  1. Parallel Tomography Shava Smallen SC99

  2. What are the Computational Challenges? • Quick turnaround time • Resource availability and utilization • Network performance • Coallocation • Transparent execution • Single login • Remote data access • Security

  3. GTOMO • Developed by collaboration of NCMIR researchers and computer scientists to address computational challenges of telescience by leveraging distributed resources • GTOMO is an embarrassingly parallel implementation of tomography.

  4. projections sinograms slices GTOMO Description • projections are preprocessed into sinograms • each sinogram is individually processed into a slice

  5. ptomo driver ptomo writer reader ptomo disk disk GTOMO Architecture Off-line Work queue scheduling Solid lines = data flow dashed lines = control

  6. Grid Enabled • GTOMO is implemented using components of the Globus toolkit • distributed resources • single login • security • Uses AppLeS to achieve performance • coallocation of workstations and immediately available supercomputer nodes

  7. AppLeS = Application Level Scheduling • AppLeS + application = self-scheduling application • scheduling decisions based on • dynamic information • available from Network Weather Service (NWS) • static application and system information • Methodology • select sets of resources • plan possible schedules for each set of feasible resources • predict the performance for each schedule • implement best predicted schedule on selected infrastructure

  8. AppLeS for GTOMO • Resource selection • NCMIR interactive workstations • NPACI supercomputer time • We have developed a scheduler which coallocates program execution over workstations and immediately available supercomputer nodes for an improved execution performance

  9. Resource Selection • Strategy: • submit GTOMO to available workstations • use dynamic information available from the supercomputer’s batch scheduler to determine a job request which will be started immediately • available on Maui Scheduler • Utilizes computational resources available to a typical research lab

  10. Preliminary Experiment Results • Resources • 6 workstations available at Parallel Computation Laboratory (PCL) at UCSD • immediately available nodes on SDSC SP-2 (128 nodes) • Maui scheduler exports the number of immediately available nodes • e.g. 5 nodes available for the next 30 mins 10 nodes available for the next 10 mins

  11. Allocation Strategies/Experiment Setup • 4 strategies compared: • SP2Immed/WS: workstations and immediately available SP-2 nodes • WS: workstations only • SP2Immed: immediately available SP-2 nodes only • SP2Queue(n): traditional batch queue submit using n nodes • experiments performed in production environment • ran experiments in sets, each set contains all strategies • e.g. SP2Immed, SP2Immed/WS, WS, SP2Queue(8) • within a set, experiments ran back-to-back

  12. Experiment Results (8 nodes on SP-2)

  13. Experiment Results (16 nodes on SP-2)

  14. Next Steps • Develop contention model to address network overloading which includes • NWS bandwidth measurements • network capacity information • Expansion of platform • reservations (e.g. GARA scheduled resources) • S3 • On-line tomography (NPACI Telescience Alpha Project)

  15. People • AppLeS: (http://apples.ucsd.edu) • Shava Smallen, Jim Hayes, Fran Berman, Rich Wolski, Walfredo Cirne • NCMIR: (http://www-ncmir.ucsd.edu) • Mark Ellisman, Marty Hadida-Hassan, Jaime Frey • Globus: (http://www.globus.org) • Carl Kesselman, Mei-Hui Su • ssmallen@cs.ucsd.edu
