Presentation Transcript
slide1
Welcome to theNENA NG9-1-1 Tutorialas of March 6, 2011[To see animation, run in PowerPoint presentation mode]
intent of this document
Intent of this Document
  • Present information on NG9-1-1 and the transition to it
  • Provide a high level overview to make you conversant
  • Not a complete picture with all the details
  • Not intended to make anyone an expert in NG9-1-1
the 9 1 1 service process from caller to calltaker and beyond
The 9-1-1 Service Processfrom Caller to Calltaker and Beyond

Caller

Access Provider

Service Provider*

E9-1-1 Network

PSAP CPE

Telecommunicator

  • The Access Provider and the Service Provider are often the
  • same company, but do not have to be.
  • The E9-1-1 Network is usually built to support multiple
  • counties, but may be sold to individual counties.
  • * There does not have to be a Service Provider at all
e9 1 1 components for wireline
E9-1-1 Components (for wireline)

Originating CallsEmergency Service Providers

Other ES Providers

ILECs

CO

Selective

Router

Primary PSAPs

CO

CLECs

Secondary

PSAPs

SR DB

ALI

DBMS

MSAG

Wireline Subscriber Records

add cellular e9 1 1 components
Add Cellular E9-1-1 Components

Originating CallsEmergency Service Providers

Other ES Providers

ILECs

CO

Selective

Router

Primary PSAPs

CO

CLECs

Secondary

PSAPs

MSC

WSPs

SR DB

Cellular

Dynamic

Updates

ALI

PDE

MPC

MSAG

DBMS

Wireline Subscriber Records

or

Cellular Shell Records

Difficult and costly to integrate new call or messaging sources, and the corresponding data needs.

adapt for voip e9 1 1 components
Adapt for VOIP - E9-1-1 Components

Originating CallsEmergency Service Providers

Other ES Providers

ILECs

CO

Selective

Router

Primary PSAPs

CO

CLECs

ESGW

Net

Secondary PSAPs

Internet

VSPs

SR DB

VoIP

Dynamic

Updates

ALI

VPC

Customer Info

DBMS

MSAG

Wireline Subscriber Records

or

VoIP Shell Records

Difficult and costly to integrate new call or messaging sources, and the corresponding data needs.

what s driving ng9 1 1
What’s Driving NG9-1-1
  • Newer Technologies/Services
    • Text, Image, Video, Telematics, Sensors, Subscriber Info
  • Improve Survivability
    • Network Resilience, Virtual PSAPs
  • Improve Interoperability and Information Sharing
  • Need to “Mainstream” 9-1-1 Technology
how ng9 1 1 is different
How NG9-1-1 is Different
  • Technology:
    • Packet Based vs Circuit Switched
  • Functions:
    • Replicates E9-1-1 capabilities
    • Adds new capabilities
    • GIS vs Tabular MSAG
  • No longer a ‘local’ service:
    • Interoperability at county, region, state and national
    • levels
ng9 1 1 myths
NG9-1-1 Myths
  • NG9-1-1 will cause a PSAP to be overwhelmed with more and new data elements from new types of devices
  • NG9-1-1 will improve wireless and nomadic VoIP E9-1-1 accuracy and routing
  • NG9-1-1 will make text-to-9-1-1 available to all callers
  • NG9-1-1 will eliminate prank or harassing calls
ng9 1 1 myths10
NG9-1-1 Myths
  • NG9-1-1 will enable call back to Non-Service Initialized (NSI) wireless handsets
  • NG9-1-1 will save money
  • All connected devices will know and report their own locations without action by the PSAP
  • NG9-1-1 will eliminate all known and unknown issues with E9-1-1 and usher in an era of peace and prosperity
ng9 1 1 reality
NG9-1-1 Reality
  • NG9-1-1 by itself will not enable text to 9-1-1
    • NG9-1-1 is designed to support text when available
    • Standards work is underway in the wireless industry to support future types of text messages
  • NG9-1-1 will not eliminate prank or harassing
  • calls
  • NG9-1-1 will not enable call back to NSI
  • wireless devices
ng9 1 1 reality12
NG9-1-1 Reality
  • NG9-1-1 will enable more - but it may not cost less.
  • In the short term, overall costs will be higher because legacy networks must be maintained while NG9-1-1 systems are being deployed
  • NG9-1-1 defines what information is desired/required from originating networks, but does not define how those networks function internally
e9 1 1 vs ng9 1 1
E9-1-1 vs NG9-1-1
  • Complex analog trunking

and data network

  • Class 5 switch for Selective

Router

  • Translation based control
  • Limited to voice calls
  • Data bandwidth 20 char

(digits)

  • Complex Emergency

Gateway Network for VoIP

  • Custom interfaces for each service type
  • Engineered, managed IP networks (ESInet)
  • IP software selective routing function
  • GIS and database controls
  • Voice, text, video
  • Bandwidth unlimited
  • Direct handling of Internet sourced calls
  • Standard IP interface

for all service types

transition
Transition
  • Two basic ways
    • Conversion from today’s 9-1-1 direct to NENA defined NG9-1-1 using transitional interfaces
    • Using an interim IP system approach, then converting to NG9-1-1
transitional ng9 1 1
Transitional NG9-1-1
  • NG9-1-1 is designed to use IP end-to-end - where mainstream telecommunications is headed
  • To avoid major design changes in the future, the core architecture (NENA `i3’) is oriented to the expected end-state

In the meantime…

  • Gateways in and out will allow current OSP and PSAP interfaces to work during transition
  • Current cellular and VoIP location data processes are accommodated until they convert to IP interactions
baseline ng9 1 1
Baseline NG9-1-1
  • Describes a basic set of features & functions that constitute a NENA Standards-based Next Generation 9-1-1 solution, on the path to an end-state i3 architecture. ..
  • …Must include the functions of today’s E9-1-1 system, replicated in IP protocol and structures as defined by NENA NG9-1-1 standards, including all network and PSAP components of the system …
  • …The basic ability to support non-voice multimedia, such as text and video.
ng9 1 1 basics

NG9-1-1 Basics

NG9-1-1 System

Procedures +

Databases +

i3 Architecture +

ESInet within IP network

terminology
Terminology
  • Emergency Services IP Network (ESInet)
    • A privately managed IP transport network that may be shared by multiple agencies
  • i3 Standard requirements, architecture and functions
    • Including the Emergency Services Routing Proxy (ESRP) and the Emergency Call Routing Function (ECRF).
  • NG9-1-1
    • The set of network elements, software applications, databases, CPE components, and operations & management procedures required to provide Next Generation emergency services.
esinet
ESInet
  • Combination of multiple transports.
  • Can interface with other networks.
  • Coexistence with other ES applications.
esinet concept
ESInet Concept

“I-95”

Poison Control

The blue lanes are for other non-emergency services

N11 / CAD-to-CAD

IP

Network

IP Radio

Law, Fire, EMS

9-1-1

The ESInet is the red lane on this data superhighway.

NG9-1-1 and other emergency services application sets run on the ESInet.

IP network logical segment = ESInet for emergency services call traffic

nena ng9 1 1 system
NENA NG9-1-1 System

GIS source data

Policy Rules and management

Policy Rules DB

Service

Operations Procedures

Geospatial DB

PSAPs

i3 Architecture

Originating Service Providers: Wireline, Wireless, VoIP, etc

PSAPs

ESInet

Other Emergency Entities

ng9 1 1 system
NG9-1-1 System
  • DB Mgmt
  • GIS
  • ALI
  • Policy Routing
  • etc

Functional Entities

NIF

PSTN

LIF

GIS

“ALI”

ESInet

LIS – Location Information Server

HELDETC

LoST

LoST

ECRF – Emergency Call Routing Function

SS7E-MF

CO/SR

SIP

LNG/LSRG - PIF

SS7E-MF

SIP

NG PSAP

SIP

BCF – Border Control Function

CO/SR

SIP

ESRP – Emergency Services Routing Proxy

SIP

LNG/LSRG - PIF

SS7E-MF

IP

SIP

SIP

IP Host

Host Client

CO/SR

TDM

LPG

Legacy PSAP

Internet and Other ESInet’s

The `i3’ specification describes the technical functions and interfaces

nena ng9 1 1 i3 elements simplified diagram with english subtitles
NENA NG9-1-1 – i3 ElementsSimplified Diagram (with English subtitles!)

Inputs

Outputs

Pictures, Video, Graphics

Gateway

9-1-1 Call

Routing

Control

PRF

Policy Routing Function

Gateway

Location Info

Border Control

Subscriber Info

transitional ng9 1 1 simplified
Transitional NG9-1-1(simplified)

Originating CallsEmergency Service Providers

Other ES Providers

ILECs CLECs

ESInets

CO

GW

ESRP Selective

Routing

Function

Primary PSAPs

GW

Mapping

MSC

WSPs

ECRF*

ECRF

Secondary PSAPs

Internet

VSPs

VoIP

Dynamic

Updates

ALI DBMS or LIS

VPC

Customer Info

LoST

Validation

GIS

Wireline Subscriber Records

and

VoIP Shell Records

State or Regional IP Networking, IP software services, GIS and database controls

*Emergency Call Routing Function is national level from Internet

\

calls messages enter
Calls & Messages Enter

Three options from Originating Service Providers:

  • Through the current Selective Routing switch and a Legacy SR Gateway

OSP SR LSRG NG9-1-1

  • Through a Network Gateway

OSP LNG NG9-1-1

  • Direct via IP and SIP protocol

OSP (IP/SIP) NG9-1-1

= IP

calls messages enter28
Calls & Messages Enter
  • Through the current Selective Routing switch and a Legacy SR Gateway

OSP SR LSRG NG9-1-1

but SR has split service:

OSP SR Other Counties still on E9-1-1

LSRG for NG9-1-1 Counties

= IP

data base management
Data Base Management
  • GIS and Geospatial Routing DB
  • Validation
  • Routing Control
  • Policy Rules
  • Data Access rules
  • System Logging
  • Detail Call Records
  • Security
long term ng9 1 1 components simplified
Long term NG9-1-1 Components(simplified)

Originating CallsEmergency Service Providers

Other ES Providers

ILECs CLECs

ESInets

CO

IP Selective

Routing

Function

Primary PSAPs

Mapping

MSC

WSPs

ECRF*

ECRF

Secondary PSAPs

Internet

VSPs

All interfaces to ESInet are IP and include caller location, data

LVF

Validation

LoST

GIS

Local GIS data is ‘published’ to user points

*Emergency Calling Routing Function is national level from Internet

\

the nature of ng9 1 1
The Nature of NG9-1-1
  • Designed to support interoperability
  • Designed with open standards
  • Designed for and enables open competition by component through interface standards
  • Enables a transition to competitive service provider environment
  • Causes a need for regulatory (and legislative) change
ng9 1 1 added features
NG9-1-1 Added Features
  • GIS based routing control
  • Location data transported with the call
  • Additional types of calls and messaging
  • Additional data
  • Virtual PSAP capabilities
  • Added alternate routing options (ex: sensing PSAP status)
  • Direct control of call management [PRF]
  • ?
slide34

Basic Call Flow in NG9-1-1

GIS

Location to Service Translation (LoST)

GIS Data Layers

LIS

ECRF

Device acquires location before a call is made

Location Query to Location InformationServer(LIS)

Location response (civic or geo) – pre-validated

Device (or network) queries ECRF for routing

ECRF provides next hop routing - ESRP 1

Originating Network

ESInet

slide35

Basic Call Flow in NG9-1-1

LoST

LIS

ECRF

ESRP 1

Call is placed

Call is sent to ESRP 1 with the location

LIS is re-queried for any updates to location

Can be ALI

ESRP queries ECRF for next hop

Originating Network

ESInet

slide36

Basic Call Flow in NG9-1-1

LoST

LIS

ECRF

ESRP 1

ESRP 2

“Next Hop” Routing

Call is sent to ESRP 2 with location

LIS is re-queried to update location

ECRF is queried for next hop

Originating Network

ESInet

slide37

Basic Call Flow in NG9-1-1

LoST

Policy

Rules

LIS

PRF

ESRP 1

ESRP 2

“Next Hop” Routing

Policy Rules are evaluated at each hop

Call is sent with location to PSAP

LIS is queried to obtain any updated location information

Originating Network

ESInet

slide38

Basic Call Flow in NG9-1-1

LoST

LIS

PRF

ESRP 1

ESRP 2

Media

Call is Connected to PSAP

Media is established between PSAP and caller

Media can be any combination of Voice, text, data, video, etc…

LIS is queried for any

updated location information

Originating Network

ESInet

ng9 1 1 concepts
NG9-1-1 Concepts
  • Think of your NG9-1-1 system as one element of an interconnected public safety and security system
  • County - Regional – State – National – International
  • Expansion of, and beyond the traditional PSAP
    • Fusion Centers
    • Virtual PSAPs
    • Trauma Centers
    • Poison Control
    • Emergency Operations Centers
ng9 1 1 concepts40
NG9-1-1 Concepts
  • More direct control of system capabilities by 9-1-1 Authorities and PSAP management
    • GIS data updated electronically, to control validation and routing
    • Electronic access to interactive validation data by service providers
    • Routing control and options controlled in databases directly accessible from 9-1-1 Authority and PSAP database terminals, or other authorized remote access points
ng9 1 1 challenges
NG9-1-1 Challenges
  • Costs
    • Most pricing is custom at this stage
    • Double costs during transition
  • Relationship of cost to implementation scope
    • Bigger geography equals better price performance
  • Jurisdictional Impacts
    • If multiple services on ESInet, who is in charge?
    • Shared usage and costs means shared responsibilities
regulatory challenges
Regulatory Challenges
  • Regulations Should Allow:
    • Your NG9-1-1 provider to be different than your current E9-1-1 provider
    • Your NG9-1-1 IP infrastructure provider to be different than your NG9-1-1 services provider
    • Choice of service providers

See:

NENA NG9-1-1 Transition Policy

Implementation Handbook

funding challenges
Funding Challenges
  • PSAP Authorities must be allowed to accrue fundsto build ESInets and NG9-1-1 while still paying for and operating legacy networks
  • Consider different funding sources:
    • IP access providers?
    • Pre-paid wireless?
  • Consider new payment terms for 9-1-1 fees
    • More sources/lower fees?
ng9 1 1 user benefits the light at the end of the tunnel
NG9-1-1 User BenefitsThe light at the end of the tunnel…
  • Text/IM to 9-1-1
  • Files to 9-1-1 , such as photos or video clips
  • Streaming video
  • Telematics and sensor data
  • Nomadic and/or mobile call taker workstations
  • PSAP “on-the-fly” or Virtual PSAP
  • Policy-based alternate routing with new options
  • Additional Policy-based routing for:
    • Language preference of caller
    • Type of technology in use (IM, Sensor, Satellite phone, etc.)
nena standards and documentation
NENA Standards and Documentation
  • What’s done?
    • GIS basics and preparation
    • Intro to NG9-1-1 databases
    • Policy changes for NG9-1-1 (funding recommendations, regulatory and legislative changes, jurisdiction issues)
    • `i3’ architecture specification, Version 1
nena standards and documentation46
NENA Standards and Documentation
  • What’s in progress, re baseline NG9-1-1?
    • Specifics on NG9-1-1 databases and management
    • ESInet Design guidelines
    • System operations, PSAP operations
    • Transition Options and Plans
    • System Management Guidelines
    • SDO convergence over time
  • List and status: www.nena.org, then Programs, NG9-1-1 Project, Standards Status
testing ice and pilots
Testing – ICE and Pilots
  • Industry Collaboration Event
  • ICE Interoperability Testing underway
  • NENA Project sponsored, Vendor managed
  • Eight ICE events planned, three are completed
  • Distributed Pilot testing planned for 2011
  • At least five sites
  • Results: Recommended testing content
nena policy handbook
NENA Policy Handbook
  • State-Level 9-1-1 Leadership and Coordination
  • Funding the NG9-1-1 System
  • Addressing Transitional Regulation/Legislation/Tariff
  • Modifications to Enable Next Generation 9-1-1 Deployment
  • Establishing State-Wide Emergency Services IP Networks
  • (ESInets)
  • Confidentiality, Disclosure and Retention of 9‑1‑1 Call and
  • Other Emergency Information
  • Next Generation 9-1-1 Liability Issues
  • Develop a Strategy and Implement Recommendations
education
Education

NENA/APCO Joint Education Steering Committee

  • Formed late Spring 2010
  • Reviewing identified stakeholder groups
  • Assessing/Identifying requirements for stakeholders that will need to better understand some or all aspects of NG9-1-1
  • Working with NENA EAB and APCO Institute for education delivery
education50
Education

Challenges

  • Must baseline everyone’s level of understanding of NG9-1-1 before more material is introduced
  • Which topics are the most critical?
  • How much content is “too much” ?
  • Identify effective delivery methods for targeted topics and stakeholders
nena ng9 1 1 project
NENA NG9-1-1 Project

Project Lead Team

NENA

Operations Committee

NENA

Technical Committee

ICE Steering Committee

NG

Partner Program

Education Steering Committee

Vendor based

NENA / APCO

NG9-1-1

TransitionCommittee

Contact: Roger Hixson, rhixson@nena.org
