RCC MH COVER SLAB- FRONT VIEW

. . . . . . . . 120cm. 160cm(4no x 40cm). . 15cmThickness. RCCMH COVER SLAB APPEARANCE. . . . . . . . . . . . . . . . . . . . . WITH 12 MM REINFORCEMENT AND 10 X 10 CM GRID. CEMENT CONCRETE 1: 1: 2(1Cement: 1 Coarse Sand : 2 Grade stoneAggragate of 12.5MM nominal size). Reinforcement
