Presentation Transcript
course generation example
Course Generation, Example

Learn about “derivation”

Course Generator

Repository

pedagogical aims
Pedagogical Aims
  • : : Represent advanced pedagogical knowledge
  • Joint work with University of Augsburg,Lehrstuhl für Didaktik der Mathematik
  • Formalization of pedagogical strategies based on OECD PISA
    • Focus on mathematical literacy & competencies
      • problem solving,
      • use of mathematical language,
      • mathematical modeling
    • 6 scenarios: LearnNew, Rehearse, Overview, trainCompetency, Workbook, ExamSimulation.
basics of hierarchical task network planning
Basics of Hierarchical Task Network Planning
  • Similar to classical AI planning
    • World state represented byset of atoms
    • Actions correspond to state transitions
  • Differences to classical AI planning
    • What it plans for: Sequence of actions that perform a task network
    • How it plans:
      • Methods decomposetasks
      • down to primitive tasks performed by operators
basics of htn planning
Basics of HTN-Planning
  • Domain description
    • Tasks: Activities to perform
      • Primitive/Compound
    • Operators: Perform primitive tasks

(task, precondition, delete list, add list)

    • Methods: Decompose compound tasks

(task,precondition, subtasks)

    • Axioms: Infer preconditions not asserted in world state
  • Shop2/JShop2: D. Nau et.al., University of Maryland
challenges
Challenges

Learn about “derivation”

Repository

Examples for “derivation”

  • Reasoning about Content
  • Reasoning about User
  • Tool Support
  • Adaptivity++, Interactivity, Service Provision
  • Pedagogical Knowledge

?

?

Course Generator

?

Repository

?

?

Repository

connecting course generation and htn
Connecting Course Generation and HTN
  • Input: Pedagogical Task
      • Pedagogical Objective
      • List of Content Identifiers

(learnNew (def_function def_deriv))

(getAppropriateExercise (def_function))

  • Output: Actions generating structured sequence of LOs

((!startSection def_derivation)

(!insertElement

intro_def_funct)

(!insertElement

def_function)

(!endSection))

course generation by htn example
Course Generation by HTN, Example

(:method (learnConceptLearnNew ?c)

MethodLearnConceptLearnNew

()

((!startSection LearnNew)

(introduce ?c)

(developConcept ?c)

(practice! ?c)

(connect ?c)

(reflect ?c)

(!endSection)))

Goal Task

Preconditions

Subtask

course generation by htn example1
Course Generation by HTN, Example

(:method (learnConceptLearnNew ?c)

MethodLearnConceptLearnNew

()

((!startSection LearnNew)

(introduce ?c)

(developConcept ?c)

(practice! ?c)

(connect ?c)

(reflect ?c)

(!endSection)))

decomposing a task
Decomposing a Task

(:method (introduce ?c)

MethodIntroduce

()

((!startSection (introduce ?c))

(insertMotivation ?c)

(introductionExamplify ?c)

(learnPrerequisitesConceptsShort ?c)

(!endSection)))

  • Optional tasks: Should be achieved, but do not fail

(:method (introduce ?c)

MethodIntroduceFallback

()

())

critical tasks
Critical Tasks
  • Critical tasks: Have to be fulfilled, otherwise fail

(:method (learnConceptProblemBased ?c)

()

((insertProblem! ?c)

(do something …)))

reasoning about user
Reasoning about User

(:method (introductionExamplify ?c)

MethodIntroductionExamplify

((learnerProperty anxiety ?an)(call > ?an 2)

(assignIterator ?element

(call GetElements

((class example)

(property difficulty easy)

(relation for ?c)))))

((!insertElement ?element)))

(:- (learnerProperty ?property ?value)

(same ?value (call queryLM ?property)))

reasoning about content
Reasoning about Content

(:method (introductionExamplify ?c)

MethodIntroductionExamplify

((learnerProperty anxiety ?an)(call > ?an 2)

(assignIterator ?element

(call GetElements

((class example)

(property difficulty easy)

(relation for ?c)))))

((!insertElement ?element)))

(:- (assignIterator ?element (?head . ?tail))

((same ?element ?head)))

(:- (assignIterator ?element (?head . ?tail))

((assignIterator ?element ?tail)))

(id1 id2 id3 …)

course generation by htn example2
Course Generation by HTN, Example

(:method (learnConceptLearnNew ?c)

MethodLearnConceptLearnNew

()

((!startSection LearnNew)

(introduce ?c)

(developConcept ?c)

(practice ?c)

(connect ?c)

(reflect ?c)

(!endSection)

)

)

crucial and fallback methods
Crucial and Fallback Methods

(:method (developConcept ?c)

((learnerProperty competencyLevel ?c ?cl) (call > ?cl 3))

((!startSection (develop ?c))

(!insertElement ?c)

(!endSection))

((learnerProperty competencyLevel ?c ?cl) (call <= ?cl 3)

(learnerProperty motivation ?c ?mo) (call >= ?mo 3))

((!startSection (develop ?c))

(!insertElement ?c)

(explain ?c)

(selectAppropriateExample ?c)

(!endSection))

()

((!startSection (develop ?c))

(!insertElement ?c)

(explain ?c)

(!endSection)))

Crucial methods

Fallback method

course generation by htn example3
Course Generation by HTN, Example

(:method (learnConceptLearnNew ?c)

MethodLearnConceptLearnNew

()

((!startSection LearnNew)

(introduce ?c)

(developConcept ?c)

(practice ?c)

(connect ?c)

(reflect ?c)

(!endSection)

)

)

selecting exercises
Selecting Exercises

(:method (selectAppropriateExercise ?c)

MethodSelectExerciseHighMotivation

((learnerProperty field ?field)

(learnerProperty educationalLevel ?el)

(learnerProperty motivation ?c ?m)

(call >= ?m 3)

(learnerProperty competencyLevel ?c ?cl)

(equivalent (call + 1 ?cl) ?ex_cl)

(assignIterator ?exercise

(call GetElements

((class exercise)

(relation for ?c)

(property learningcontext ?el)

(property competencylevel ?ex_cl)

(property field ?field)))))

((insertElement ?exercise)))

Service Provision!

course generation by htn example4
Course Generation by HTN, Example

(:method (learnConceptLearnNew ?c)

MethodLearnConceptLearnNew

()

((!startSection LearnNew)

(introduce ?c)

(developConcept ?c)

(practice ?c)

(connect ?c)

(reflect ?c)

(!endSection)

)

)

service integration
Service Integration

(:method (reflect ?c)

MethodReflectWithOLM

((learningServiceAvailable OLM))

((!startSection reflect)

(!insertLearningService OLM)

(!endSection))

MethodReflectManual

()

((!startSection reflect)

(!text reflect)

(!endSection)))

(:- (learningServiceAvailable ?tool)

((call checkService ?tool)))

conclusion
Conclusion
  • Using HTN-planning for Course Generation
    • Representing pedagogical knowledge
    • Distributed content, integration of learning services
    • Adaptivity++, interactivity, service provision, sub-goal recognition
  • Efficient:
    • Generation of a course with 15 LO ≈ 700ms
    • with caching ≈ 200ms
thanks
Thanks

www.activemath.org
