easygem 2 4 technology summary for secs communication

EasyGem™2.4Technology Summary for SECS Communication

Easy, Fast and Reliable Equipment FA Control Solution

introduction
Introduction

HOST

  • EasyGem is based on Easycluster CTC. It supports control and status information between Host and Equipment
  • EasyGem supports SECS II Protocol, GEM Standards and HSMS Communication
  • EasyGem has proven reliability and flexibility through multiple OEM installs in different FAB environments.

FAB Network

GEM

CTC

PMC

PMC

I/F

PMC

PMC

Machine

TMC

Intra-tool Network

Easycluster

advantages
Advantages
  • Easy to build

: Defined using Configuration File or GUI

  • Easy to extend

: GEM Definition options to change functionality. ( ex : 200mm <-> 300mm, Increased Modules )

  • Easy to debug

: Comprehensive history and communication data logfiles

( Host<->Gem, Gem<->Equip, Error, Debug Message file )

  • High Reliability and Flexibility

: Multiple OEM installs in varied End User facilities

features
Features
  • 200mm/300mm FA Scenario Support

: 200mm -> Gem Scenario, 300mm -> Gem and Control/Process Job Scenario

  • Full Gem Scenario Support

: Up to Spooling, Trace, Variable Limit Set/Monitor, Material Movement

  • Max 64 Process Module Support

: PPID, CEID

  • User ID Definition : Maximum 3000

: ID => SVID,CEID,ECID,RCMD,ALID

  • TEPAS Support

: TEPAS( Samsung : Total Equipment Prediction Analysis System )

1 TraceID has maximum 200 SVIDs, minimum 1sec sampling time and maximum 21 hundred million counts. At the same time 10 TraceID is supported

  • Variable and Flexible Option

: User can configure Option as Fab Request and Equipment System,

user configuration files
User Configuration Files
  • ALID.cfg

: Alarm ID Registry File( link with Equipment Alarm Number )

  • CEID.cfg

: Collection Event ID Registry File( includes Kornic Provision Event )

  • ECID.cfg

: Equipment Constant ID Registry File( link with Equipment Parameter IO )

  • SVID.cfg

: Status Variable ID Registry File( link with Equipment Status IO )

  • RCMD.cfg

: Remote Command Registry File( includes Kornic Default Command )

  • Recipe.cfg

: Process Program ID Registry File( link with Process Module Recipe Item )

  • System.cfg

: EasyGem Option Configuration File

debugging files
Debugging Files
  • SECS Message Log File

: All messages between Host and Equip. are saved. File is created at 1 hour intervals

  • Report/Event ID Log File

: Can show ReportID/Event from host in GUI.

The information remains persistent, no need to reload

  • Equipment Execution Log File

: Command and Event messages between Gem and Equipment

  • Gem Analysis Error Log File

: If message from host has an error( syntax, format, reject situation ),

the analysis error message is saved.

  • Communication History and Error Log File

: Ethernet Port Open Fail and Host Communication Start/End Time

architecture
Architecture

Configuration

System

CEID

RCMD

SVID

PP Body

ALID

Log File

Log File

SECS2

Message

Comm

Debug

Easycluster

Analysis

Debug

Event

Log

PMC / TMC

Spooling

Data

Easycluster

IO Manager

Application1

Alarm Manager

Application2

EasyGem

Event

.

.

.

.

Communication

Task

Format

CTC

Execution

Analysis

Application1

Data

gathering

Unformat

Application2

GUI

GUI

Alarm Manager

IO Manager

Host

SECS2 Format

UnFormat Task

H/W

system requirements
System Requirements
  • Control System
    • Pentium III or Higher, min. 128 MB RAM
    • Monitor : SVGA (1,024 768)
    • LAN Card
  • OS

: Window NT 4.0 Workstation, Windows 2000, Windows XP

  • FA Pre-test Tool

: SECSim Pro™ (GW Associates, Ver2.0)

generic equipment model gem
Generic Equipment Model(GEM)
  • State Models

: Process, Communication, Alarm, Control, Material Movement, Spooling

  • Establish Communications

: Communication State Display in GUI, Timer Constants, Comm. Enable/Disable

  • Data Collection

: Collection Event, Host Defined Event Reports, Event Enable/Disable, Status Data Collection, Trace Data Collection, Host Limit monitoring, Variable Name list Req.

  • Alarm Management

: Set Alarm Enable/Disable/Auto/Semi, Alarm Reporting, Alarm Data Request

  • Remote Control

: Control Event, Control Status Variable, State Display, Appropriately Accept/Deny

  • Equipment Constants

: Non-Volatile Storage, Host Data Req. and New Data Set, EC Name List Request

generic equipment model gem10
Generic Equipment Model(GEM)
  • Process Program Management

: Host Upload/Download/Delete/Directory request, Process Program Verification

  • Material Movement

: Port/Wafer Status, Completion Time

  • Equipment Terminal Services

: Single/Multi Block, Message Display in GUI

  • Error Messages

: Unrecognized Device ID/Stream/Function, illegal Data, Transaction Timeout

  • Clock

: Equipment Clock Request/Set

  • Spooling

: Non-Volatile Storage, Spool Status and Display

supported semi standards
Supported SEMI Standards
  • SEMI E5-0301SEMI Equipment Communications Standard 2 Message Content (SECS-II)
  • SEMI E30-1000Generic Model for Communications and Control of Manufacturing Equipment (GEM)
  • SEMI E37-0298High-Speed SECS Message Services (HSMS) Generic Services
  • SEMI E37.1-96EHigh-Speed SECS Message Services Single – Session Mode (HSMS-SS)
  • SEMI E39-0600Object Services Standard : Concepts, Behavior, and Services (OSS)
  • SEMI E40-0301Standard for Processing Management (PJM)
  • SEMI E42-0299ERecipe Management Standard: Concepts, Behavior, and Service(RMS)
  • SEMI E84-0301Specification for Enhanced Carrier Handoff Parallel I/O Interface(PIO)
  • SEMI E87-0301Provisional Specification for Carrier Management (CMS)
  • SEMI E90-0301Specification for Substrate Tracking(STS)
  • SEMI E94-1000Provisional Specification for Control Job Management(CJM)
  • SEMI E99-1000EThe Carrier ID Reader/Writer Functional Standard: Specification of Concepts, Behavior, and Services
semi standard compliance
Semi Standard Compliance

GEM COMPLIANCE STATEMENT

Fundamental GEM Requirements

GEM Section

Implemented

GEM-Compliant

State Models

3.0, 3.1, 3.3

Yes No

Yes

(See NOTE 1)

No

Equipment Processing States

3.4

Yes No

Host-Initiated S1=F13/F14 Scenario

4.1.5.1

Yes No

Event Notification

4.2.1.1

Yes No

On-Line Identification

4.2.6

Yes No

Error Message

4.9

Yes No

Documentation

8.4

Yes No

Control ( Operation Initiated)

4.12(except 4.12.5.2)

Yes No

Additional Capabilities

Implemented

GEM-Compliant

(See NOTE 2)

Establish Communications

4.1, 3.2

Yes No

Yes No

Dynamic Event Report Configuration

4.2.1.2

Yes No

Yes No

Variable Data Collection

4.2.2

Yes No

Yes No

Trace Data Collection

4.2.3

Yes No

Yes No

Status Data Collection

4.2.5

Yes No

Yes No

Alarm Management

4.3

Yes No

Yes No

Remote Control

4.4

Yes No

Yes No

Equipment Constants

4.5

Yes No

Yes No

Process Program Management

4.6

Yes No

Yes No

Material Movement

4.7

Yes No

Yes No

Equipment Terminal Services

4.8

Yes No

Yes No

Clock

4.10

Yes No

Yes No

Limits Monitoring

4.2.4

Yes No

Yes No

Spooling

4.11

Yes No

Yes No

Control (Host-Initiated)

4.12.5.1

Yes No

Yes No

( E5-0301/SEMI E30-1000/SEMI E39-0600 )

semi standard compliance14
Semi Standard Compliance

PM COMPLIANCE STATEMENT

Fundamental PM Requirements

PM Section

Implemented

PM Compliant

Single Process Job Execution

8.2

 Yes No

Yes No

Process Job Milestones

8.2.1 (except 8.2.1.2, 3)

Yes No

Yes No

Process Job Failure Indication

8.2.1.7

Yes No

Yes No

Abort Command

8.2.3.2

Yes No

Yes No

Process Job Object Implementation

8.3, 9

Yes No

Yes No

Reject Invalid/Incomplete Parameter

8.2.1.2.1

Yes No

Yes No

Reject Unsupported Capabilities

11.2

Yes No

Yes No

Services Implementation (not per Additional)

10

Yes No

Yes  No

Resource Pre/Post-conditioning

Yes No

Yes No

Stop, Pause and Resume Commands

8.2.3.3, 4, 5

Yes No

Yes No

Manual Process Start

8.2.3.9

Yes No

Yes No

Process Job Queuing

8.3

Yes No

Yes No

Process Tuning

7.5, 10.4.9

Yes No

Yes No

Processing of Material Groups

7.6

Yes No

Yes No

Multiple Concurrent Process Jobs

7.7

Yes  No

Yes No

Multiple Consecutive Process Jobs

7.8

Yes No

Yes No

Process Job With No Material

7.9

Yes  No

Yes No

Event Notification

8.2.2

Yes No

Yes No

Enhanced Job Creation

10.4.2

Yes No

Yes No

Multiple Job Creation

10.4.3

Yes No

Yes No

Duplicate Job Creation

10.4.4

Yes No

Yes No

( E40-0301 )

semi standard compliance15
Semi Standard Compliance

CMS COMPLIANCE STATEMENT

Fundamental CMS Requirements

CMS Section

Implemented

CMS Compliant

Load Port Number

9.1

■Yes No

■Yes No

Carrier Slot Number

9.2

■Yes No

■Yes No

Load Port Transfer State Model

9.3 – 9.4.3

■Yes No

■Yes No

Carrier Object Implementation

10

■Yes No

■Yes No

Load Port Reservation State Model (internal buffer equipment)

12

Yes ■No

Yes ■No

Load Port/Carrier Association State Model

13

■Yes No

■Yes No

Carrier ID Verification Support

14.2

■Yes No

■Yes No

Slot Map Verification Support

14.3

■Yes No

■Yes No

Services Implementation

16

■Yes No

Yes ■No

Additional Events Implementation

18

■Yes No

Yes ■No

Variable Data Definitions

19

■Yes No

Yes ■No

Alarms Implementation

20

■Yes No

Yes ■No

Additional CMS Capabilities

CMS Section

Implemented

CMS Compliant

Load Port Reservation State Model (fixed buffer equipment)

12

■Yes No

■Yes No

Reservation Visible Signal

12.2

■Yes No

■Yes No

( E87-0301)

semi standard compliance16
Semi Standard Compliance

STS COMPLIANCE STATEMENT

Fundamental STS Requirements

STS Section

Implemented

STS Compliant

Substrate Tracking

8 (except 8.4)

■Yes No

■Yes No

Substrate Object and State Model

9

■Yes No

■Yes No

Substrate Location Object and State Model

10

■Yes No

■Yes No

Service Message Implementation

11

■Yes No

■Yes No

Variable Data

12

■Yes No

■Yes No

Events

8.4

■Yes No

■Yes No

Fundamental STS Requirements

STS Section

Implemented

STS Compliant

none

( E90-0301)

semi standard compliance17
Semi Standard Compliance

CJM COMPLIANCE STATEMENT

Fundamental CJM Requirements

CJM Section

Implemented

CJM Compliant

Control Job Object

8

■Yes No

■Yes No

Control Job State Model

9

■Yes No

■Yes No

Control Job Queue Model

10

■Yes No

■Yes No

Carrier Properties

11

■Yes No

■Yes No

Service Message Implementation

12

■Yes No

■Yes No

Variable Data

13

■Yes No

Yes ■No

Events

7.3.2

■Yes No

■Yes No

Additional Requirements

14

■Yes No

Yes ■No

( E94-1000 )

related screens
Related Screens

( Gem Communication)

related screens19
Related Screens

( Gem Configuration)

related screens20
Related Screens

( Host Communication)

related screens21
Related Screens

( Job Manager)
