  1. VIDEO AT THE EDGE • PROFESSIONAL • IPTV SOLUTIONS

  2. A SINGLE SCALABLE NETWORK • Data | Voice | Video

  3. A SINGLE SCALABLE NETWORKData - Voice - Video • A single • infrastructure Standard components Low cost upgrade to handle video

  4. Full-screen, full-resolution • MPEG-2 or MPEG-4 • Real time encoding • SD and HD video • Uses IP infrastructure • Multicast, webcast or on-demand

  5. IPTV quality levels • MPEG-2 at 4-7 Mbps = digital cable (very close to DVD) • MPEG-2 at 15 Mbps = more sharpness, fewer artifacts, crisper color • MPEG-4 (Part 10 / AVC) = up to 4 times more efficient

  6. RF vs. IPTV Coax, UTP, fiber etc. IP network • Fixed • Flexible • Proprietary • Interoperable • Sometimes Analog • Always digital • Redundant • Converged • Home run and/or hard, • One soft switch matrixswitched for all telecom

  7. Virtual video switch matrix

  8. Unicast vs. Multicast

  9. REGIONAL BROADCAST OR CABLE TV • Video transport: AndoverTV • News and weather feeds: Network TV affiliates • Radio webcasts: Colombian radio

  10. SCHOOL OR UNIVERSITY • TV distribution: Pennfield, MI • Internet2: Michigan Tech • PEG station to classrooms: Madison County, GA • Information channel: Blue Ridge Community College

  11. CORPORATE OR GOVERNMENT • Cable news feeds to network: AFL-CIO, United Airlines • Video distribution applications: Northrop Grumman Sandia Nat’l Laboratories Johnson Space Center Raytheon

  12. DIGITAL SIGNAGE NETWORK • Campus-wide signage & emergency: Michigan Tech • Signage in casinos: Progressive Gaming International

  13. HOSPITAL, HOTEL OR MULTI-RESIDENCE • TV & educational videos: Metro Hospital • Guest room & residential TV: A number of hotel & condominium projects

  14. AV DISTRIBUTION OR OVERFLOW • Overflow rooms for trials: US District Courts in NY, LA, VA, RI, MS • Conference & training centers • Operating room video to classrooms: Loma Linda School of Dentistry

  15. RURAL TELCOS & SMALLER ISPS • Multicast & on-demand video: Several overseas & domestic providers • Transport & backhaul: Qwest, Iowa Communications, Togo Telecom

  16. VIDEOCONFERENCING - TELEMEDICINE • Hospital demos: Cisco Systems • Intra-facility video: Johns Hopkins Hospital • Distance learning: Various school districts

  17. AVN200 Stand Alone Encoder • Standard definition • Up to 720 x 480 • Analog input • MPEG-2 output • 1.5 to 7.5 Mbps

  18. AVN210 Rack Mount Encoder • Standard definition • Up to 720 x 480 • Analog input • MPEG-2 output • 1.5 to 7.5 Mbps

  19. AVN220 Encoder Blade • Standard definition • Up to 720 x 480 • Analog input • MPEG-2 output • 1.5 to 15 Mbps

  20. AVN420 Encoder Blade • Standard definition • Up to 720 x 480 • Analog input • MPEG-4 Part 10/AVC • 100 kbps to 4 Mbps

  21. AVN441HD Encoder Blade • High definition • Up to 1920 x 1080 • Analog or digital input • MPEG-4 Part 10/AVC • 4 to 20 Mbps

  22. MPP200 Chassis • Media Processing Platform • Holds 1 or 2 encoder blades • Rack mountable - one RU

  23. MPP1700 Chassis • Media Processing Platform • Holds up to 17 encoder blades • Redundant power supply • Rack mountable - three RU

  24. Amino Set Top Boxes • Decode MPEG2 or MPEG4 • Video & audio outputs for TVs and video monitors • SD and HD models available • Sold by VSI only in conjunction with AVN series encoders

  25. PackeTV® Webcaster • Complete streaming service • VSI gear plus CDN subscription • Viewers watch with QuickTime or VLC plug-in • Or a television with IPTV set-top box

  26. PackeTV Webcast Solution

  27. PackeTV Software Suite • PackeTV Manger • Manages and controls AVN-series encoders • Start/stop streams • Set network properties • Create play lists • PackeTV Client • Click, view & record streams

  28. Road Map • 16-Channel Trunk Card • • Gigabyte Ethernet switch • • For MPP1700 • • Coming 4th Quarter 2009

  29. Value Added Resellers • eVideon™ from Optimal Solutions • Live TV over IP network • Video on demand • School & health care versions

  30. Value Added Resellers • infovalue • BizTV™ & QuickTV™ streaming solutions • SuiteTV™ video on demand • NextGenTV™ video on demand • SimulcastTV™ for large venues

  31. Demonstration/Registration Program • For authorized resellers

  32. About Visionary Solutions • Designer and manufacturer • OEM video technology • Founded in 1995 • The cost performance leader • in IPTV
