aerobic plate count
Aerobic Plate Count
  • Provides general estimate of live, aerobic, bacteria
  • Excludes
    • Obligate Anaerobes
    • Microaerophiles
plate counts
Plate Counts
  • Assumption
    • Each colonies arises from a single bacterial cell
    • Bacteria like to “clump” together so some colonies may arise from more than one cell
  • Report as
    • Colony Forming Unit (CFU)/gram or ml
    • NOT at total bacteria
apc results
APC Results
  • Evaluate Sanitation of Product
  • Predict Shelf-life
  • “Safety” Indicator
  • Monitor Environment
limitations of apc
Limitations of APC
  • Only aerobic organisms are counted
  • Bacteria Type not known
  • Media may not support growth of certain bacteria
  • Eye strain/Human Error
  • Hard to Distinguish Between food particles and bacteria
  • Don’t Use on Fermented Foods
  • Colonies may be too small to see
types of samples
Types of Samples
  • Liquid
    • Non-viscous Liquids can be measured with pipet
    • Viscous liquids should be weighed
  • Solid
    • Aseptically weigh Sample
  • Sponge/Swab

Collect sample by swabbing a defined area

  • Environmental and Container
    • Rinse inside of Containers
    • Open Plate to Collect Air Samples
    • RODAC Plates
protocol for plate counts
Protocol for Plate Counts
  • Prepare a Sample Homogenate
    • 1:10 dilution
    • 1 part sample to 10 parts total volume
  • Blend in Blender or Stomacher for 2 min.

90 ml of diluent

10 g/ml sample

1:10 Dilution – 10-1

formula
Formula
  • 10 ml/g sample, want 1:100 dilution
    • 100 – 10 = 90 ml of diluent needed
  • Start with Different Sample Sizes
    • 50 g sample
      • Must have 500 g total volume for 1:10
      • 500 – 50 = 450 ml diluent needed
    • 95 ml sample
      • Must have 950 total volume for 1:10
      • 950 – 95 = 855 ml of diluent
plate count protocol
Plate Count Protocol
  • Prepare Serial Dilutions
    • Dilute to a level where you will get countable colonies on plates
    • Use a NEW STERILE PIPET between each dilution
    • Place pipet tip down in pipet tanks
  • Shake each dilution bottle 25 times in a 90 degree arc within 7 seconds.
  • Phosphate Buffer or Peptone Buffer to Dilute
dilutions
Dilutions

Dilution Blanks Containing 90 ml Diluent

Sample Homogenate

10 ml

10 ml

10 ml

10 ml

10-2

10-3

10-4

10-5

10-1

(1:100)

(1:1000)

(1:100000)

(1:10)

(1:10000)

plating
Plating

Put 1 ml of Each Dilution into Empty Petri-Dish

10-4

10-5

10-2

10-3

10-1

1 ml

1 ml

1 ml

1 ml

1 ml

1 ml

1 ml

1 ml

1 ml

1 ml

apc protocol
APC – Protocol
  • Add 18-20 ml of tempered (45-50 F), molten plate count agar to the petri dish.
    • Agar MUST be tempered or the bacteria will be killed by heat
  • Standard Methods or Plate Count Agar
  • Swirl 10 times in each direction
  • Allow to Solidify
  • Incubate inverted at 35-37 C for 48 hours
sterilization
Sterilization
  • Equipment and Media MUST be Sterile
  • Hot Air Sterilization
    • 170 C for 1 hour
      • Equipment Temperature
      • Put in oven for 2 hours
      • Wrap in paper, foil, etc.
  • Steam Sterilization
    • 121 C for 15 min. MUST have 15 psi pressure
      • Liquid Media or Equipment
      • Don’t Put Lids on tightly
counting plates
Counting Plates
  • Only count plates with 25-250 colonies
  • More than 250
    • Too Numerous To Count – TNTC
  • Less than 25
    • Too Few to Count - TFTC
counting plates1
Counting Plates

1 Too Numerous to Count

2 Too Few to Count

  • Average two countable plates and Multiply by Dilution Factor
    • Count is 175 x 104
  • Must Convert to TWO Significant Digits
    • 1.8 x 106 cfu/ml or g
counting examples
Counting - Examples

Use ALL FOUR even though 300 is outside range. If ONE

PLATE is in RANGE, use BOTH for Average.

250 x 102 – 2.5 x 104

125 x 103 – 1.3 x 105

AVERAGE – 7.8 x 104 cfu/g or ml

counting examples1
Counting Examples

All Dilutions are outside Range so we MUST use counts

Outside range

350 x 104 – 3.5 x 106 cfu/ml or g*

Use an “*” when using dilutions outside countable ranges

This means it is an ESTIMATED count

counting examples2
Counting Examples

If Both Dilutions are outside Range, use the Higher Dilution

(LOWER COUNTS)

7.5 x 103 cfu/ml or g*

overloaded plates
Overloaded Plates
  • Use Highest Dilution and Use Grid on Colony Counter
    • 1 Grid = 1 cm2
    • A standard Plastic Plate has 56 cm2 surface area
  • If <10 colonies/cm2, count 12 squares (6 consecutive horizontally and 6 consecutive vertically)
    • Total and Divide by 12 (average). Multiply by 56 to get total colonies on plate. Report as Estimate
  • If >10 colonies/cm2
    • Count 4 squares, average and multiply by 56
apc variations
APC Variations
  • Psychrotrophic
    • Incubate at 5-7 C for 10 days
    • Use Pre-poured Plates
  • Thermoduric
    • Hold 5 ml liquid sample or 1:10 diluent of solid sample in 60-80 C water bath for 30 min
    • Cool on ice for 10 min
    • Plate and incubate
dilution variations
Dilution Variations

99 ml Dilution Blanks

1 ml

1 ml

1 ml

10-7

10-3

10-5

10-1

1 ml

1 ml

0.1 ml

0.1 ml

1 ml

1 ml

0.1 ml

0.1 ml

-5

-7

-1

-3

-6

-8

-2

-4

CAN NOT use with petri-film
