Dynamical Construction of a Core-Based Group-Shared Multicast Tree in Mobile Ad Hoc Networks. B.H. Liu, M.J. Tsai, and W.C. Ko Department of Computer Science National Tsing Hua University Hsing Chu, Taiwan, ROC Speaker : Bing-Hong Liu. Agenda. Introduction The Heuristic Simulation
E N D
Dynamical Construction of a Core-Based Group-Shared Multicast Tree in Mobile Ad Hoc Networks B.H. Liu, M.J. Tsai, and W.C. Ko Department of Computer Science National Tsing Hua University Hsing Chu, Taiwan, ROC Speaker : Bing-Hong Liu
Agenda • Introduction • The Heuristic • Simulation • Conclusion
core core Introduction(1/2) • Core-based group-shared tree • Shared by group members and rooted at core node • Core distributes the packets to and from all group members Local broadcast operation Traditional Find a minimum non-leaf multicast tree
Introduction(2/2) • Minimum non-leaf multicast tree Problem • No polynomial time approximation scheme unless P=NP • A distributed heuristic is needed
A Reduction A reduction on one node reforms tree structure between this node and its all neighbors
Which node does the reduction? It leads us to define the profit of each tree node
Profit Value • Node’s profit can be simply defined • If the number of its neighbors is smaller than or equal to 2 • Set to 0 • Otherwise • Set to the number of its neighbors - 2 • The node with larger profit value (> 0) in its neighborhood can do the reduction
Distributed Reduction Method(1/2) A cycle is constituted This problem is solved by the election model
Distributed Reduction Method(2/2) • Election model • Each tree node elects a candidate with largest profit in its neighborhood • A node can do the reduction when it is the candidate of each of itself and all neighbors
Simulation(1/2) • Environment • Network topology is generated by geometrically distributed network model [1] • Group members are randomly selected from all nodes in the network • Cost • The number of non-leaves in the multicast tree • Comparison • Graph-center tree (GCT), multicast-center tree (MCT), and random-member tree (RMT) • RMT applied with our reduction method (RRMT)
Simulation(2/2) X axis: The number of group members Y axis: The average ratio of the cost of other multicast tree to that of RRMT
Conclusion • A heuristic is to reduce the cost of the multicast tree when the local broadcast operation is used • RMT applied with our heuristic gets better performance than original one
Reference • [1] S.K.S. Gupta and P.K. Srimani, “Adaptive Core Selection and Migration Method for Multicast Routing in Mobile Ad Hoc Networks,” IEEE Transactions on Parallel and Distributed Systems, vol. 14, no. 1, 2003, pp.27–38.
