Presentation Transcript
slide1

Model-based AdaptiveProduct and Process EngineeringWork Package 2 Evatronix & advICo Use Case:Collaborative IP-based SoC designPilot 3 demonstration and D15

usb phy design challenges in mapper
USB PHY design challenges in MAPPER
  • Needed experts from two different designers’ words: analog and digital
  • The design environment is distributed (2 companies, 3 locations)
  • Problems with interoperability of current design tools (different domains, different file formats)
evatronix and advico workflows
Evatronix and Advico workflows

Each company has well defined own design flow

advICo Design Flow

Component specification

Development

Verification

Product preparation

distributed design and verification between advico and evatronix

Evatronix

Design

Flow

advICo

Design

Flow

Analog and Digital Block integration

Distributed design and verification between Advico and Evatronix

But common USB PHY design flow was a challenge

distributed design and verification between advico and evatronix1
Distributed design and verification between Advico and Evatronix

But common USB PHY design flow was a challenge

pilot 3 usb otg phy design coverage
Pilot 3 USB-OTG-PHY design coverage

Integration &Verification of whole USB PHY design was a scope of the Pilot 3

pilot 3 step 22
Pilot 3 – step 2

Digital waveform view

pilot 3 step 23
Pilot 3 – step 2

Analog waveform view

deliverable d15
Deliverable D15
  • Visual knowledge modeling in the field of Electronic Design Automation
  • Towards distributed collaborative design of electronic systems – USB PHY IP component development
    • Collaborative refinement of design specification through virtual meeting – Pilot 1
    • Distributed design and verification at Evatronix – Pilot 2
    • Distributed design and verification between Evatronix and advICo – Pilot 3
  • Design task patterns
  • Contributions from ethnography
active knowledge models in wp2
Active knowledge models in WP2
  • Evatronix (digital) and advICo (analog) design process
  • enterprise architecture (POP*)
  • joint A/D design flow (USB PHY)
  • pilot definitions
  • design task patterns
  • CVW interface
mapper collaborative infrastructure deployed in wp2
MAPPER collaborative infrastructure deployed in WP2
  • Tool integration with TRMS v. 2
  • CURE workspace
  • Metis modeling
  • GUIs: CURE, CVW
trms development path
TRMS development path

TRMS 1

E-Colleg result

application

ANTS transport mechanism

partial firewall crossing

TRMS 1.1

initial version for MAPPER

application

own transport mechanism

no firewall crossing

2003

TRMS 1.2

developed in MAPPER

applet

own transport mechanism

service-based functionality

2005

TRMS 2

new architecture

application

http/https transport mechanisms

firewall crossing

2006

2007

trms achievements in mapper
TRMS achievements in MAPPER
  • new architecture developed (old terminology kept)
  • transfer based on standard https or http protocols
  • all functionality based on Web services (supporting MAPPER integration)
  • both applet and application versions available
  • deployed in pilots 2 and 3
distributed design and verification of usb phy design at advico and evatronix conclusions
Distributed design and verification of USB PHY design at advICo and Evatronix Conclusions
  • METIS – models of each company design process allow to develop the best common design process for this special (from each company perspective) USB PHY design
  • CURE – As this interface didn’t require any additional effort from end users to setup it, and it can be used almost everywhere where internet access is – this is ideal environment which can integrate various design tools.
  • TRMS – possibility of invoking it just from web browser, implemented security, remote invocation different design tools. All these features support automatisation of our design process. TRMS helps us use our tools more efficiently and accelerates our design work
