    1. Smart-box Demand Ventilation

    2. What is Smart-box Demand Ventilation Meaning the ventilation is varied depending on what demand there is and probably wont run full speed at any time. Giving energy savings, greater control Options WHAT IS REQUIRED Two Speed, Trickle & Boost (via sensor) Variable speed via Pressure or Temperature Control Competition Nu-aire Ecosmart Vent-Axia Sentinel Flaktwoods - iFan

    3. Demand Ventilation Two Speed Trickle & Boost options

    4. Smart-box PIR Movement Detection Control Fan will run at set low speed and boost to set high speed on movement in room PIR Smart-box PIR 1ph REU control, Stet Motor protection, 24v Transformer, Contactor & PIR Detector Smart-box PIR 3ph RTRDU control, 24V transformer, Contactor, PIR Detector

    5. Smart-box CO2 Carbon Dioxide Control Fan will run at set low speed and boost to set high speed on increase CO2 Levels Smart-box CO2 1ph REU control, Stet Motor protection, 24v Transformer, Contactor & CO2 Detector Smart-box CO2 3ph RTRDU control, 24V transformer, Contactor, CO2 Detector

    6. Smart-box HR1 Humidity Control Fan will run at set low speed and boost to set high speed on increased humidity levels in room Smart-box HR1 1ph REU control, Stet Motor protection, Humidistat Detector Smart-box HR1 3ph RTRDU control, HR1 Humidistat Detector

    7. Trickle & Boost Options PIR Humidistat CO2 Time Clock Timer Thermostat Remote Switch

    8. Demand Ventilation Constant Pressure Constant Temperature

    9. Constant Pressure Systems Smart-box CP 1Ph Made up of REP control & DSG Pressure sensor Smart-box CP 3Ph Made up of PXDM control & DSG Pressure sensor Smart-box CPT 1Ph Made up of REPT control & DSG Pressure sensor & TFR Temp Sensor Smart-box CPT 3Ph Made up of PXDM control & DSG Pressure sensor & TFR Temp Sensor Smart-box CT 1Ph Made up of RET control and TFR Temp control Air Valves BPD 100mm or 125mm, Battery or 12V wired

    10. BPD Air Valve for CP Systems

    11. Selling Points / Advantages Quieter Systems With Smart-box the system is only at max design duty when absolutely necessary. The Noise Levels within the systems are lower because the fan is rarely at full speed. Pure Demand Vent Only ventilates the room when you need it why fully ventilate a room when its not occupied maximum savings possible. Healthy Atmosphere Constant trickle vent, keeps the room fresh when unoccupied, whilst still saving energy, system will boost or ramp to max design duty when triggered by a smart-box sensor. Improved Lifecycle Smart-box enables the fan to run at lower speeds this reduces the maximum load and wear on the motor therefore increasing the overall working life of the fans. Competitive prices compared to Nu-aire / Flaktwoods & Vent-Axia. Put us to the test and see the price savings.

    12. Prices Examples KVK250 Smart-box PIR 1Ph 641.79 Vent-Axia Equiv Price SENT250S/PIR 1064.91 KVKDUO200 Smart-box CP 1PH 1132.57 Vent-Axia Equiv Price SENT200T/CP 1,495.00 Nu-aire Equiv Price ESTCP6 1,815.00 PIR Air Valve BPD100T 91.16 Vent-Axia Equiv (Same Unit) 434184 138.60

    13. Example Quotation

    14. Literature Available

    15. Demand Ventilation Your choice of fan & control option. Just Ask us..
