fast hydraulic erosion simulation and visualization on gpu

Fast Hydraulic Erosion Simulation and Visualization on GPU

Xing Mei1Philippe Decaudin2Bao-Gang Hu1

1. CASIA (China) 2. INRIA (France)

Pacific Graphics’07

outline
Outline
  • Introduction
    • Hydraulic Erosion
    • Existing Methods
  • Hydraulic Erosion on GPU
    • Method Overview
    • Simulation Steps
    • Multi-pass Implementation on GPU
  • Results
  • Conclusion & Future Work
introduction hydraulic erosion
Introduction- Hydraulic Erosion
  • Process

Water flow takes away (dissolves) the soil

and relocates (deposits) it somewhere else

  • Effect

Changes terrain appearance

Creates interesting geo-morphological structures

Eroded landscape on Maui Island

Gullies

introduction erosion simulation why
Introduction- Erosion Simulation (Why?)
  • Enhance realism
  • A useful complement to fluid simulation

Topographical changes affect the water flow

[Chiba’98]

[Beneš’06]

introduction existing methods
Introduction- Existing Methods
  • Procedural [Kelly’88, Prusinkiewicz’93]
    • Ad hoc rules with fractal terrain generation
    • Fast and efficient; No water flow involved

Limited control on the erosion results

  • Physically Based Simulation

[Musgrave’89, Chiba’98, Neidhold’05…]

    • Simulation on already-existing terrains
    • Controllable Erosion Process, but computationally expensive

4 fps on 256x256 grids [Neidhold’05]

5 fps on 300x300 grids [Beneš’07]

Limited for interactive applications

erosion on gpu motivation
Erosion on GPU- Motivation
  • A novel hydraulic erosion simulation method
    • Effective

produces the important features in the erosion process Gullies, water catchments, deposited sediment…

    • Efficient

Well mapped to GPU

Interactive frame rates for large size terrains

erosion on gpu method overview
Erosion on GPU- Method Overview
  • 5 steps in one cycle of the simulation

(1) Water Increment

(2) Water Movement (flow simulation)

water

(3) Erosion or Deposition

(4) Sediment Transportation

Rainfall & River Source

(5) Evaporation

Water Movement

Erosion

Evaporation

Terrain

Sediment Transportation

Catchment

Deposition

Deposited

Sediment

erosion on gpu data structure
Erosion on GPU- Data Structure
  • Layers of 2D arrays
  • Each step should update the cell data in parallel

No scattering operations on the data array involved

cell

Suspended Sediment

Outflow flux

Velocity

Water Height -

Terrain Height -

Arrays

cell

erosion on gpu 1 water increment
Erosion on GPU(1)Water Increment
  • Two kinds of sources

River sources – fixed location, radius, intensity

Raindrops – random location, radius, intensity

Water increment

erosion on gpu 2 water movement flow simulation
Erosion on GPU(2) Water Movement (Flow Simulation)
  • Possible Models?
    • GPU friendly

Grid-based methods > Lagrangian methods

    • Efficient

Shallow water model > 3D Navier-Stokes Equation

    • Suitable for Erosion-Deposition

Velocity field is necessary

  • Previous models on shallow water framework
    • Simplified Newtonian physics model [Neidhold’05]

hard to parallelize

    • Kass&Miller’s implicit method [Beneš’07]

many iterations over the grid, not efficient for large size terrain

  • Our choice

The Virtual Pipe model [O’Brien’95]

erosion on gpu 2 water movement flow simulation11
Erosion on GPU(2) Water Movement (Flow Simulation)
  • Virtual Pipe Model
    • Water is exchanged between cells through virtual pipes
    • How much water exchanged through each pipe?

Flux – accelerated by the hydrostatic pressure difference

Two-Step Process

Update Flux

Update Water Height

A simple explicit method

P0

P0

P1

P2

Cell

erosion on gpu 2 water movement flow simulation12
Erosion on GPU(2) Water Movement (Flow Simulation)
  • Two “problems” about the original model

Staggered grid

water height (d) – cell center

flux (F) – cell border

2. Non-negative water update

A scaling back process

scattering operations are involved

Both are not GPU-friendly

Cell

erosion on gpu 2 water movement flow simulation13
Erosion on GPU(2) Water Movement (Flow Simulation)

Outflow flux

  • Adaptation to the original model
    • the outflow flux for each cell
    • Flux (F) and outflow flux (f)
    • Water height update (d)

- send away the outflow flux

- collect inflow flux from neighbours

Inflow flux

Cell(x,y)

erosion on gpu 2 water movement flow simulation14
Erosion on GPU(2) Water Movement (Flow Simulation)

Outflow flux

  • Non-negative water update

Inflow flux

Cell

omitted, strengthened condition

a scaling factor K limiting the outflow flux

erosion on gpu 2 water movement flow simulation15
Erosion on GPU(2) Water Movement (Flow Simulation)
  • 3-step process
    • Update outflow flux
    • Update water height
    • Update (horizontal) velocity field

From Flux (f) to Velocity (V)

  • No-Slip Boundaries

set outflow flux to 0 for boundary cells

  • Limitation for time step

Cell

Boundary

cell

erosion on gpu 3 erosion deposition
Erosion on GPU(3) Erosion & Deposition
  • Sediment transport capacity

Current suspended sediment

  • How to compute for each cell ?

We adapt a classic model from soil science [Julien’85]

Deposition

Erosion

erosion on gpu 4 sediment transportation
Erosion on GPU(4) Sediment Transportation
  • Suspended sediment (S) is advected by the velocity field
  • Many GPU-friendly schemes to solve the equation
    • Stable semi-Lagrangian method [Stam’99]
    • Upwind differencing scheme
    • More mass-conservative methods such as BFECC [Kim’05, Selle’07]

(advection dominated, no diffusion considered)

erosion on gpu multi pass implementation on gpu
Erosion on GPU- Multi-pass Implementation on GPU
  • General computation framework on GPU [Harris’03, Owens’07]

To update a 2D array in parallel:

  • Multi-pass process

pack datainto textures

draw a screen-aligned quad

update texture in pixel shader

Simulation

(1) Water Increment

Outflow

(2) Flow Simulation

Water Height

Initialization

Visualization

Velocity

(3)Erosion-Deposition

VS: Vertex Texture

PS: Phong Lighting

(4) Sediment transport

(5) Evaporation

results
Results
  • Platform: Pentium IV 2.4GHz + 2Gb RAM + Nvidia 8800 GTX

512x512 grids for video demos

water

suspended sediment in the flow

deposited sediment

Video

“PG scene” in the rain

results20
Results
  • Deposited sediment in a basin

The bottom of the basin is flattened by the deposited sediment

Video

results21
Results
  • River flow in a drained channel

Part of the original river bank get eroded

Video

results22
Results
  • Mountain scene eroded by rainfall

Video

results23
Results
  • Final example:

the combination of the rainfall and the river source

Video

results24
Results
  • Performance results for the final example at different grid size

1 cycle = 1 simulation + 1 visualization

Interactive frame rates for terrain up to 1024x1024!

results25
Results
  • ST, VT, CT at different grid size

ST : Simulation Time

VT : Visualization Time

CT : Cycle Time = ST+VT

1. ST, VT, CT scales

well with grid size

~ linear with # of cells

2. VT takes more time

for large size terrain

3. Further Improvements

conclusion future work
Conclusion & Future Work
  • A novel simulation method for hydraulic erosion
    • Effective – proper model selection and adaptation for each step

Produces dynamic erosion process and realistic results

    • Efficient - well designed for complete GPU implementation

Interactive frame rates for large size terrain

  • Future work
    • Further improvements on models:

Fluid solver - Limitation for time step

Erosion Model - Little erosion on flat terrain

    • Extension to non-height-field scene

(general 3D objects, structures with caves)

    • More erosion process – thermal weathering, wind erosion…
slide27
Thanks!

More info on

http://evasion.imag.fr/Publications/2007/MDH07/
