1.Develop a free-body diagram by replacing the various machine elements mounted on the shaft by their statically equivalent load or torque components. To illustrate this, Fig. 11.1(a) shows two gears exerting forces on a shaft, and Fig. 11.1(b) then shows a free-body diagram of the gears acting on the shaft.2.Draw a bending moment diagram in the x-y and x-z planes as shown in Fig. 11.1(c). The resultant internal moment at any section along the shaft may be expressed as3.Develop a torque 140
