Theta GDI Upper Housing Oil-Hole 막힘. Sep 25. 2012. KONEC. Problem Description. Theta BSM-GDI #8. 주물막 잔존. Problem Description. Press Pin 과 소재 Hole 치수가 동일함으로 , 공정 진행 후 소재 Burr 밀림 현상 발생 Pin 규격 : Ø9.5 소재경 : Ø9.5. #40 Heat Treatment. #50 Shot Peeing. Press 형판. Burr.
