  1. Flip Flop 主講人：林佳慶 http://www.cis.nctu.edu.tw/~jacklin/ jacklin@cis.nctu.edu.tw

  2. Outline • Propagation Delay Review • 循序電路 • SR Latch • D Flip-Flop • JK Flip-Flop • Example

  3. Propagation Delay Gate Delay

  4. Timing Diagram equivalent to “Switch” equivalent to “Inverter”

  5. Conclusion of Time Delay • The overall gate delay will determine the speed of the circuit. • The gate delay can not be displayed in the logic simulator. • In the Xilinx, the gate delay can be observed in the simulator after implementation, next to the function block of implementation.

  6. CLK 循序電路（1/2） • 組合電路(Combinational circuit)並不會儲存之前發生過的狀態，循序電路(Sequential circuit)會根據目前的狀態來決定下一次的輸出狀態

  7. Reset Next Next Next Next Next 0 1 2 3 4 5 Reset Reset Reset Reset Next/Reset 循序電路（2/2） • Example：計數器

  8. SR Latch（1/4） • 由二個NOR構成的正緣觸發SR正反器 • S=1,Q設為1；R=1,Q設為0

  9. SR Latch（2/4） • 正緣觸發的時序圖

  10. SR Latch（3/4） • 下圖的SR正反器由二個NAND構成，具有回饋電路，不同前者的是，以負緣觸發

  11. SR Latch（4/4） • 具有控制訊號的SR正反器

  12. D Latch（1/2）

  13. D Latch（2/2） • 負緣觸發D正反器 的時序圖

  14. JK Filp-Flop • Master-Slave JK Flip-Flop(pulse-triggered flip-flop)

  15. Flip-Flop Characteristic Tables 相當於將JK Flip-Flop的輸入接在一起

  16. Q1Q0Q1+Q0+D1D0 0 0 0 1 0 1 0 1 1 0 1 0 1 0 1 1 1 1 1 1 0 0 0 0 D1 Q0 Q1 D0 DFF DFF CLK 範例：以D正反器建立二位元計數器 • 取得D正反器的Function Table • 畫出2-bit counter with D Filp-Flop的Next-State Table 00 01 10 11

  17. 範例：以D正反器建立二位元計數器 • 以觀察歸納或K-map導出D1／D0的Boolean Equation D0=~(CLK) D1=Q0 XOR Q1
