  1. Inkjet Controller 개발 내역 • Inkjet Controller 개발 경험 • Fujifilm Dimatix. Inc 의 실험용 장비인 DMP-3000, DMP-5001, DMP-5005 에 탑재된 Controller 개발. • DMP-3000 장비는 25대 이상 해외 연구소에 수출됨. 2. Controller Drive 성능 - Inkjet Head Voltage : Up to 140V - Inkjet Head Current : Up to 20mA per DPN Nozzle - Jetting-Frequency : Up to 80KHz - Amp-Frequency : Up to 16MHz - Amp SlewRate : Up to 100V/usec - Drive 방법 : Linear-Waveform Drive

  2. Inkjet Controller 개발 내역 3. Controller 주요 기능 1) Linear Type 의 Jetting-Waveform, Default-Waveform 적용 2) 100KHz 이상의 실시간 Drop-Watcher 기능 구현 3) Linear-encoder 에 대한 Stage Mapping 기능 구현 4) 2um Jetting Resolution, 500mm/sec 기능 구현 5) Sabor-Angle 적용 기능 구현
