topics of discussion
Topics of Discussion
  • Conditions of perfect competition
  • Classification of productive inputs
  • Important production relationships (Assume one variable input in this chapter)
  • Assessing short run business costs
  • Economics of short run production decisions

2

conditions for perfect competition
Conditions for Perfect Competition
  • Homogeneous products
    • i.e., Corn grain, mined low-sulfur coal
  • No barriers to entry or exit
    • No regulatory barriers
    • No extremely high fixed costs
  • Large number of sellers
    • How large is large?
  • Perfect information
    • Information cost is relatively small
    • No one firm has access to information that others don’t

Page 86

3

classification of inputs
Classification of Inputs
  • Economists view the production process as one where a variety of inputs are combined to produce a single or multiple outputs
    • Cheese plant example
      • Many inputs: Labor, stainless steel cheese vats, raw milk, energy, starter cultures, cutting and wrapping tables, water, etc.
      • Multiple outputs: Cheese, dry whey, whey protein concentrates are produced by the plant

Pages 86-87

4

classification of inputs1
Classification of Inputs

Land: includes renewable (forests) and non-renewable (minerals) resources

Labor: all owner and hired labor services, excluding management

Capital: Manufactured goods such as fuel, chemicals, tractors and buildings that may have an extended lifetime

Management: Makes production decisions designed to achieve specific economic goals

Pages 86-87

5

classification of inputs2
Classification of Inputs

Inputs can also be classified depending on whether amount of input used changes with production level

Fixed inputs: The amount of input used does not change with output level

Up to a point the size of milking parlor does not change with ↑ milk production/cow or for initial ↑ in herd size

Variable Inputs: The amount of input used changes directly with the level of output

Usually the amount of labor supplied is a variable input (i.e., car assembly plant that ↑ the speed of assembly line to ↑ production/hour

Pages 86-87

6

production function
Production Function

“given the level of”

Output = f(labor|capital, land,

and management)

Start with

one variable

input

Assume remaining inputs

fixed at current levels

  • f(•) is general functional notation
    • Could be any functional form

Page 88

7

slide8

Production Function

  • We can graph the relationship between output and amount of labor used
    • Known as the Total Physical Product (TPP) curve
    • Purely a physical relationship, no economics involved
      • X lbs of fertilizer/acre generates a yield of Y

Page 89

8

slide9

Total Physical Product (TPP) Curve

Maximum Output

Decreasing output

Data from previous table

Variable input

Page 89

9

other physical relationships
Other Physical Relationships
  • The following derivations of the TPP curve play an important role in decision-making
    • Marginal Physical Product (MPP) =
    • Average Physical Product (APP)=

Page 90

10

slide11

Production Function

MPP = Change in output as you

change input use

↑MPP

↓MPP

Page 89

11

slide12

Total Physical Product (TPP) Curve

Data from previous table

4.8

  • MPP = 1.8/4.0 = .45
    • Output ↑ from 3.0 to 4.8 units = 1.8
    • Labor ↑ from 16 to 20 units = 4.0

Output

3

Input

Page 89

12

law of diminishing marginal returns
Law of DiminishingMarginal Returns
  • Pertains to what happens to the MPP with increased use of a single variable input
    • If there are other inputs their level of use is not changed
  • Diminishing Marginal Returns
    • The MPP↑ with initial use of a variable input
    • At some point, MPP reaches a maximum with greater input use
    • Eventually MPP↓ as input use continues to ↑

Page 93

13

slide15

Plotting the MPP Curve

Change from A to B on the production function → a MPP of 0.33

Change in output

associated with a

change in inputs

Data from previous table

Page 91

15

slide16

Plotting the MPP Curve

Q of

Output

MPP = Slope of the line

tangent at a point (A) on the

TPP curve

= ∆Q*/∆I*

A

∆Q*

Q of

Input

0

∆I*

Page 91

16

slide17

Plotting the MPP Curve

Q of

Output

At A, MPP = ∆Q/∆I

= 0/∆I* = 0

A

TPP is at a maximum

when MPP = 0

Q of

Input

0

∆I*

Page 91

17

slide18

Production Function

Average Physical Product (APP) = Amount of output ÷ amount of inputs used

= Output/unit of input used

Page 89

18

slide19

Total Physical Product (TPP) Curve

Data from previous table

Output

APP = .31 (= 8÷26) with labor use = 26

Input

Page 89

19

slide20

Plotting the APP Curve

Output divided

by labor use at B (3 ÷ 16) =0.19

APP = output level

divided by level of input use

Data from previous table

Page 91

20

slide21

Plotting the APP Curve

Q of

Output

B

APP = Q*/I*

= Slope of the line from

the origin to the point

on the TPP curve

At I**, APP is at a maximum,

as line OB is just tangent

to the TPP curve

A

Q*

0

Q of

Input

I*

I**

Page 91

21

slide22

Relationship Between APP and MPP

Q of

Output

APP is at a maximum at

input level where APP = MPP

MPP

APP*

APP

Q of

Input

0

I*

Page 91

22

slide23

Definition of the Three Stages of Production

Stage I: MPP > APP

APP is ↑

APP is increasing in Stage I

Page 91

23

slide24

Definition of the Three Stages of Production

Stage II: MPP < APP

MPP > 0

Page 91

24

slide26

The Three Stages of Production

Q of

Output

MPP

APP

Stage III

Q of

Input

0

Stage II

Stage I

  • Stage II starts at input use where APP is at a maximum (pt A)
  • Stage II ends at input where MPP = 0 (or TPP is at a maximum)

Page 91

26

slide27

The Three Stages of Production

Why are using the amount of input in Stage Iand Stage III of production irrational from the producer’s perspective?

Q of

Output

MPP

APP

Stage III

Q of

Input

0

Stage II

Stage I

Page 91

27

slide28

The Three Stages of Production

Q of

Output

Can increase output by using less inputs: →More output and less cost

MPP

APP

Stage III

Q of

Input

0

Stage II

Stage I

Average productivity is increasing as more inputs are being used so why stop if the average return is greater than cost?

Page 91

28

slide29

The Three Stages of Production

Q of

Output

MPP

APP

Stage III

Q of

Input

0

Stage II

Stage I

The producer’s economic question:

What level of input amount contained in Stage II should the I use to maximize profits?

Page 91

29

economic dimension
Economic Dimension
  • To answer the above question
    • We need to account for the price of the product being produced
    • We also need to account for the cost of the inputs used to produce the above product

30

key cost relationships
Key Cost Relationships
  • The following cost concepts play key roles in determining where in Stage II a producer will want to produce
    • Total Variable Cost (TVC) = the total value of costs that change with the level of output (e.g. energy costs, labor costs, material costs, etc.)
    • Total Fixed Cost (TFC) = total value of costs that do not changed with the level of output (e.g. property taxes)
    • Total Costs (TC) = the sum of total variable and fixed costs
      • TC = TVC + TFC

Page 94-96

31

key cost relationships1
Key Cost Relationships
  • The following cost concepts play key roles in determining where in Stage II a producer will want to produce
    • Marginal Cost (MC) =  total cost of production ÷  output produced as output level changes

=  variable cost of production ÷  output produced given that total fixed costs by definition do not change with output = ∆TC/∆Q = ∆TVC/∆Q

    • Average Variable Cost (AVC) = total variable cost of production ÷ total amount of output produced = TVC/Q

Page 94-96

32

key cost relationships2
Key Cost Relationships
  • The following cost concepts play key roles in determining where in Stage II a producer will want to produce
    • Average Fixed Cost (AFC) = total fixed cost of production ÷ total amount of output produced = TFC/Q
    • Average Total Cost (ATC) = total cost of production ÷ total amount of output produced = TC/Q = AVC + ATC

Page 94-96

33

slide34

From TPP

curve on

page 113

Page 94

34

slide35

Fixed costs are

$100 no matter

the level of

production

Page 94

35

slide36

Total fixed costs (Col. 2)

÷ by total output (Col. 1)

Page 94

36

slide37

Costs that vary

with level of

production

Page 94

37

slide41

[Total Cost (Col. 6) ÷ by Total Output (Col. (1)] or [Avg. Variable Cost + Avg. Fixed Cost]

Page 94

41

slide43

Table 6.3 Cost Relationships

  • MC = min(ATC) and min(AVC)
  • Vertical distance between ATC and AVC = AFC

Cost ($)

AFC

Input Use

Page 95

43

key revenue concepts
Key Revenue Concepts
  • The following revenue concepts play key roles in determining where in Stage II a producer will want to produce
    • Total Revenue (TR) =Multiplication of total amount of output produced by the sale price ($)
    • Average Revenue (AR) = Total revenue ÷ total amount of output produced ($/unit of output) = TR/Q
    • Marginal Revenue (MR) = ∆ total revenue ÷ ∆ total amount of output produced = ∆TR÷ ∆Q
      • How much revenue is generated by one additional unit of output?
      • Under perfect competition, it is the per unit price

44

slide46

Key Revenue Concepts

  • Remember we are assuming perfect competition
    • The firm takes price as given
    • Price (Col. 2) = MR (Col. 7)
    • What is the AR value?

Page 98

46

slide47

Profit Maximization

  • With perfect competition, where would the firm maximize profit in the above example?

47

Page 98

slide49

Profit maximizing

Output where MR=MC

P=MR=AR

$45

11.2

Page 99

49

slide50

Profit Maximization

  • The previous graph indicated that
    • Profit is maximized at 11.2 units of output
    • MR ($45) equals MC ($45) at 11.2 units of output
    • Profit maximizing output occurs between points G and H
    • At 11.2 units of output profit would be $190.40. Let’s do the math….

50

profit at price of 45
Profit at Price of $45?

$

MC

Revenue = $45  11.2 = $504.00

Total cost = $28  11.2 = $313.60

Profit = $504.00 – $313.60 = $190.40

Since P = MR = AR

Average profit = $45 – $28 = $17

Profit = $17  11.2 = $190.40

P =45

ATC

28

AVC

Q

11.2

51

profit at price of 451
Profit at Price of $45?

$

Revenue = $45  11.2 = $504.00

Total cost = $28  11.2 = $313.60

Profit = $504.00 – $313.60 = $190.40

Since P = MR = AR

Average profit = $45 – $28 = $17

Profit = $17  11.2 = $190.40

MC

P =45

$190.40

ATC

28

AVC

Q

11.2

52

slide53

P=MR=AR

  • Zero economic profit if price falls to PBE
  • Firm would only produce output OBE where AR (MR) ≥ ATC

Page 99

53

profit at price of 28
Profit at Price of $28?

Revenue = $28  10.3 = $288.40

Total cost = $28  10.3 = $288.40

Profit = $288.40 – $288.40 = $0

Since P = MR = AR

Average profit = $28 – $28 = $0

Profit = $0  10.3 = $0 (break even)

$

MC

45

ATC

P=28

AVC

Q

10.3

11.2

54

slide55

P=MR=AR

  • Firm can just cover variable cost if price falls to PSD.
  • Firm would shut down if price falls below PSD

Page 99

55

profit at price of 18
Profit at Price of $18?

Revenue = $18  8.6 = $154.80

Total cost = $28  8.6 = $240.80

Profit = $154.80 – $240.80 = –$86

Since P = MR = AR

Average profit = $18 – $28 = –$10

Profit = –$10  8.6 = –$86 (Loss)

$

MC

45

ATC

28

AVC

P=18

Q

8.6

10.3

11.2

56

profit at price of 10
Profit at Price of $10?

Revenue = $10  7.0 = $70.00

Total cost = $30  7.0 = $210.00

Profit = $70.00 – $210.00 = – $140.00

Since P = MR = AR

Average profit = $10 – $30 = –$20

Profit = –$20  7.0 = –$140

Average variable cost = $19

Variable costs = $19  7.0 = $133.00

Revenue – variable costs = –$63

Not covering variable costs!!!!!!

$

MC

45

ATC

30

28

AVC

19

P=10

Q

8.6

10.3

11.2

7.0

57

the firm s supply curve
The Firm’s Supply Curve

Profit Maximizing Output Levels

$

MC

45

ATC

AVC

28

18

10

Q

7.0

8.6

10.3

11.2

58

slide59

The Firm’s Supply Curve

  • We know that so long as P (= MR) > AVC some of the fixed costs can be covered
    • Better economic position then shutting down altogether, WHY?
  • We know that when P (= MR)=MC, the firm maximizes profit
  • Portion of MC curve defined by output level that generates the minimum AVC is referred to as the firm’s supply curve

Page 99

59

the firm s supply curve1
The Firm’s Supply Curve

$

Firm Supply Curve

MC

45

ATC

AVC

28

18

Q

8.6

10.3

11.2

60

key input relationships
Key Input Relationships
  • The following input-related derivations play key roles in determining amount of variable input to use to maximize profits
    • Marginal Value Product (MVP)=

MPP × Product Price

      • MPP → ∆Output ÷ ∆Input Use
      • Product Price → ∆Revenue ÷ ∆Output
      • MVP → ∆Revenue÷ ∆Input Use (Additional output value generated by the last increment in input use)
    • Marginal Input Cost (MIC) = wage rate, rental rate, seed cost, etc.

Page 100

62

slide63

D

MVP=MPP x Output Price

Wage rate is

labor’s MIC

C

E

B

F

G

5

H

I

J

63

Page 101

slide64

Profit maximizing input use rule

    • Use a variable input up to the point where
      • Value received from another unit of input (MVP)
      • Equals cost of another unit of input (MIC)
    • → MVP=MIC

D

C

E

B

F

G

5

I

H

J

Page 101

64

slide65

D

The area below the green lined MVP curve and above the red lined MIC curve represents cumulative net benefit

C

E

B

F

G

5

I

H

J

Page 101

65

slide67

Page 100

Profit are maximized where MVP = MIC

or where MVP =$5 and MIC = $5

67

slide68

=

Marginal net benefit (Col. 5) = MVP (Col. 3) – labor MIC (Col. 4) = Value of additional output from last unit of input net of the cost of that input

Page 100

68

slide69

The cumulative net benefit (Col. 6) of input use

= the sum of successive marginal net benefits (Col. 5)

= the grey area in previous graph.

Page 100

69

slide70

For example…

$25.10 = $9.85 + $15.25

$58.35 = $25.10 + $33.25

Page 100

70

slide71

=

Cumulative net benefit is maximized where MVP=MIC at $5

Page 100

71

slide72

If you stopped at point E on the MVP curve, for example, you would be foregoing all of the potential profit lying to the right of that point up to where MVP=MIC.

D

C

E

B

F

G

5

I

H

J

Page 101

72

slide73

D

If you use labor beyond the point where MVP =MIC, you begin incurring losses as the return to another unit of labor is < $5.00, its per unit cost

C

E

B

F

G

5

I

H

J

Page 101

73

a final thought
A Final Thought

One final relationship needs to be made. The level

of profit-maximizing output (OMAX) in the graph on

page 99 where MR = MC corresponds directly with

the variable input level (LMAX) in the graph on page

101 where MVP = MIC.

Going back to the production function on page 88,

this means that:

OMAX = f(LMAX| capital, land and management)

74

in summary
In Summary…
  • Features of perfect competition
  • Factors of production (Land, Labor, Capital and Management)
  • Key decision rule: Profit maximized at output MR=MC
  • Key decision rule: Profit maximized where MVP=MIC

75
