end user computing is no longer just about the device or technology

End user computing is no longer just about the deviceor technology…

  • It’s about the overall experience:
  • Enabling end users to do more without making IT sacrifices
  • Making data access pervasive anytime, anywhere, on any device
  • Developing a deeper understanding of end users, roles and needs

Confidential

it s about maximizing end user productivity and it control

It’s aboutmaximizingend user productivityandIT control:

  • Making users more productive than ever by mapping to technology interaction, data access and device usage
  • Empowering IT professionals with tools to more efficiently deploy, manage, secure and support their changing workforce

Confidential

dell end user computing

Dell End User Computing

is about:

  • Customer inspired design across a complete portfolio of systems, services and solutions
  • Seamless experience across multiple devices, operating systems and applications
  • Tailored solutions optimized for management, security and productivity

Confidential

commercial brands evolving with end user needs enabling them to do more than ever before
Commercial brands evolving with end user needs, enabling them to do more than ever before

Latitude & OptiPlex

Vostro

XPS

Dell Precision

Empower your

passions

Big Ideas for

Small Business

Professional Class

Laptops & Desktops

The Ultimate in Workstation Performance

Driving enterprise efficiency and TCO.

Elevating design. Redefining durable, powerful, secure, manageable.

Worry-free business solutions and services designed for small business.

Artful blend of high performance and purposeful design for consumers.

Confidential

6

slide7
Dell Latitude™ Laptops

Enabling end users to do more than ever before without sacrificing IT management and security.

Inspired Design

Business-ClassControl

Go-Anywhere Productivity

IntegratedSolutions

Confidential

slide8
Dell Latitude™ Laptops

Inspired Design

Business-ClassControl

Go-AnywhereProductivity

IntegratedSolutions

Long-lasting durability, uncompromised reliability and flexible integration into your organization with environmentally conscious principles to respect our planet.

Performance, versatility and collaboration features that that help end users be more productive than ever – no matter where they’re working, when they’re working, or who they’re collaborating with.

Efficient manageability, confident security, long-term stability and proven service and support for uncompromised IT control over your laptops.

Tailored solutions for cost effective security, management, virtualization and productivity in next-generation end user computing environments.

Confidential

slide9
Inspired Design

Long-lasting Durability

Dell E-Family laptops are designed and tested to help ensure long term reliability and durability in hard working environments.

Long-lasting durability, uncompromised reliability and flexible integration into your organization with environmentally conscious principles to respect our planet.

Right Fit

Dell Latitude E-Family laptops seamlessly integrate into the office and field environments and provide flexibility to support users’ needs.

Environmentally-Conscious Principles

Dell Latitude E-Family laptops are engineered to respect our planet and offer services that minimize energy consumption and help recycle.

Confidential

slide10
Inspired Design

Long-lasting Durability

Dell Latitude E-Family laptops are designed and tested to help ensure long term reliability and durability in hard working environments.

  • Get ultimate protection from extreme temperatures, vibration, dust and high altitudes with MIL-STD 810G testing.
  • Handle work’s tough demands with the Tri-Metal™ casing, brushed aluminum finish, reinforced magnesium alloy wrapped corners and frame, strong steel hinges, rugged closing latch and durable powder-coated underside.
  • Worry less about a mess with the spill-resistant keyboard and LCD protective seal that helps to form a barrier around your LCD panel when closed.
  • Protect data from drops and vibration with StrikeZone™ shock absorber, Fast Response Free-Fall Sensor, and rubber hard drive isolation.

Confidential

slide11
Inspired Design

Right Fit

Dell Latitude E-Family laptops seamlessly integrate into the office and field environments and provide flexibility to support users’ needs.

  • Get the protection you need no matter how tough the job with business rugged to fully rugged solutions.
  • Choose from a range of specialty models designed for integration into vertical solutions, such as education, healthcare, manufacturing, military, and more.
  • Find the right balance of sophisticated design and quality construction for ultimate durability.
  • Transition seamlessly to full desktop productivity with E-port docking solutions featuring true hot docking and undocking capabilities.

Confidential

slide12
Inspired Design
  • Compute more, consume less, and save money with BVR/PFC free configurations on all Latitude E-family laptops, efficient power supplies, and recyclable packaging.
  • ENERGY STAR 5.2, EPEAT Gold3, CECP, TCO 3.0, WEEE, Japan Energy Law, Japan Green PC, EU RoHS, China RoHS
  • Protect your organization’s sensitive data and recycle responsibly with Dell Asset Recovery and Recycling Service.
  • OptiPlex 9010 small form factor is brominated flame retardant free (BFR-free) and polyvinyl chloride free (PVC-free); meeting the definition of BFR-/PVC-free as set forth in the iNEMI Position Statement on the ‘Definition of Low-Halogen Electronics (BFR-/CFR-/PVC-free)’. Plastic parts contain less than 1,000 ppm (0.1%) of bromine (if the Br source is from BFRs) and less than 1,000 ppm (0.1%) of chlorine (if the Cl source is from CFRs or PVC or PVC copolymers). All printed circuit board (PCB) and substrate laminates contain bromine/chlorine total less than 1,500 ppm (0.15%) with a maximum chlorine of 900 ppm (0.09%) and maximum bromine being 900 ppm (0.09%).
  • A minimum of 10% post-consumer recycled plastic enclosure on all new OptiPlex generation form-factors.
  • EPEAT Gold Registered in US. EPEAT registration varies by country – see www.epeat.net for registration status by country.

Dell’s new generation of Latitude E-family laptops are the most environmentally-responsible Latitude laptops ever.

Environmentally-Conscious Principles

Dell Latitude E-Family laptops are engineered to respect our planet and offer services that minimize energy consumption and help recycle.

Confidential

slide13
Go-Anywhere Productivity

Agile Performance

Dell Latitude E-Family laptops deliver agile performance to match productivity needs and help end users work effectively and efficiently, without interruption.

Performance, versatility and collaboration features that that help end users be more productive than ever – no matter where they’re working, when they’re working, or who they’re collaborating with.

Effective Collaboration

Dell Latitude E-Family laptops enable end users to easily connect and collaborate with colleagues anytime, anywhere.

Versatile Usage

Dell Latitude E-Family laptops help professionals work comfortably and flexibly with intuitive design features that adapt to fit their unique work styles.

Confidential

slide14
Go-Anywhere Productivity

Agile Performance

Dell Latitude E-Family laptops deliver agile performance to match productivity needs and help end users work effectively and efficiently, without interruption.

  • Power through your day with the latest Intel® Core™ i5 or i7 processor options, high-bandwidth DDR3 memory and Intel® HD or NVIDIA® graphics.
  • Stay productive with up to 32.8 hours1of battery life, 3-year battery and E-Family Battery Slice options, and ExpressCharge™ for 80% recharge in an hour.
  • Get up and going fast when traveling from site to site with Intel Rapid Start and Intel Smart Connect.2
  • With optional 9-cell battery, optional 9-cell battery slice, optional 3-cell modular bay battery and optional SSD. Based on testing using the Mobile Mark 2007 battery life benchmark test. For more information about this benchmark test, visit www.bapco.com. Test results should be used only to compare one product with another and are not a guarantee you will experience the same battery life. Battery life may be significantly less than the test results and varies depending on your product’s configuration, software, usage, operating conditions, power management settings and other factors. Maximum battery life will decrease with time and use.
  • WiFienabled connection required. System must be on or in sleep mode with application running to update.

Confidential

slide15
Go-Anywhere Productivity

Effective Collaboration

Dell Latitude E-Family laptops enable end users to easily connect and collaborate with colleagues anytime, anywhere.

  • Connect with colleagues from virtually anywhere with the high-performing antenna and latest wireless and mobile broadband options.
  • Communicate effectively worldwide with optional built-in HD webcam, array micro-phones and Microsoft Unified Communications certifications for an optimal video conference experience.

Confidential

slide16
Go-Anywhere Productivity
  • Work comfortably and flexibly with 180 degree LCD movement, comfortable, responsive keyboard and enlarged touchpad, and dedicated number keypad on 15” laptops.
  • Easily work in low-light settings with the optional backlit keyboard.
  • Work efficiently with USB 3.0 for fast data transfers and USB Powershare to charge USB 3.0 devices while in sleep mode.

Versatile Usage

Dell Latitude E-Family laptops help professionals work comfortably and flexibly with intuitive design features that adapt to fit their unique work styles.

Confidential

slide17
Business-Class Control

Efficient Manageability

Dell Latitude E-Family laptops deliver a choice of remote manageable hardware and solutions to help you manage your systems with ease.

Efficient manageability, confident security, long-term stability and proven service and support for uncompromised IT control over your laptops.

Confident Security

Dell Latitude E-Family laptops deliver confident security with robust access control and strong data protection.

Long-term Stability

Dell Latitude long lifecycles and managed transitions ensure long-term stability that helps organizations save time and money.

Proven Service & Support

Dell Latitude E-Family laptops are put into production fast and remain up and running with services designed to configure, deploy, manage, and support your PCs.

Confidential

slide18
Business-Class Control

Efficient Manageability

Dell Latitude E-Family laptops deliver a choice of remote manageable hardware and solutions to help you manage your systems with ease.

  • Remotely manage your Latitude E-family laptops with the latest Intel® vPro systems management iAMT 8.x with Dell‘s remote BIOS management and Dell’s remote hard drive wipe.
  • Minimize stocked parts with one common dock, AC adapter and accessories for typically up to 5 generations of a family or longer.
  • Easily share optical drives, hard drives and batteries between laptops with common media modules.
  • Upgrade components conveniently via one single access door, now with fewer screws.
  • Save time and money with easy to use centralized systems management appliances from Dell KACE™.

Confidential

slide19
Business-Class Control

Confident Security

Dell Latitude E-Family laptops deliver confident security with robust access control and strong data protection.

  • Safeguard data and meet compliance regulations with Trusted Platform Module (TPM), Dell Data Protection | Encryption and encrypted hard drive options.
  • Control who has access to your data with ControlVault™ and contactless smart card and fingerprint reader login access options.
  • Strengthen security with industry standard anti-virus, physical hardware lock and optional remote hard drive location and wipe service.
  • Help prevent system viruses and contain data leaks with port control options.

Confidential

slide20
Business-Class Control
  • Confidently plan future product roll-outs with ImageWatch™ advance look at software and hardware changes.
  • Maximize ROI with 15+ months stable lifecycle and 60 to 90 days transition period.
  • Easily order replacement parts and resolve issues by standardizing Latitude E-Family laptops to a global configuration with Global Standard Platform.

Long-term Stability

Dell Latitude long lifecycles and managed transitions ensure long-term stability that helps organizations save time and money.

Confidential

slide21
Business-Class Control
  • Customize support services for your specific needs with Dell ProSupport for IT or End Users.
  • Simplify and accelerate the customization and utilization of your new Latitude E-Family laptops with Dell Configuration and Deployment Services.
  • Protect data by tracking lost or stolen laptops with Dell Asset Tagging and Reporting as well as Computrace.

Proven Service & Support

Dell Latitude E-Family laptops are put into production fast and remain up and running with services designed to configure, deploy, manage, and support your PCs.

Confidential

slide22
Integrated Solutions

Dell Data Protection

Protect data no matter where it is with the most comprehensive and flexible data protection and encryption solutions.

Tailored solutions for cost effective security, management, and productivity in next-generation end user computing environments.

Dell Systems Management

Save time and money with efficient solutions for centralizing management, automating processes, and reducing support costs.

Dell Desktop Virtualization

Improve data security, streamline management, and speed time to value with purpose-built hardware, software, and services.

Dell Cloud (SaaS) Services

Gain efficiencies by offloading selective IT tasks to a cloud and adopting an on-demand, pay-as-you-go model that scales with your needs.

Confidential

slide23
Integrated Solutions

Dell Data Protection

Protect data no matter where it is with the most comprehensive and flexible data protection and encryption solutions.

  • Authentication Software
  • Manage strong authentication – Supports single sign on, pre-boot authentication, TPM and self-encrypting drives
  • Intuitive interface that allows end users to easily enroll credentials
  • Supports RSA’s SecurID, passwords, contactless Smart Cards, Smart Cards, multi-factor, biometric information and system passwords
  • Dell Data Protection | Encryption
  • Single solution for system disk and removable media vs. multiple software
  • One-touch preset compliance policy templates to enable fast deployment
  • Extremely flexible encryption based on user profile, data sensitivity and compliance needs instead of sector based that is either encrypted or not
  • Highest level of Federal Information Processing Standards 140-2 certification commercially available with optional Hardware Encryption

Confidential

slide24
Integrated Solutions

Dell Systems Management

Save time and money with efficient solutions for centralizing management, automating processes, and reducing support costs.

  • Automating everyday management tasks with tools and utilities
  • Implement a KACE management appliance – 61%* report the appliance paid for itself in less than 3 months
  • Do it yourself with a leading client management solution

Centralized Management

Confidential

slide25
Dell Virtualization Solutions Portfolio

Integrated Solutions

Simplified

Simple IT Infrastructure

Enterprise

Advanced IT Infrastructure

On Premise

DVS SimplifiedAppliance

Dell Hosted

Customer Managed

Desktop as a Service

Coming in mid-2012

DVS Enterprise

Integrated Solution Stack

Dell Desktop Virtualization

Improve data security, streamline management, and speed time to value with purpose-built hardware, software, and services.

Dell Hosted

Dell Managed

  • Integrated validated solution stacks simplify deployment and decrease risk
  • Purpose built solutions with open, proven infrastructure - all the components from a single source
  • End to end platforms and services to meet the specific needs of our customers

Confidential

slide26
Integrated Solutions
  • Offload and automate manual, resource-intensive tasks such as:
  • Email management
  • Software inventory and license management
  • Desktop management
  • Online backup and restore
  • Laptop data encryption
  • Remote infrastructure monitoring
  • Crisis management and alerting

Dell Cloud (SaaS) Services

Gain efficiencies by offloading selective IT tasks to a cloud and adopting an on-demand, pay-as-you-go model that scales with your needs.

Confidential

slide28
E6530 Weight, Dimensions, Top/Right View

display latch

microphone

display release latch

camera

camera status light

display

power button

HDMI connector

eSata/USB2.0 connector

powered USB 3.0 connector

optical drive

wireless switch

ExpressCard slot

fingerprint reader

security digital (SD) memory-card reader

contactless smart card Reader

touchpad

touchpad buttons (2)

touchpad buttons (3)

trackstick

keyboard

volume control buttons

device status light

Starting weight:

5.4lbs / 2.449kg with a 4-cell battery, airbay, and optional SSD

Dimensions:

  • Width: 15.12” / 384.00mm
  • Depth: 10.16” / 258.00mm
  • Height (front/back): 1.11-1.34” / 28.00-34.20mm
slide29
E6530 Back/Left View

network connector

security cable slot

modem connector

Power, battery, HDD status lights

power connector

USB 2.0 connector

VGA connector

USB 3.0 connector

audio connector

cooling vents

smart card slot

slide33
E6430 Weight, Dimensions, Top/Right View

microphone

display release latch

camera

camera status light

display latch

display

power button

eSata/USB2.0 connector

USB 3.0 connector

Powered USB3.0 connector

volume control buttons

wireless switch

optical drive

ExpressCard slot

fingerprint reader

security memory-card (SD) reader

contactless smart card reader

touchpad buttons (2)

touchpad

trackstickbuttons (3)

trackstick

keyboard

device status lights

Starting weight:

4.44lbs/2.014kg with a 4-cell battery, airbay, and optional SSD

Dimensions:

  • Width: 13.86” / 352mm
  • Depth: 9.49” / 241mm
  • Height (front/back): 1.05-1.27” / 26.60-32.40mm
slide34
E6430 Back/Left View

HDMI connector

security cable slot

modem connector

Power, battery, HDD status lights

power connector

network connector

USB 2.0 connector

VGA connector

audio connector

cooling vents

smart card slot

e6430s weight dimensions top right view
E6430s Weight, Dimensions, Top/Right View

microphone

camera

camera status light

display

power button

eSATA/USB 2.0 connector

powered USB 3.0 connector

volume control buttons

wireless switch

optical drive

11. ExpressCard slot(34mm)

fingerprint reader

contactless smart card reader

security digital (SD) memory-card reader

touchpad buttons

touchpad

trackstick buttons

trackstick

keyboard

device status lights

Starting weight:

3.75lbs/1.70kg with a 3-cell battery, airbay, and mSATA SSD

Dimensions:

  • Width: 13.19” / 335mm
  • Depth: 8.80” / 223.3mm
  • Height (front/back): 1.06-1.22” / 26.8-30.9mm
e6430s back left view
E6430s Back/Left View

security network slot

network connector

mini-HDMI connector

power, battery, and HDD status lights

USB3.0 connector

power connector

VGA connector

audio connector

cooling vents

smart card slot

e6330 weight dimensions top right view
E6330 Weight, Dimensions, Top/Right View

microphone

camera

camera status light

display

power button

eSATA/USB 2.0 connector

powered USB 3.0 connector

volume control buttons

wireless switch

optical drive

11. ExpressCard slot(34mm)

fingerprint reader

contactless smart card reader

security digital (SD) memory-card reader

touchpad buttons

touchpad

trackstick buttons

trackstick

keyboard

device status lights

Starting weight:

3.54lbs/1.606kg with a 3-cell battery, airbay, mSATA SSD

Dimensions:

  • Width: 13.19” / 335mm
  • Depth: 8.80” / 223.3mm
  • Height (front/back): 1.0-1.18” / 25.4-30.1mm
e6330 back left view
E6330 Back/Left View

security network slot

network connector

mini-HDMI connector

power, battery, and HDD status lights

USB3.0 connector

power connector

VGA connector

audio connector

cooling vents

smart card slot

e6230 weight dimensions top right view
E6230 Weight, Dimensions, Top/Right View

microphone

camera

camera status light

display

power button

HDMI

USB 3.0 connector

powered USB3.0 connector

wireless switch

ExpressCard slot (34mm)

finger print reader

touchpad buttons (2)

touchpad

contactless smart card reader (optional)

keyboard

volume and control buttons (3)

device status lights

Starting weight:

3.05lbs/1.383kg with a 3-cell battery, airbay, and mSATA SSD

Dimensions:

  • Width: 12.2” / 309mm
  • Depth: 8.9” / 226mm
  • Height (front/back): 0.88”-0.97” / 22.4-24.65mm
e6230 back left view
E6230 Back/Left View

network connector

power, battery, and HDD status light

security cable slot

power connector

VGA connector

eSATA/USB 2.0 connector

audio connector

cooling vents

security digital (SD_ memory card reader

smart card slot

e6430 atg weight dimensions top right view
E6430 ATG Weight, Dimensions, Top/Right View

microphone

display release latch

camera

camera status light

display latch

display

power button

eSata/USB2.0 connector

USB 3.0 connector

powered USB3.0 connector

volume control buttons

wireless switch

optical drive

ExpressCard slot

fingerprint reader

secure digital (SD) memory-card reader

contactless smart card reader

touchpad buttons (2)

touchpad

trackstick buttons (3)

trackstick

keyboard

device status lights

Starting weight:

5.52lbs/2.5kg with a 6-cell battery, airbay

Dimensions: (with port covers)

  • Width: 14.07” / 357.30mm
  • Depth: 9.70” / 246.50mm
  • Height (front/back): 1.16”-1.37” / 29.50mm-34.80mm
e6430 atg back left view
E6430 ATG Back/Left View

HDMI connector

security cable slot

modem connector or WWAN pass through (optional)

Power, battery, and HDD status lights

power connector

network connector

USB 2.0 connector

VGA connector

audio connector

cooling vents

smart card slot

e5530 weight dimensions top right view
E5530 Weight, Dimensions, Top/Right View

Figure 1. Front View

1. Display Latch

2. Microphone (optional)

3. Display Release Latch

4. Camera (optional)

5. Camera Status Light (optional)

6. Display

7. Microphone

8. Power Button

9. VGA Connector

10. Optical-Drive Eject Button

11. Optical-Drive

12. USB 2.0 Connector

13. Audio Connector

14. Fingerprint Reader (optional)

15. Wireless Switch

16. Device Status Indicators

17. Touchpad Buttons

18. Touchpad

19. Trackstick Buttons (optional)

20. Trackstick (optional)

21. Keyboard

22. Device Status Lights

23. Volume Control Buttons

Preliminary Starting weight:

5.25lbs/2.38kg4with a 4-cell battery, airbay and SSD

Preliminary Dimensions: (with port covers)

  • Width: 15.28” / 388.00mm
  • Depth: 9.88” / 251.00mm
  • Height (front/back): 1.19”-1.31” / 30.20mm-33.20mm
e5530 back left view
E5530 Back/Left View

Figure 2. Back View

1. Network Connector

2. USB 2.0 Connector

3. Modem Connector (optional)

4. Power Connector

5. Security Cable Slot

6. Cooling Vents

7. HDMI Connector

8. eSATA/USB 3.0 Connector

9. USB 3.0 Connector

10. Secure Digital (SD) memory-card slot

11. ExpressCard/SmartCard Slot (optional)

e5430 weight dimensions top right view
E5430 Weight, Dimensions, Top/Right View

Figure 1. Front View

1. microphone (optional)

2. display release latch

3. camera (optional)

4. camera status light (optional)

5. display latch

6. display

7. power button

8. VGA connector

9. microphone

10. volume control buttons

11. optical-drive eject button

12. optical drive

13. USB 2.0 connector

14. audio connector

15. fingerprint reader (optional)

16. touchpad

17. touchpad buttons

18. wireless switch

19. device status indicators

20. trackstick buttons (optional)

21. trackstick (optional)

22. keyboard

23. device status lights

15 14 13

Preliminary Starting weight:

4.50lbs/2.04kg4with a 4-cell battery, airbay and SSD

Preliminary Dimensions: (with port covers)

  • Width: 13.78” / 350.00mm
  • Depth: 9.45” / 240.00mm
  • Height (front/back): 1.18”-1.28” / 29.00mm-32.50mm
e5430 back left view
E5430 Back/Left View

Figure 2. Back View

1. Network Connector

2. USB 2.0 Connector

3. Modem Connector (optional)

4. Power Connector

5. Security Cable Slot

6. Cooling Vents

7. HDMI Connector

8. eSATA/USB 3.0 Connector

9. USB 3.0 Connector

10. Secure Digital (SD) memory-card Slot

11. ExpressCard/SmartCard Slot (optional)

latitude e4 intel technology chief river architecture
Latitude E4 – Intel TechnologyChief River Architecture
  • E4 products are built with Intel Ivy Bridge Technology
  • Latest Intel 22nm Process Technology.
  • 3rd generation higher Performance Ivy Bridge Dual Core or Quad Core Processor with Panther Point PCH
  • Intel ® HD Graphics 4000 w/ DX11 compliant, 3 independent displays with docking.
  • Optional Intel® Rapid Start Technology for Latitude E6x30
  • Optional Intel® Smart Connect Technologyfor Latitude E6x30
  • Optional Intel vPro™ technology(on i5 & i7) with Active Management Technology 8.0
  • Intel® Wireless Display 3.0 driver included in Intel WLAN/WiMAX options.
  • Selected transitional Sandy Bridge and Ivy Bridge Processors are also supported on Latitude E6x30 and E5x30

* Offerings vary by product, details please refer to CPU MPR

memory
Memory

Your computer supports a maximum of 8GB of memory when you use two 4GB DIMMs; however, 32-bit operating systems, such as the 32-bit version of Microsoft® Windows® 7, can only use a maximum of 4GB of address space. Moreover, certain components within the computer require address space in the 4GB range. Any address space reserved for these components cannot be used by computer memory; therefore, the amount of memory available to a 32-bit operating system is less than 4GB.

NOTES:

Greater than 4GB memory requires a 64-bit operating system.

1600MHz is factory installed. 1333MHz is compatible with E4 platforms.

1600MHz memory will only perform as 1600MHz memory when 3rd generation CPUs are used. It will perform as 1333MHz memory if 2nd generation CPUs are installed in the system..

Memory modules should be installed in pairs of matched memory size, speed, and technology. If the memory modules are not installed in matched pairs, the computer will continue to operate.

latitude primary storage
Latitude Primary Storage
  • Full Disk Encryption drives provide hardware encrypted data protection which can be activated within a few seconds centrally and can be much safer and faster than software based encryption. Note: Encrypted drives require the system be configured in AHCI mode.
  • Mobility Solid State Drives offer highly reliable, durable and lightweight storage. SSDs provide improved performance and operate quieter and cooler than standard hard drives.
  • Solid State Hybrid Hard Drive Hard disk with 8GB flash storage. Delivers impressive performance and responsiveness with the simplicity of a 2.5” single drive form factor
  • Intel Rapid Recover Technology (IRRT)
  • Latitude systems ship standard with IRRT functionality (exception: AHCI with FDE drives). The IRRT feature uses RAID 1 mirroring functionality to copy data from the system primary drive to an external eSATA recovery drive. This gives the user additional security as their hard disk contents can be backed up at any time when connected to an external eSATA drive through the system eSATA port or through the E-Port Docking system. Data recovery is made easy with the IRRT feature.
  • Technology Transition: Advanced Format drives
  • The Hard Disk Drive (HDD) industry is moving towards Advanced Format (AF) with 4k sector HDDs to address the current limitations with the 512-byte sector HDDs. Please find more information and instructions to ensure compatibility and performance optimization at Dell.com/512e-drives

NEW

  • * E6230 only offers 7mm HDD options. 500gb 7mm will be available after launch, Est July block
common modular accessories
Common Modular Accessories
  • E-Modular bay II
    • An external solution for additional functionality via eSATA connection
    • Enables optical and hard drives to be used externally
    • E6230 must use E-Modular bay II for optical drive selection.
  • E-Modules
    • Common & shared across E3 laptops.
    • Used internally on some models (E6420, E6520, E6320 and E6420 ATG), and externally in the E-Modular bay II (HDD and Optical drives only)
      • E-Modular USB 3.0 - Provides 2 USB 3.0 ports for those who need it or 2 additional USB 2.0 ports
      • E-Modular 320GB HDD - Provides 2nd HDD capability internally or externally
      • E-Modular DVD-ROM or DVDRW – DVD capabilities that can be used internally or externally
      • E-Modular 30Wh Battery – Provides an extra power boost
webcam specifications
Webcam Specifications

Easy Remote Collaboration: Videoconference online with an optional built-in camera (comes with Dell Webcam software pre-installed for camera setup)

slide96
A = Card Serial Number (CSN) Read, HID Secure Application Area Read, and Read / Write of All Other Application Areas. iCLASS specific anti-collision to support multiple cards in the field. HID Secure Application can be used for pre-boot authentication

B = Read of Card Serial Number (MIFARE: UID, FeliCA: IDm) for pre-boot authentication and via PC/SC 2.01, raw frame communication allowing implementation of both security protocols at application level, MIFARE anti-collision to support multiple cards in the field.

C= ISO/IEC 14443 Part 4 communication via PC/SC 2.01, raw frame communication, anti-collision to support multiple cards in the field. CHUID from FIPS-201 PIV-II cards can be used for pre-boot authentication. Includes support for MIFARE/DESFire in native, wrapped and ISO communication modes.

D = UID read (can be used for pre-boot authentication), raw frame communication, PC/SC 2.01 synchronous card support for specific chip types, anti-collision to support multiple cards in the field.

Security

latitude e4 battery overview
Latitude E4 – Battery Overview
  • Compatibility chart
  • E5430/E5530 are ExpressCharge Capable system while E5420/E5520 are not. NEW
  • E6230/E6330/E6430s refresh batteries to 3.0Ahs; New Batteries will be qualified on E6220/E6320 – Schedule TBD NEW
  • All 3.0Ah Batteries except 3YRW batteries and 9cell slice, are ExpressCharge Capable. NEW
  • Dell Battery Management Function, allows users to customize their battery charge plan via BIOS with following options. NEW
    • Standard Charge;
    • Express Charge
    • Predominately AC use
    • Auto Charge
    • Custom Charge
      • Start Charging   %
      • Stop Charging   %
  • Express charge benefits
    • For a battery advertised as having the ExpressCharge™ feature, the battery typically will have greater than 80% charge after about an hour of charging with the system off, and fully charge in about 2 hours with the system off.
    • Enabling Expresscharge™ requires both Latitude notebook and battery that is used on the system both ExpressCharge capable. Lack any of above requirement, ExpressCharget will not be enabled.
e4 power adapters
E4 Power Adapters
  • 65W Standard is recommended for E6230, E6330, E6430s, E6430 UMA, E6530UMA, E5530, E5430.
  • 65W BFR/PVC Free is required for BFR/PVC Free Configurations.
  • 90W Standard is required for discrete gfx option on E6430 Discrete, E6530 Discrete
  • All E6x30 AC adapters are compliant with ErP Lot 6 Compliant, new Europe Regulatory Power Requirements effective 1/3/2013
latitude e4 keyboards
Latitude E4 Keyboards
  • Most E4 platforms support both standard and backlit keyboard options
  • All 15” keyboards include a numpad
  • All standard (non-backlit) keyboards have an antimicrobial coating
  • Most keyboards are leveraged across more than one system
  • Not all Latitude languages are supported with Backlit Keyboards
  • Advanced series dual pointing keyboards also include fingerprint reader
latitude keyboards hot key definition
Latitude Keyboards Hot Key Definition

Dell Confidential - NDA Use only

e family docking
6

9

4

2

11

5

10

7

8

1

3

(1) E-Monitor Stand Connector

(2) eSATA

(3) PS/2

(4) Network Connector (RJ-45)

(5) USB3.0 x 2

(6) Parallel Port

(7) Serial Port

(8) VGA

(9) DVI x 2

(10) Display Port 1.2 x 2

(11) AC Adapter Connector

E-Port Plus Back View

E-Family Docking

*See important information at end of document

e family docking1
4

8

6

2

5

7

3

1

E-Port Back View

(5) VGA

(6) DVI

(7) Display Port

(8) AC Adapter Connector

(1) E-Monitor Stand Connector

(2) eSATA

(3) USB3.0 x 2

(4) Network Connector (RJ-45)

E-Family Docking

*See important information at end of document

e family docking2
1

5

2

3

(1) 2 x USB

(2) 2 x PS/2

(3) Parallel Port

(4) Serial Port

(5) Docking Connector

4

E-Legacy Extender

E-Family Docking

*See important information at end of document

environmental specifications
Environmental Specifications

Link to Product Safety, EMC and Environmental Data Sheets:

http://www.dell.com/content/topics/global.aspx/about_dell/values/regulatory_compliance/dec_conform?c=us&cs=04&l=en&s=bsd&redirect=1

ad
