Presentation Transcript
slide1

◀ TRIM/FORM/SINGULATION SYSTEM ▶

for “J” FORM PKG (SOJ, PLCC, ETC.)

GULL FORM PKG (QFP, SOP, ETC.)

90° FORM PKG (DIP, SIP)

slide2

INDEX

  • General Structure of Servo CAM of System
  • 1.1 Comparison Table of CAM Structure
  • 1.2 Layout of Micron CAM Structure
  • Mechanical D/T/F/S System for “J” Form PKG (PLCC32)
  • 2.1 Specification & Configuration for Trim System
  • 2.2 Top View of System
  • 2.3 Front View of System
  • 2.4 Specification & Configuration for Form/Sing System
  • 2.5 Top View of System
  • 2.6 Front View of System
  • 2.7 Side View of System
slide3

INDEX

  • 3 Mechanical D/T/F/S System for “Gull” Form PKG (QFP100L-14X20)
  • 3.1 Specification & Configuration for Trim System
  • 3.2 Top View of System
  • 3.3 Front View of System
  • 3.4 Specification & Configuration for Form/Sing System
  • 3.5 Top View of System
  • 3.6 Front View of System
  • 3.7 Side View of System
  • Mechanical D/T/F/S System for “90 ” Form PKG (SK-DIP24)
  • 4.1 Specification & Configuration of System
  • 4.2 Top View of System
  • 4.3 Front View of System
slide5

Crank Shaft (Split Type)

Index CAM

Floater CAM

Main Servo Motor for Tool up/down & Index/Floater CAM Operation

Speed Reducer

Connecting Rod

Sub-Servo Motor for Tool Open Height Control during Jamming, Maintenance,Rework

Air Cushion

slide7

Index Rotary

Index Unit

Orientation, Device Check

Vision

On-Loading

Off-Loading

Belt Loading

Floater

Tool (Degate,Dejunk, Debar)

slide8

Orientation, Device Check

Floater

& Index

Vision

Monitor

Touch

Screen

Vision

Tool

Rotary Type Pick & Place

Multi Magazine Stock

Multi Magazine Stock

MGZ Elevator 2 Units

MGZ Elevator 2 Units

Scrap Hood

CAM Servo Motor

slide10

Index Rotary

Index Rotary

Index Unit

Vision

Magazine On-Loading

Sing Tool (2up)

Unit Counter

Chute

Belt Loading

Form Tool (1up)

Floater

Index Buffer Rail

Tube Off-Loading

slide11

Vision

Monitor

Index Buffer Sub-Rail

Touch

Screen

Vision

Rotary Type Pick & Place

Form Tool

Singulation Tool

Lead Frame Flip-Over

CAM Servo Motor for Singulation

Multi MGZ Stock

Scrap Hood

MGZ Elevator 2 Units

Main CAM Servo Motor

slide12

Unit Counter

Chute

Air Blow

Main Servo Motor

Tube Stock &

Auto Tube Change

Floater CAM

Index CAM

slide14

Transfer Pick & Place (1)

Orientation, Reverse L/F, Device Check

Transfer Pick & Place (2)

Buffer

Pick&Place for L/F

Vision

Sing. Tool (2up)

Tray Offloader

Form Tool

Trim Tool

L/F MGZ Onloader

Tray Onloader

Tray Transfer P&P

slide15

Tray Onloading

Orientation, Reverse L/F, Device Check

Monitor

Vision

Tray Offloading

Pick & Place

Mgz Carrier Type Onloading

Synchronized CAM

slide17

L/F Scrap Discharge

Air Blower & Unit Counter

Tube Off Loading

Index CAM

Index

Tube Stock

L/F P&P

MGZ Transfer

Orientation, Reverse L/F, Device Check Sensor

24 SKDIP T/F/S System

slide18

Orientation, Reverse L/F, Device Check

L/F Scrap Discharge

Master Die with Tool

L/F P&P

Monitor

Air Blower & Unit Counter

Main Servo Motor

Tube Stock

Mgz Loader

Press Guide Post

Mgz Elevator

Sub-Servo Motor

Scrap Hood

24 SKDIP T/F/S System
