Presentation Transcript
prepared by dr sarwer jamal al bajalan m b ch b f i b m s neurology 2014


Prepared by:

Dr. Sarwer Jamal Al-Bajalan

M.B.Ch.B, F.I.B.M.S(Neurology)



Disorders Of The Peripheral Nervous System

  • Introduction and clinical approach
  • Acquired polyneuropathies(PNP)
  • Hereditary neuropathies
  • Mononeuritis Multiplex
  • Mononeuropathies
peripheral neuropathy introductionand clinical approach
Peripheral neuropathy: Introductionandclinical approach

General considerations

  • Peripheral neuropathy or polyneuropathy:

diffuse peripheral nerve lesion, often symmetrical

  • Mononeuropathy—lesion of a single nerve (i.e., median, femoral, or abducens). Often entrapment or trauma
  • Mononeuritis multiplex—focal involvement of two or more individual nerves, often asymmetric
polyneuropathy clinical manifestations
Polyneuropathy:clinical manifestations

Age of onset varies, for example

  • Childhood—CMT
  • Adulthood—Diabetes
  • Older adult—Paraproteinemia

Acuity of onset

  • Acute—AIDP, porphyria, toxic, tick paralysis, diphtheria, vasculitis
  • Chronic—B12 deficiency, paraproteinemia, diabetes, most other causes


  • Motor symptoms—distal weakness predominates in most neuropathies. Difficulty opening jars, tripping over feet
  • Sensory symptoms—may be
          • positive (tingling, burning) or
          • negative (numbness).
  • Autonomic symptoms—orthostatic lightheadedness, gastroparesis, sweating abnormaities, erectile dysfunction, tachycardia
positive sensory symptoms
Positive Sensory symptoms
  • Paresthesia— spontaneous abnormal sensations, which are not unduly painful
  • Dysesthesia— painful paresthesia
  • Allodynia— painful sensation resulting from a nonpainfulstimulus, such as stroking, high sounds
  • Hyperesthesia — increased sensitivity to a stimulus
  • Hyperalgesia— increased sensitivity to a painful stimulus
signs of pnp
Signs of PNP

Large-fiber neuropathy

• Loss of vibration and position sense

• Diminished or absent reflexes

• Positive Romberg sign

• Pseudoathetosis

Small-fiber neuropathy

• Loss of pain and temperature sensation

• Reflexes may be normal.

Autonomic dysfunction

• Miosis

• Orthostatic hypotension (BP supine and erect after 3 minutes)

Cutaneous sensory loss in a stocking-glove distribution

Foot deformities such as pescavus, pesplanus, or hammertoes may indicate a hereditary neuropathy.

Nerve thickening may be seen in CMT, leprosy, Refsumdisease, amyloidosis, or HNPP.

investigations in pnp
Investigations in PNP
  • EMG and ENG
      • Can distinguish polyneuropathy from polyradiculopathyor plexopathy
      • Can identify mononeuropathy and mononeuritis multiplex
      • Can distinguish axonal and demyelinating neuropathies
      • Can identify subclinical sensory or motor involvement
  • Blood tests
      • I) 75 gram 2 hour oral GTT, B12, TSH, SPEP, immunofixation, ESR, renal and liver function tests
      • II) ANA, dsDNA, anti-Ro, anti-La, HIV, Lyme
      • III) Others…
  • CSF examination; (AIDP/CIDP)
  • Nerve biopsy: sural, radial, superficial peroneal(vasculitis)
acquired polyneuropathies
Acquired polyneuropathies
  • Diabetic neuropathies
  • Guillain–Barre syndrome (GBS)
  • Chronic demyelinating polyneuropathy
  • Chronic axonal polyneuropathy
  • Brachial plexopathy
  • Lumbosacral plexopathy
  • Spinal Root Lesions
diabetic neuropathies
Diabetic neuropathies

Commonest cause of neuropathy worldwide.

  • 8% have neuropathy at diagnosis;
  • 50% after 25 years.


  • Diabetes = fasting glucose >126, 2 hr postprandial glucose of 200 mg/dL
  • Impaired fasting glucose = fasting glucose 100–125 mg/dL
  • Impaired glucose tolerance = 2 hr postprandial glucose 140–199 mg/dL

Classification of diabetic neuropathies:

  • Diabetic polyneuropathy
  • Diabetic neuropathic cachexia
  • Diabetic amyotrophy
  • Diabetic cranial neuropathies
  • Diabetic mononeuropathies
diabetic polyneuropathy
Diabetic polyneuropathy
    • Length dependent, painful sensory > motor neuropathy
    • Autonomic dysfunction is common.
  • NCS:
    • Show length-dependent axonal polyneuropathy.
    • May be normal if only small fibers involved.
  • Rx :
    • Foot care,
    • Control of hyperglycemia, and
    • Medications for neuropathic pain (i.e., gabapentin, nortriptyline, duloxetine, pregabain).
diabetic amyotrophy
Diabetic amyotrophy

Clinical manifestations

  • Abrupt onset of severe pain in backs, hips, and thighs followed by weakness and wasting of proximal muscles > distal muscles
  • Usually unilateral, but may progress to be bilateral
  • Associated with weight loss

D Dx: Vasculitis, malignantinfiltration


  • NCS(ENG) usually show distal sensorimotor polyneuropathy
  • Needle EMG shows denervation in proximal lower extremity muscles including paraspinals
  • Consider MRI to rule out structural or infitrativeprocess causing radiculopathy or plexopathy


  • Spontaneous recovery over 1–3 years
  • Methylprednisolone (1g iv tiw x 1, then qweek x 3, then q2 weeks x 4) may speed recovery
  • IVIG reported to be beneficial as well

Diabetic cranial neuropathies

      • Oculomotor(III) palsy — pupil sparing
      • Abducens(VI) palsy

Diabetic mononeuropathies

  • DM patients are prone to entrapment syndromes.
  • Surgery should be considered if motor involvement, but results may not be as good as in nondiabetics.
      • Median at the wris(CTS)
      • Ulnar at the elbow
      • Common peroneal at the fibular neck
guillain barre syndrome gbs
Guillain–Barresyndrome (GBS)

1. Acute inflammatory demyelinating polyradiculoneuropathy (AIDP)


  • The most common cause of acute neuromuscular


  • Annual incidence 1–2 /100,000
  • Two-thirds are preceded by a GI or upper respiratory tract infection (Campylobacter jejuni, CMV, EBV, haemophilusinfluenzae, mycoplasma).

There is a predominantly cell-mediated inflammatory

response directed at the myelin protein of spinal roots,

peripheral and extra-axial cranial nerves, possibly triggered

by molecular mimicry between epitopes found in

the cell walls of some microorganisms and gangliosides

in the Schwann cell and axonal membranes. The resulting

release of inflammatory cytokines blocks nerve conduction

and is followed by a complement-mediated

destruction of the myelin sheath and the associated


clinical features
Clinical features
      • Neurologic symptoms begin 5 days to 3 weeks after antecedent event.
  • Ascending weakness. Proximal weakness may occur as well because of root demyelination
  • Early loss of reflexes
  • Paresthesiascommon. Actual sensory loss is variable.
  • Progressive over days to weeks, nadir by 4 weeks
  • Often associated with back pain
  • Involvement of cranial nerves can cause facial and bulbar weakness.
  • Up to 25% have respiratory involvement requiring mechanical ventilation.
  • Autonomic dysfunction (hypotension, hypertension, cardiac arrhythmia)
diagnostic studies
Diagnostic studies


May be normal early in the course of the disease

  • Prolongation of F-responses,
  • Prolongation of motor latencies, and
  • Prolongation of motor conduction velocities.
  • Conduction block correlates with degree of weakness.


  • Elevation of protein (may be normal first 10 days).
  • Little or no CSF pleocytosis, unless associated with HIV or Lyme.
  • IVIG0.4 g/kg/day x 5 days
  • Plasma exchange (2–5 exchanges, depending on the severity of the disease)
  • No benefit from corticosteroids
  • Supportive measures
      • Follow vital capacity (VC) and negative inspiratory force (NIF
      • Transfer patient to the I CU and consider elective intubation IF:
        • fVC<20 mL/kg (1.5 L for an average adult) or
        • NIF is worse than–30 cm H2O,
      • Do not wait for O2 saturation or PO2 to drop.
      • Swallowing assessment
      • Cardiac monitoring in all patients who are severely affected, at least until they start to improve.
      • Treat neuropathic pain
          • (gabapentin, pregabalin, or tramadol).
          • Avoid tricyclic antidepressants early, which may lower threshold for arrhythmia.
      • DVT prophylaxis
      • Bowel regimen for constipation
      • Physical therapy to prevent contractures and speed recovery of function
  • Overall, 80% of patients recover completely within 3–6 months.
  • Untreated, about 35% of patients have residual weakness, atrophy, hyporeflexia, and facial weakness.
  • Partial recovery followed by relapse occur in <10% of patients.
  • Recurrence after full recovery is 2%.
  • Mortality is 4 %.
  • Poor outcome associated with
      • Older age
      • Preceding diarrheal illness
      • Rapid deterioration and severe weakness
      • Electrically inexcitable nerves and muscle wasting (axonal loss)
other variants of gbs
Other Variants of GBS

2. Acute motor axonal neuropathy (AMAN)

  • Little or no demyelination
  • Often associated with Campylobacter jejuniinfection
  • A subset of patients will recover rapidly

3. Acute motor sensory axonal neuropathy (AMSAN)

  • Little or no demyelination
  • Poorer prognosis than AIDP and AMAN

3. Miller Fisher syndrome

  • Ophthalmoplegia
  • Ataxia
  • Areflexia
  • Associated with GQ1b antibody

4. Acute sensory neuropathy

6. Acute pandysautonomia

chronic polyneuropathy
Chronic polyneuropathy
  • A chronic symmetrical polyneuropathy, evolving over months or years, is the most frequently seen form of neuropathy.
  • In about 30% of patients no cause can be established, even after thorough investigation.
  • These patients usually have a mild axonal neuropathy which, whilst causing unpleasant symptoms, does not lead to motor disability.
  • Therefore, if a patient with what seems to be an idiopathic polyneuropathy progresses to significant disability, further thought needs to be given to finding a specific cause (usually inflammatory or genetic).
chronic demyelinating polyneuropathy
Chronic Demyelinating Polyneuropathy
  • This type of chronic polyneuropathy is often : Hereditary or Immune -mediated (including those caused by abnormal paraproteins).
  • Causes:
      • Hereditary
      • CIDP
      • Lymphoma
      • Osteoclastic myeloma
      • IgMparaproteinaemia
      • Arsenic toxicity
      • Amiodarone toxicity
      • Diphtheria
heriditary demyelinating polyneuropathy
Heriditary Demyelinating Polyneuropathy
  • Many inherited disorders cause demyelinating peripheral neuropathies and one of the best known is Charcot–Marie–Tooth disease (CMT).
  • This neuropathy produces:
      • Distal wasting (‘inverted champagne bottle’ or ‘stork’ legs),
      • Often with pescavus, and
      • Predominantly motor clinical involvement.
      • In 70–80% the cause is duplication of the PMP-22gene on chromosome 17 (autosomal dominant CMT type 1)
      • Similar phenotypes are produced by mutations in other genes with differing modes of inheritance

Pescavus, Inverted champagne bottole, Samll muscle atrophy

chronic inflammatory demyelinating polyradiculopathy cidp
Chronic Inflammatory Demyelinating Polyradiculopathy (CIDP)
  • Presents with a relapsing or progressive generalisedneuropathy.
  • Sensory, motor or autonomic nerves can be involved but the signs are predominantly motor;
  • A variant causes only motor involvement (multifocal motor neuropathy, MMN).
  • RX

Immunosuppressive treatment:

    • Corticosteroids ,
    • Methotrexate or
    • Cyclophosphamide , or
    • Plasma exchange
    • Intravenous immunoglobulin, IVIG
    • MMN is best treated by IVIG.
  • Some 10% of patients with acquired demyelinating polyneuropathy have an abnormal serum paraprotein, sometimes associated with a lymphoproliferativemalignancy.
chronic axonal polyneuropathy
Chronic axonal polyneuropathy
  • This is the most common type of chronic polyneuropathy.
  • Where the cause can be found, it is usually a disorderaffecting axonal metabolism and transport, either acquired (drugs and toxins) or genetically determined
      • Metabolic/endocrine diseases (including diabetes)
      • Alcohol
      • Drugs and toxins
      • Vitamin deficiency
      • Hereditary
      • IgGparaproteinaemia
      • Paraneoplastic
      • Primary amyloidosis
brachial plexopathy
Brachial plexopathy
  • Trauma usually damages either the upper or the lower parts of the brachial plexus, according to the mechanics of the injury.
  • The clinical features depend upon the anatomical site of the damage .
  • Causes of Lower Brachial Plexopathy:
      • Infiltration from breast or apical lung tumours (Pancoasttumour).
      • Therapeutic irradiation
      • Thoracic outlet syndrome: which may be accompanied by circulatory changes in the arm due to subclavianartery compression.
neuralgic amyotrophy
Neuralgic Amyotrophy
  • An acute brachial plexopathy of probable inflammatory origin.
  • In this syndrome, a period of very severe shoulder pain precedes the appearance of a patchy upper brachial plexus lesion.
  • Often affecting the long thoracic nerve which produces winging of the scapula.
  • Recovery occurs over months and is usually complete.
lumbosacral plexopathy
Lumbosacral plexopathy

May be caused by:

  • Neoplastic infiltration or
  • Compression by retroperitoneal haematomasin patients with a coagulopathy.
  • A small vessel vasculopathy can produce a lumbar plexopathy, especially in elderly patients when it may be the presenting feature of;
      • Type 2 diabetes mellitus (‘diabetic amyotrophy’) or
      • A vasculitis.
spinal root lesions
Spinal Root Lesions
  • Compression at or near their spinal exit foramina by prolapsed intervertebral discs or degenerative spinal disease.
  • Infiltration by spinal and paraspinaltumourmasses and
  • Inflammatory or infective processes.
  • The clinical features include:
      • Muscle weakness and wasting and
      • Dermatomalsensory loss with
      • Reflex changes that reflect the pattern of roots involved.
      • Pain in the muscles whose innervating motor roots are involved.
mononeuritis multiplex
Mononeuritis Multiplex
  • Lesions of multiple nerve roots, peripheral nerves or cranial nerves.
  • It is due either to involvement of the vasa nervorum or to malignant infiltration of the nerves.
  • The clinical expression of a very widespread multifocal neuropathy may become confluent so that the clinical picture eventually resembles a polyneuropathy.
  • In this case neurophysiology may be required to identify the multifocal nature of the problem.
causes of mononeuritis multiplex
Causes of Mononeuritis Multiplex

Cancer -related:

  • Chronic graft versus host disease (GVHD)
  • Direct tumor invasion with intraneural spread of Lymphoma
  • B-cell leukemia
  • carcinoid tumor
  • Paraneoplastic – Small cell lung cancer


  • Churg-Strauss syndrome
  • Hypereosinophilia
  • Cryoglobulinemia
  • Hypereosinophilia
  • Atopy-related peripheral neuritis
  • Idiopathic thrombocytopenic purpura


  • Amphetamine angiitis
  • Gasoline sniffing
  • Genetic disorder; Tangier disease.
  • Multiple compression neuropathies.


  • Lyme disease
  • Leprosy
  • Acute viral hepatitis A
  • Hepatitis B
  • Hepatitis C
  • Acute parvovirus B-19 infection
  • Herpes simplex virus infection
  • AIDS and HIV infection


  • Wegener granulomatosis
  • Henoch-Schönleinsyndrome
  • Sjögrensyndrome
  • Behçet’sdisease
  • Temporal (giant cell) arteritis
  • Systemic lupus erythematosus
  • Rheumatoid arthritis
  • Polyarteritisnodosa
  • Scleroderma


  • Diabetes mellitus
  • Amyloidosis[8]
  • Neurosarcoidosis[36, 37]

Facial mononeuropathy (Bell palsy)

  • Weakness: Upper and lower face, inability to close the eye, mouth drawn to the affected side.
  • Patients often describe the face as ‘numb’, but there is no objective somatosensory loss.
  • Loss of direct & consensual corneal reflex on the affected side.
  • Decreased tearing, hyperacusis, and loss of taste to the anterior two thirdsof the tongue may be present.
  • Onset is sudden, usually over hours.

EMG/NCVare rarely necessary to make the diagnosis, but can be used to determine prognosis.

DDx: Herpes zoster, HIV, Lyme, facial tumor, sarcoidosis & neuro-brucellosis.


  • Artificial tears, protective goggles, eye patch at night
  • Prednisone 40–60 mg/d for a week ; speeds recovery if started within 72 hrs.
  • Anti-viralsprobably not beneficial?? ( Acyclovior 400x5 for 10 days)
rt lmn vii palsy
Rt LMN VII palsy


  • some recovery within 3 weeks(85%).
  • Complete recovery(75%)
  • Poor recovery predicted if:
    • Complete paralysis,
    • Older age
    • Comorbidity; DM , HTN
    • Hyperacusis
    • Loss of taste for > 1wk
    • Reto-auricular pain
    • Axonal loss
  • Aberrantre-innervation may occur during recovery, producing unwanted facial movements such as eye closure when the mouth is moved, or ‘crocodile tears’ (tearing during salivation).
hemifacial spasm
Hemifacial spasm
  • Usually presents after middle age with intermittent twitching around one eye, spreading ipsilaterallyover months or years to affect other parts of the facial muscles.
  • The spasms are exacerbated by talking or eating, or when the patient is under stress.
  • The causeis probably an aberrant arterial loop irritating the nerve just outside the pons.
  • The facial nerve should be imaged to exclude a structural lesion, especially in a young patient.
  • Treatment
              • Drug is not effective.
              • Botulinum toxin (repeated every 3 months).
              • Microvascular decompression.
trigeminal nerve lesions
Trigeminal Nerve Lesions
  • Isolated trigeminal sensory neuropathy is rare. It causes unilateral facial sensory loss and is associated in some patients with;
                  • scleroderma,
                  • Sjögren’ssyndrome or
                  • other connective tissue disorder.
  • Trigeminal neuralgiado not have sensory loss on examination unless there have been operative procedures on the nerve.
  • Herpes Zoster (most frequently in the ophthalmic division) and is followed in about one-third of patients by postherpeticneuralgia).
entrapment neuropathy
Entrapment neuropathy
  • Focal compression or entrapment is the usual cause of mononeuropathy.
  • The pressure damages the myelin sheath  slowing NCS.
  • Sustained or severe pressure  axonal loss  loss of sensory AP distal to the site of compression.


  • Acromegaly ,
  • Hypothyroidism ,
  • Pregnancy
  • Diabetes
  • Osteophytes
  • HNPP(hereditary neuropathy with liability to pressure palsies)
            • multiple recurrent entrapment neuropathies,
            • especially at unusual sites
            • autosomal dominant
symptoms and signs in common entrapment n europathies
Symptoms and signs in common Entrapment Neuropathies

Median at wrist (CTS) Ulnar at elbow MeralgaiaParaesthetica


Differential diagnosis by pattern of symptoms

Pattern 1:

  • Symmetrical proximal and distal weakness with sensory loss. (Consider CIDP, vasculitis.)

Pattern 2:

  • Symmetrical distal weakness with sensory loss. (Consider diabetes, drugs and toxins, hereditary neuropathies, amyloidosis, paraproteinemia.)

Pattern 3:

  • Asymmetric distal weakness and numbness. (Consider vasculiticneuropathy, HNPP, infectious neuropathy, multifocal trauma or entrapment.)

Pattern 4:

  • Asymmetric distal or proximal weakness without sensor loss. (Consider multifocal motor neuropathy, motor neuron disease, inclusion body myositis.)

Pattern 5:

  • Asymmetric proximal and distal weakness with sensory loss. (Consider polyradiculopathy or plexopathy, ma ignantinfiltration, brachial neuritis, HNPP.)

Pattern 6:

  • Symmetric small fiber sensory neuropathy without weakness. (Consider diabetes, Fabry disease, amyloidosis, HIV.)

Pattern 7:

  • Symmetric small and large fiber sensory neuropathy without weakness. (Consider diabetes, drugs, toxins, paraproteinemia.)

Pattern 8:

  • Marked proprioceptive sensory loss. (Consider paraneoplastic, B6 toxicity, Sjogren, HIV.)

Pattern 9:

  • Autonomic predominant. (Consider autoimmune, amyloidosis, diabetes, AIDP.)

Pattern 10:

  • Neuropathy with cranial nerve involvement. (Consider Lyme, HIV, AIDP, sarcoidosis, malignant infiltration, Tangier disease, trichloroethylene toxicity, anti-Gd1b neuropathy.)
