  1. WELCOME TO Professional Linear Guide Manufacturer

  2. Overview ABBA Linear Tech Company Profile Competitiveness in Product Global Partnership What Can ABBA Offer

  3. Company Profile Established July, 1999 Capital US$ 6 millon Headquarter Taipei County,Taiwan Plant Area 1st Factory 6,000 m2 2nd Factory 30,000m2 TechnicalOver 20 years of manufacturing high precision ball screw

  4. 1st Factory Company Profile Oil Tank Cover Strip BR Linear Guide

  5. 2nd Factory in 2004 50 Production Lines Company Profile RR Roller Series AR Series Ball-Chain Series Miniature Chain Series

  6. Production Line Company Profile

  7. Technical background ABBA patent Linear Ball rail – BR series Comparision between 4 - row & 2 - row. Comparision between X & O design. Miniature design – BM series ( with cage) Ball Chain design – BC series ( with cage) KR system – AR series Competitiveness in Product

  8. Technique Background

  9. ABBA Patent Miniature USA . Asia Europe BR Series USA . Asia Europe AR Series Released at 2004 ABBA Oil Tank USA . Asia Europe Roller Series Released at 2004 Chain series USA . Asia Europe

  10. Basic shaft Rail System Equal load capacities – in 4 direction Built - in Long Life Lubrication(Patent) High Smooth Running High Running Parallelism Accuracy Integral All-round Sealing 4 Fixed Screw BR series

  11. BR series Basic shaft Rail System BRS = THK’s SR BRH = THK’s HSR

  12. 45º BR series Equal load capacities – in 4 direction

  13. BR series Built-in Long Life lubrication(Patent) Lubrication Part

  14. BR series High smooth running

  15. wheeler wheeler wheeler rail Magnetism seat BR series High Running Parallelism Accuracy 3-Face Rail Grinding Machine

  16. Top seal x2 Side seal x2 End seal x2 BR series Integral All-round Sealing

  17. BR series 4 Fixed Screws 2 1 3 4

  18. Oil Tank & Cover strip Oil tank End stop With screw Cover strip Prevent Dust and Moisture

  19. Contact Friction of 4-row circular arc is Lower than 1 1 3 2-row Gothic 2 2 4 Comparison between 4 & 2 row 4-row circular & 2-row Gothic

  20. Comparison between X & O The ability of Self-adjustment X ( ABBA,THK ) > O ( STAR …) D ( ABBA,THK ) >d ( STAR …) The ability of Self-adjustment ( ABBA,THK ) Is better tha( STAR …)

  21. Comparison between X & O The ability of Self-adjustment

  22. Interchangeable with THK High Smooth & Low Noise Running (Patent) Built-in Long Life Lubrication(Patent) Product – Miniature BM New Feature :

  23. BM07 = THK’s RSH07ZM BM09 = THK’s RSH09ZM BM12 = THK’s SRS12M BM15 = THK’s SRS15M Miniature BM Interchangeable WITH THK

  24. Miniature BM High Smooth & Low Noise Running ( Patent )

  25. Product – Miniature BM Self-lubrication ( Patent )

  26. Interchangeable with THK No Chain-Jam(Patent) High Smooth & Low Noise Running Product – BC Chain series New Feature :

  27. Product – BC Chain series Interchangeable BC = THK’s SHS Compatible BC = THK’s SHS + SSR + SNR + HSR

  28. Product – BC Chain series High Smooth & Low Noise Running ( Patent )

  29. Product – BC Chain series No Chain-Jam

  30. KR System – AR series

  31. Product – RR Roller series

  32. Product – RR Roller series

  33. Global Partnership • Strong Base in Global Business • Well-Known Reputation from Customers in Europe and Asia • Long Term Partnership

  34. Global Partnership Growth 100% Yearly

  35. We Are Your Best Firm Partner !!
