Presentation Transcript
pulse width modulation pwm

Pulse Width Modulation (PWM)

Digital System Design

slide2
เราจะควบคุมความเร็วของมอร์เตอร์ได้อย่างไร?เราจะควบคุมความเร็วของมอร์เตอร์ได้อย่างไร?
pwm on pic16xxx
PWM on PIC16xxx

PWM period = [(PR2) + 1] • 4

• TOSC • (TMR2 prescale value)

Duty cycle =

CCPxCON<5:4>

CCPRxL

80% = 819 = 11 0011 0011
