Presentation Transcript
chest drains

Chest Drains

By Michael Shackcloth

  • Conduit to remove fluid or air from the pleural or pericardial spaces
  • The fluid may be blood, pus or pleural effusion
  • Allow the lungs and heart to work unrestricted
spaces that need draining following heart surgery
Spaces That Need Draining Following Heart Surgery
  • Valve surgery - Pericardium
  • Bypass graft surgery – Pericardium
    • Left pleural space if opened during LIMA harvest
    • Right pleural space if opened during RIMA harvest
    • Right pleural space often opened during OPCAB to allow heart to move across making grafting easier
spaces that need draining following thoracic surgery
Spaces That Need Draining Following Thoracic Surgery
  • Only a single pleural cavity opened
  • Air and blood may collect in the space
  • Two drains
  • Apical drain – Air
  • Basal drain – Blood
  • Traditionally apical drain is placed anteriorly and basal drain at the back
mechanism of action
Mechanism of Action
  • Fluid or air passes from an area of high pressure to one of a lower pressure
  • An underwater seal is therefore needed to stop air being sucked into the chest via the drain
mechanism of action1
Mechanism of Action
  • Drainage occurs when pleural pressure is positive (unless suction is applied)
  • Fluid within the pleural cavity drains into the water seal
  • Air bubbles through the water seal into the outside world
  • Length of tubing below the fluid level is important. The longer the length the greater the resistance to drainage
  • What does it do?
    • Makes the external pressure negative
  • Air or blood drains more easily out of chest


  • If on to high tissues may get sucked into the drain damaging them
  • If connected but not on similar effect to clamping the drains
does and don ts of chest drains
Does and Don’ts of Chest Drains
  • Do not clamp a functioning drain as this can lead to a tamponade ortension pneumothorax
  • If becomes disconnected, reconnect and ask patient to cough
  • Always keep drain below level of patient
    • If raised above patient the contents may siphon back into the chest
drain removal
Drain Removal
  • Explain to patient what you are going to do and what they have to do
  • Get everything ready
  • Check suture is in place to close drain hole
  • Get patient to practice what is expected of them.
timing of drain removal
Timing of Drain Removal
  • Remember air moves from higher pressures to lowest pressure
  • Pleural pressure always lower than atmospheric pressure so air will move into the pleural space from outside
on expiration
On Expiration
  • Pleural pressures at their highest
    • But still less than atmospheric pressure
  • Difficult to hold breath at full expiration
  • Natural reaction to pain is to take a deep breath in
on inspiration
On Inspiration
  • Easy to hold breath on maximal inspiration
  • Pleural pressure most negative therefore air more likely to move into pleural space
valsalva manoeuvre
Valsalva Manoeuvre
  • Forced expiration against a closed glottis
  • Creates a positive intrapleural pressure
  • Easy for patient to hold
