recovering human body configurations combining segmentation and recognition

Recovering Human Body Configurations: Combining Segmentation and Recognition

Greg Mori, Xiaofeng Ren, and Jitentendra Malik (UC Berkeley)

Alexei A. Efros (Oxford)

the goal
The goal
  • Given an image:
    • Detect a human figure
    • Localize joints and limbs
      • Create a skeleton of their pose
      • Create a segmentation mask of the person
other approaches simple features
Other approaches: Simple features
  • Model people as generalized cylinders (1980’s)
    • Easily implemented bottom up
    • Often use tree to express relations
  • Problems:
    • Cylinders are common
    • Often dependencies between body parts
    • Really need context
other approaches probable pose
Other approaches: Probable pose
  • Often use probable pose
    • Template matching
    • Top down constraints on pose
    • But even highly improbable poses are still possible
other approaches frequent simplifications
Other approaches: Frequent simplifications
  • Nude models
  • Limited poses
  • Background subtraction or limited clutter
arguably the most difficult recognition problem in computer vision
“Arguably the most difficult recognition problem in computer vision”
  • Variation in clothing
  • Variation in limbs
  • Variation in pose
solution islands of saliency
Solution: “Islands of Saliency”
  • Use low-level features that are informative independent of context
  • Based on these islands, one is able to fill in gaps with context
segmentation
Segmentation
  • Combine boundary finder (Martin et al., 2002) with Normalized Cuts (Malik, Belongie, et al., 2001)
    • Groups similar pixels into regions
segmentation regions
Segmentation: Regions
  • 40 regions
  • Most salient parts of body become regions
    • Limbs usually two “half-limbs”
segmentation superpixels
Segmentation: Superpixels
  • 200 region (oversegmentation)
  • Retains virtually all structures in original
  • Still reduces complexity from 400,000 pixels to 200 superpixels
finding limbs
Finding limbs
  • Candidates: all 40 regions
  • Four cues for half-limb detection
    • Contour: Probability of the boundary
      • Average probability of the region’s boundary, as measured by Martin’s boundary finder
    • Shape: How close to a rectangle
      • Area of overlap with reconstructed rectangle,
find limbs
Find limbs
  • Shading
    • Limbs are roughly cylindrical, so should have 3D pop out due to shading
    • Compare Ix-, Ix+, Iy-, Iy+ for region to mean of Ix-, Ix+, Iy-, Iy+ for training set
  • Focus cue
    • Background is often not in focus
    • Cfocus = Ehigh/(a Elow + b)
finding limbs16
Finding limbs
  • Cues are combined by summing
  • Use logistic regression to learn weights (training set of hand-labeled half-limbs)
evaluation cues
Evaluation: Cues

Number of hits

Number of candidates generated

evaluation summary
Evaluation summary
  • Not very good detectors
  • Strength of boundary best cue
  • Combining cues yields better performance
  • On average 4.08 of top 8 candidates produced were hits
  • 89% have at least 3 hits among top 8
    • Motivates search for 3 half-limbs combined with head and torso
finding torsos
Finding torsos
  • Unlike half-limbs, typically several regions
  • Consider all sets of adjacent regions within some range of total sizes
  • Set of cues:
    • Contour
    • Shape
    • Focus
    • (No shading)
finding torsos21
Finding torsos
  • Find orientation of torso
    • Find best matching head
      • Again contour, shape, and focus cues with shape a disk
    • Score for torso, score for head, and score for relative positions of head to torso multiplied to create score for oriented torso
evaluation
Evaluation
  • Success if all four torso points within 60 pixels of ground truth
body building
Body building
  • From 5-7 half-limbs and ~50 candidate oriented torsos form partial configurations consisting of:
    • Each torso
    • Three half limbs assigned each assigned to:
      • One of 8 half limb body parts
      • One of two polarities
  • 2-3 million partial configurations!
enforce constraints
Enforce constraints:
  • Relative widths
      • Foreshortening doesn’t affect width of limbs much
      • Use anthropomorphic data to rule out limbs more than 4 standard deviations wider than expected
  • Length of limbs relative to torso
      • Assume torso not too foreshortened
        • No more than +/- 40% angle with image plane
      • Again, prune limbs more than 4 standard deviations away from mean length, relative to torso
      • Seems to be making some assumptions of probable pose
enforce constraints27
Enforce constraints
  • Adjacency
    • Upper limbs must be adjacent to torso
    • Lower limbs must be adjacent to upper limbs
  • Symmetry in clothing: color histograms must not be overly dissimilar for corresponding segments
    • E.g. right and left upper arms should be similar
    • Makes some small assumptions about variations in clothing
body building slimming down
Body building: slimming down
  • Reduces to ~1000 partial configurations
  • Sorted by linear combination of the torso and the three half-limb scores
    • (This score can be used to improve torso detection)
extending to full limbs
Extending to full limbs
  • Adding additional rectangles evaluated on adjacent superpixels to empty limb joints
  • Want high internal similarity and high dissimilarity to surroundings
summary
Summary
  • “Arguably the most difficult problem in computer vision”
    • Not solved here
  • Method here is appealing:
    • Don’t need to store exemplars
    • Island of saliency approach seems useful in many contexts
    • Use some configural knowledge to make reasonable guesses
    • Good illustration of integrating recognition and segmentation
