions, contraindications, warnings, and precautions.

Fresenius Medical Care, DEL-CLAMP, Stay●Safe, Safe-Lock, DELFLEX and FREEDOM are trademarks of Fresenius Medical Care Holdings Inc. or its affiliated companies. All other trademarks are the property of their respective owners.

fresenius products
Fresenius Products

Baxter is a trademark of Baxter International Inc. or its affiliates.

Instructions on how to use Baxter products were reproduced from the manufacturer’s literature and were current at the time of print. Instructions are included for the patient's convenience but Fresenius Medical Care North America does not specifically endorse the use of these products or assume any liability related to their use. Should there be any differences between the instructions listed in this manual and the instructions for use provided with the medical devices referenced, the instructions provided with the medical device should be taken as accurate."

connections using fresenius medical care products4
Connections using Fresenius Medical Care products

Note: for clarity the model is shown not wearing personal protective equipment (PPE). Follow your facility’s policies and procedures for use of personal protective equipment.

It is vital to maintain sterility of the connectors during connection procedures.

safe lock patient to baxter supplies
Safe-Lock patient to Baxter supplies

A Universal Connector will allow the patient with a Fresenius Safe-Lock PD system to use Baxter supplies while in the hospital.

Universal Connector

Fresenius Safe-LockPD system

Baxter Supplies

safe lock systems
Safe-Lock Systems

Please note Safe-Lock systems include:

  • Delflex Premier Plus exchange set
  • Freedom Y-set with snap disconnect
  • All Freedom cycler tubing sets
  • Newton cycler set with safe lock connectors
  • 8 Lead Safe-Lock Manifold set
safe lock patient to baxter supplies7
Safe-Lock® patient to Baxter supplies

Type II adapter on catheter

Universal Connector

P/N # 050-30026

4 inch convertible extension set

Extension set with roller clamp

Pre-filled

Universal Connector

P/N # 050-30031

Premier transfer set

A Universal Connector (P/N #050-30026) or Pre-filled Universal Connector (P/N #050-30031) will connect to any of the patient catheter or catheter extension sets shown above.

safe lock patient to baxter supplies8
Safe-Lock patient to Baxter supplies

Gather supplies

Pre-filled Universal Connector

Baxter tubing solution set and related supplies for transfer set connection and exchange procedure.

Baxter extension set

safe lock patient to baxter supplies9
Safe-Lock patient to Baxter supplies

1

2

  • Hold Premier transfer set
  • Untwist tubing segment secured with DEL-CLAMP clamp.
  • Remove tubing segment from patient’s catheter

3

safe lock patient to baxter supplies10
Safe-Lock patient to Baxter supplies

4

4. Remove sealing cap

from large end of

Universal Connector.

5. Attach Universal

Connector to patient’s catheter

6. Remove the sterility protector

from the small end of the

Universal Connector.

5

6

safe lock patient to baxter supplies11
Safe-Lock patient to Baxter supplies

7

7. Remove the sterility protector

from the Baxter extension set.

8. Attach the Baxter extension

set to the Universal

Connector. Proceed with

exchange.

8

safe lock patient to baxter supplies12
Safe-Lock patient to Baxter supplies

Typical connection and use of the Universal Connector

discharge instructions for all connections
DISCHARGE INSTRUCTIONSFOR ALL CONNECTIONS
  • The patient should return to his/her home or clinic with the additional extension in place. This practice will allow the patient to return home and resume dialysis without interruption.
  • Instruct the patient to remove any adaptors added to their extension set at the beginning of the next exchange or as directed by the PD clinic nurse.
slide14

Choose the type of catheter or transfer set and the type of system utilized. Look down the column and across the row to the adapter needed. Click on the icon in the box to take you to the procedure

slide15

Please contact your Fresenius Clinical Sales Representative at

1-800-662-1237 if you have questions regarding the use of a Fresenius PD system or adapter.

slide16

CD Available through Customer Service

800-323-5188 (P/N # 100676-01)
