Presentation Transcript
where is white
Where is WHITE?
  • It’s combination of all colors (all frequencies of light are reflected)
If you add more and more colors of MARKERS, the darker and darker the color will get.
  • But as you add more and more colors of LIGHT, thelighter the result will get!
then what is black
Then what is BLACK?
  • No reflection of color (all frequencies of light are absorbed)
color is due to the way objects reflect light why
Color is due to the way objects reflect light. WHY?
  • The color of an object is not within the object, but in the light which shines upon it
  • Some wavelengths are absorbed and some are reflected
  • What is reflected to our eye is what color we see the object as….
  • Reflects: G
  • Appears: G
  • Reflects: R
  • Appears: R
how do we see color
How do we see color?
  • Our eyes respond to the visible light spectrum
  • We have psychological and physiological responses to light waves of a specific frequency and wavelength impinging upon the eye
the human eye
The Human Eye
  • Retina lined with rods and cones
  • Cones – color sensing (RGB)
  • Rods – light intensity sensing
  • For white light all three cones activated.
interesting fact
  • White light results from the combination of just red, green and blue light! Why?
  • Red, Green, Blue = PRIMARYcolors of light!
  • Magenta, Yellow, Cyan = SECONDARY colors of light!
    • Red + blue = magenta
    • Blue + green = cyan
    • Red + green = yellow
          • Through various combinations of these colors we can get all other colors of light! Simulation:
complementary colors
Complementary Colors
  • Each secondary color can be added to the primary color that is was not composed of to create white light. The matching of colors are called complementary colors.
  • Red + cyan = white
  • Blue + yellow = white
  • Green + magenta = white
mixing paints in art class










Mixing paints in art class
  • Note: The primary and secondary colors of LIGHT are different than mixing paints in art class!
  • Paints appear a certain color because of the colors they reflect/absorb
  • Primary colors of paint (from grade school):
      • Red
      • Yellow
      • Blue
polarization of light
Polarization of Light
  • Due to the unique transverse nature of a light wave, it can be thought of as a transverse wave vibrating in many directions at once if it is unpolarized.
  • A polaroid filter allows us to let only one direction of light through!

What is all this useful for?

    • Sunglasses
    • 3D movies
      • Allows you to see light from only 1 projector with each eye which gives the perception of depth
