behind the scenes of the enterprise development reference architecture edra

“Behind the Scenes” of the Enterprise Development Reference Architecture (EDRA)

Jonathan Wanagel

Microsoft patterns & practices

http://www.microsoft.com/practices

agenda
Agenda
  • About This Talk
  • What is p&p and EDRA
  • Application Architecture Challenges
  • Building an Architecture
  • Creating an Architectural Framework
  • Summary
  • Questions
about this talk
About This Talk
  • Things to Expect
    • Polls
    • Storytelling
    • Questions
    • Intermission
agenda4
Agenda
  • About This Talk
  • What is p&p and EDRA
  • Application Architecture Challenges
  • Building an Architecture
  • Creating an Architectural Framework
  • Summary
  • Questions
microsoft patterns practices
Microsoft patterns & practices
  • Guidance on Enterprise Business Applications
  • Available for download from Microsoft’s website
  • Learning the most significant challenges from customers
  • Analyzing the patterns and/or best practices for solving those challenges
enterprise development reference architecture edra
Enterprise Development Reference Architecture (EDRA)
  • EDRA incorporates numerous best practices for solving enterprise business system challenges
  • Utilizes various p&p guidance to apply the best practices
  • Includes a reusable implementation of the architecture
  • Includes complete conceptual architecture documentation
  • Includes Global Bank sample application demonstrating real-world uses cases using the framework
edra key benefits
EDRA Key Benefits
  • Extensible architecture for cross cutting concerns
  • Support for secure infrastructure deployments
  • Support for integration
  • Improved developer productivity
  • Easier adjustment to significant system requirement changes
reference architecture challenges
Integration Capable

Multiple transport

Exception handling

Application hosting

Extensible architecture

Services Based

Stateless Components

Secure deployment

Transport choice

Developer Productivity

Developer Portability

Concern Separation

Live Configuration Updates

Requirements Change Adaptability (deployment, transport, etc)

Consistent Development Experience

Consistent Usage of Best Practices

Application Architectural Governance

Transaction Management

Authentication

Authorization

Validation

Remote Debugging

Compensating Transaction

Timeout Management

Instrumentation

Logging

Duplicate Requests (Idempotency)

Business Eventing

Reference Architecture Challenges
agenda9
Agenda
  • About This Talk
  • What is p&p and EDRA
  • Application Architecture Challenges
  • Building an Architecture
  • Creating an Architectural Framework
  • Summary
  • Questions
challenge integration capable
Challenge: Integration Capable
  • Challenge Summary:

An organization can have all the integration infrastructure in the world, such as various networks, EAI middleware, integration server products, messaging systems, etc. However, if an applications architecture is closed and offers no way of interfacing with any of the integration infrastructure, then you have an application that you cannot integrate with.

How can you ensure your application architecture is integration capable so it is possible to be integrated with other systems?

  • Poll
  • Stories
challenge integration capable11
Challenge: Integration Capable
  • More Challenge Details
    • A new application may not start with integration requirements
    • Sometime after deployment, integration requirements come up because of needs from other applications
    • Want to avoid screen scraping or data oriented integration
challenge integration capable12
Challenge: Integration Capable
  • Solution Best Practices
    • Build your application with a cleanly separated business API
    • Expose the business API with an external invocation mechanism
    • Include an interception mechanism to allow adding hooks for raising “business events”
  • Questions
challenge exception management
Challenge: Exception Management
  • Challenge Summary:

All applications will have errors occur during operation, both expected and unexpected types of errors.

When errors occur, how should they get handled by the application?

  • Poll
  • Stories
challenge exception management14
Challenge: Exception Management
  • More Challenge Details
    • Do all errors get reported to the caller or user?
    • What about error information containing information that is a security risk such as “Connection string X failed”?
    • What about reporting errors to the system administrator?
    • What about the error propagation within the system?
challenge exception management15
Challenge: Exception Management
  • Solution Best Practices
    • Categorize errors as “business” errors versus “technical” errors
    • Always propagate errors to the system boundary (unless explicitly handled)
    • Use normal try/catch/throw, not error return codes
    • Business logic code throws “business” errors such as a business rule violation, with a message that is safe and user appropriate
    • At the system boundary, if error is a “technical” error then:
      • Log the error for a system administrator including unique log id
      • Replace error message with generic message to ensure unsafe information is not leaked
      • Include log id in generic message for correlation
  • Questions
challenge secure deployment
Challenge: Secure Deployment
  • Challenge Summary:

A very common infrastructure setup for security is creating a perimeter network (DMZ) that “outsiders” access, separated with a firewall from the secure network. Additionally, there might be another firewall inside the secure network separating your database servers.

How do you design your application architecture so it can be deployed to a secure infrastructure setup?

  • Poll
  • Stories
challenge secure deployment17
Challenge: Secure Deployment
  • More Challenge Details
    • Are the “outsiders” users or systems (i.e. UI or programmatic access)?
    • How do you split your application architecture for the different zones?
challenge secure deployment18
Challenge: Secure Deployment
  • Solution Best Practices
    • Build your application with a cleanly separated business API
    • Split your business tier into an “interface” and “implementation”
    • Handle boundary verification responsibilities (validation, authentication, etc) in the interface
    • Deploy your interface in the DMZ and implementation in the secure network
  • Questions
challenge multiple transports
Challenge: Multiple Transports
  • Challenge Summary:

Sometimes an application needs to be used by multiple external systems, but they do not all support a single communication mechanism.

How do you design your application architecture so it can support multiple communication mechanisms?

  • Poll
  • Stories
challenge multiple transports20
Challenge: Multiple Transports
  • More Challenge Details
    • The organization hasn’t implemented an integration server, or one or more systems are an “exception” to using it
    • This application instance alone cannot justify bringing in an integration server, and expanding scope isn’t realistic
    • Transitioning communication mechanisms and need to support old and new simultaneously, or plan to transition in the future
challenge multiple transports21
Challenge: Multiple Transports
  • Solution Best Practices
    • Create a separation between the communication transport and the rest of the architecture
    • Normalize the request input and request output mechanisms of the architecture and have the transports adapt to them
  • Questions
challenge concern separation
Challenge: Concern Separation
  • Challenge Summary:

Your organization or development team contains a mix of more skilled developers or architects experienced in dealing with technical issues, and less skilled developers experienced in coding business logic and rules.

How can you factor your application architecture so the coding for the technical issues is separated from the coding of the business logic?

  • Poll
  • Stories
challenge concern separation23
Challenge: Concern Separation
  • More Challenge Details
    • Ratio of highly skilled developers to less skilled developers can be very low
    • Coding things such as instrumentation, logging, authentication, database connections, transactions, and authorization tend to be different types of thinking then business logic
    • When business logic and technical code are intermingled, it makes it harder to follow the code when focusing specifically on the business logic or vice versa
challenge concern separation24
Challenge: Concern Separation
  • Solution Best Practices
    • Encapsulate the business logic into specific components called “business actions”
    • Try to move as much technical code as possible into separate components from business logic
    • For each business action, call the necessary technical components before and/or after the business action
    • The components with the technical code can be further sub-divided based on concern type
  • Questions
agenda25
Agenda
  • About This Talk
  • What is p&p and EDRA
  • Application Architecture Challenges
  • Building an Architecture
  • Creating an Architectural Framework
  • Summary
  • Questions
building an architecture
Building An Architecture

Web Browser

Application

Server

ASPX pages

Database

Server

SQL Server Database

slide27

Web Browser

Application

Server

ASPX pages

Business

Tier

Business API

Business Logic

Database

Server

SQL Server Database

slide28

Integration Infrastructure /

External Applications

Web Browser

Application

Server

ASMX pages

ASPX pages

Business Events

Business

Tier

Business API

Business Logic

Interception Mechanism

Database

Server

SQL Server Database

slide29

Integration Infrastructure /

Other Applications

Web Browser

Application

Server

ASMX pages

ASPX pages

Business Events

Business

Tier

Business API

Business Logic

Exception Management

Interception Mechanism

Database

Server

SQL Server Database

slide30

Web Browser

Integration Infrastructure /

Other Applications

Firewall

Application

Server

(DMZ)

ASPX pages

Business Events

Service

Interface

ASMX pages

Business API

Boundary Logic

Firewall

Application

Server

(Secure)

Service

Implementation

Business Logic

Exception Management

Interception Mechanism

Firewall

Database

Server

SQL Server Database

slide31

Web Browser

Integration Infrastructure /

Other Applications

Internal

Application

Firewall

Application

Server

(DMZ)

ASPX pages

Business Events

Service

Interface

ASMX

InProc

MSMQ

Business API

Boundary Logic

Firewall

Application

Server

(Secure)

Service

Implementation

Business Logic

Exception Management

Interception Mechanism

Firewall

Database

Server

SQL Server Database

slide32

Web Browser

Integration Infrastructure /

Other Applications

Internal

Application

Firewall

Application

Server

(DMZ)

ASPX pages

Business Events

Service

Interface

ASMX

InProc

MSMQ

Business API

Concerns

Firewall

Application

Server

(Secure)

Service

Implementation

Concerns

Business

Logic

Biz Actions

Firewall

Database

Server

SQL Server Database

agenda33
Agenda
  • About This Talk
  • What is p&p and EDRA
  • Application Architecture Challenges
  • Building an Architecture
  • Creating an Architectural Framework
  • Summary
  • Questions
creating an architectural framework
Creating an Architectural Framework
  • Creating an architectural framework is taking an architecture and making it reusable
  • Some challenge best practices can help with reusability
  • An architectural framework is itself a best practice for solving many challenges
challenge consistent usage of best practices
Challenge: Consistent Usage of Best Practices
  • Challenge Summary:

Various architectural best practices may be known by different people, but the applications being built by the organization inconsistently apply them.

How can you ensure that best practices are used as new applications are being developed by various development teams across the organization?

challenge consistent usage of best practices36
Challenge: Consistent Usage of Best Practices
  • More Challenge Details
    • Organizations often make efforts to try and improve the quality of architectures across the company
    • Setting up meetings or trainings to share “best practices” across projects or teams
    • Creating documentation or training to show best practices that can be used
  • Why a Framework Helps
    • Usage of best practices on an application can become an “implicit” activity requiring no training or communication
    • Adding best practices to development can also be “implicit”
challenge developer productivity
Challenge: Developer Productivity
  • Challenge Summary:

The various business units in your organization always have more IT needs then what gets fulfilled because they cannot afford or justify the costs.

How can you improve the productivity of the development teams to try and fulfill more business needs cost effectively?

challenge developer productivity38
Challenge: Developer Productivity
  • More Challenge Details
    • More training
    • Improved development processes
    • More developer specialization
  • Why a Framework Helps
    • Reduced time spent on establishing and building the architecture
    • Reuse of architecture reduces overall development
challenge application architectural governance
Challenge: Application Architectural Governance
  • Challenge Summary:

Many organizations have a person or group responsible for setting rules or policies affecting the architectures of applications.

How can you enforce rules or policies that affect application architecture or development?

challenge application architectural governance40
Challenge: Application Architectural Governance
  • More Challenge Details
    • How to communicate rules and policies
    • Enforcement through reviews and general policing
    • What to do when application slips through the cracks
    • How to keep existing applications compliant with rules and policies
  • Why a Framework Helps
    • Rules and policies can be enforced through updates to framework
    • Existing applications can be upgraded to newest framework to ensure compliance
challenge developer portability
Challenge: Developer Portability
  • Challenge Summary:

Organizations often need to transfer developers from working on one application to another. This can mean significant ramp up time for the developer to understand the application well enough to work on it effectively.

How can you reduce the ramp up time necessary for a developer to switch from working on one application to another?

challenge developer portability42
Challenge: Developer Portability
  • More Challenge Details
    • Sometimes moving developers occurs in “swaps” that take a long time because you then have ramp up dependencies
    • Understanding an application architecture can be time consuming
    • Understanding the business logic versus architecture logic
  • Why a Framework Helps
    • A framework creates more consistencies in architecture requiring less ramp up time
    • Better separation of concerns allows focusing more strictly on business logic
challenge requirement change adaptability
Challenge: Requirement Change Adaptability
  • Challenge Summary:

Changes in the requirements for an application can usually be reasonably handled if they affect business rules or business functionality. But requirement changes that impact the architecture can be extremely difficult to deal with.

How can you reduce the difficulty of dealing with requirement changes impacting an applications architecture?

challenge requirement change adaptability44
Challenge: Requirement Change Adaptability
  • More Challenge Details
    • Difficult to predict the requirement changes
    • Cost of adding flexibility
  • Why a Framework Helps
    • Reusability for different scenarios offers flexibility
    • Flexibility cost is significantly less
agenda45
Agenda
  • About This Talk
  • What is p&p and EDRA
  • Application Architecture Challenges
  • Building an Architecture
  • Creating an Architectural Framework
  • Summary
  • Questions
to download
To Download
  • To download the EDRA source code, documentation, candidate features for future releases, and the EDRI:
    • Go to the EDRA community workspace at http://workspaces.gotdotnet.com/shadowfx
    • Sign in (you will first need to join the workspace)
    • Go to the “Releases” section
  • For a knowledge base on EDRA including frequently asked questions, known issues, etc:
    • Go to the Wiki site at http://channel9.msdn.com/wiki/default.aspx/Channel9.EDRAWiki
summary
Summary
  • Application architecture requires understanding and choosing your challenges
  • Architectural frameworks can help solve challenges
  • EDRA is an application architectural framework that attempts to incorporate several best practices
agenda48
Agenda
  • About This Talk
  • What is p&p and EDRA
  • Application Architecture Challenges
  • Building an Architecture
  • Creating an Architectural Framework
  • Summary
  • Questions
