vibrational normal modes or phonon dispersion relations in crystalline materials
Vibrational Normal Modesor“Phonon” Dispersion Relationsin Crystalline Materials
phonon dispersion relations in crystalline materials
“Phonon” Dispersion Relationsin Crystalline Materials
  • So far, we’ve discussed results for the “Phonon” Dispersion Relationsω(k) (or ω(q)) only in model, 1-dimensional lattices.
  • Now, we’ll have a Brief Overview of the Phonon Dispersion Relationsω(k) in real materials.
  • Both experimental results & some of the past theoretical approaches to obtaining predictions of ω(k) will be discussed.
    • As we’ll see, some past “theories” were quite complicated in the sense that they contained N (N >> 1) parameters which were adjusted to fit experimental data. So, (my opinion)

They were really models & NOT true theories.

    • As already mentioned, the modern approach is to solve the electronic problem first, then calculate the force constants for the lattice vibrational predictions by taking 2nd derivatives of the total electronic ground state energy with respect to the atomic positions.
two part discussion
Two Part Discussion

Part I

  • This will be a general discussion of ω(k) in crystalline solids, followed by the presentation of some representative experimental results for ω(k) (obtained mainly in neutron scattering experiments) for several materials.

Part II

  • This will be a brief survey of variousLattice Dynamics models, which were used in the past to try to understand the experimental results.
    • As we’ll see, some of these models were quite complicatedin the sense that they contained LARGE NUMBERSof adjustable parameters which were fit to experimental data.
    • The modern method is to first solve the electronic problem. Then, the force constants which for the vibrational problem are calculated by taking various 2nd derivatives of the electronic ground state energy with respect to various atomic displacements.
slide4

The Classical Vibrational Normal Mode Problem

(in the Harmonic Approximation)

ALWAYS reduces to solving:

Here, D(q) ≡ The Dynamical Matrix

D(q) ≡ The spatial Fourier Transform of the

“Force Constant” Matrix Φ

q ≡ wave vector, I ≡identity matrix

ω2≡ ω2(q) ≡ vibrational mode eigenvalue

slide5
NOTE!
  • There are, in general, 2 distinct types of vibrational waves (2 possible wave polarizations) in solids:

Longitudinal

  • Compressional: The vibrational amplitude is parallel to the wave propagation direction.

and

Transverse

  • Shear: The vibrational amplitude is perpendicular to the wave propagation direction.
  • For each wave vectork, these 2 vibrational polarizations will give

2 different solutionsforω(k).

slide6

We also know that there are, at least, 2 distinct branches ofω(k)(2 different functions ω(k) for each k)

The Acoustic Branch

  • This branch received it’s name because it contains long wavelength vibrations of the form ω = vsk, where vs is the velocity of sound. Thus, at long wavelengths, it’s ω vs. k relationship is identical to that for ordinary acoustic (sound) waves in a medium like air.

The Optic Branch

Discussed on the next page:

slide7

The Optic Branch

  • This branch is always at much higher frequencies than the acoustic branch. So, in real materials, a probe at optical frequencies is needed to excite these modes.
  • Historically, the term “Optic” came from how these modes were discovered. Consider an ionic crystal in which atom 1 has a positive charge & atom 2 has a negative charge. As we’ve seen, in those modes, these atoms are moving in opposite directions. (So, each unit cell contains an oscillating dipole.) These modes can be excited with optical frequency range electromagnetic radiation.
  • We’ve already seen that the 2 branches have very different vibrational frequencies ω(k).
slide8
So, when discussing the vibrational frequencies ω(k),

it is necessary to distinguish between

Longitudinal & Transverse Modes(Polarizations)

&

At the same time to distinguish between

Acoustic & Optic Modes.

  • So, there are four distinct kinds of modes for ω(k).
  • The terminologies used, with their abbreviations are:

Longitudinal Acoustic Modes LA Modes

Transverse Acoustic Modes TA Modes

Longitudinal Optic Modes LO Modes

Transverse Optic Modes TO Modes

slide9

A Transverse Acoustic Mode for the Diatomic Chain The type of relative motion illustrated here carries over qualitatively to real three-dimensional crystals.

The vibrational amplitude is highly exaggerated!

This figure illustrates the case in which the lattice has

some ionic character, with + & - charges alternating:

slide10

A Transverse Optic Mode for the Diatomic Chain The type of relative motion illustrated here carries over qualitatively to real three-dimensional crystals.

The vibrational amplitude is highly exaggerated!

This figure illustrates the case in which the lattice has

some ionic character, with + & - charges alternating:

slide11

Polarization & Group Velocity

LA Modes

Frequency, 

TA Modes

Wave vector, K

0

(p/a)

A crystal with 2 atoms or more per unit cell

will ALWAYS have BOTH Acoustic & Optic Modes.

If there are n atoms per unit cell in 3 dimensions,

there will ALWAYS be 3 Acoustic Modes & 3n -3 Optic Modes.

Vibrational Group

Velocity:

Acoustic Modes

Speed of Sound:

slide12

Polarization

Lattice Constant, a

yn-1

xn

yn

xn+1

TA & TO

LA & LO

OpticModes

For 2 atoms per unit

cell in 3 d, there are a

total of 6 polarizations

The transverse modes

(TA & TO) are often

doubly degenerate, as

has been assumed in

this illustration.

LO

TO

Acoustic

Modes

LA

Frequency, 

TA

0

p/a

Wave vector, K

slide13

1st Brillouin Zones:For the FCC, BCC, & HCP Lattices

Direct: FCC Reciprocal: BCC

Direct: BCC

Reciprocal: FCC

Direct: HCP

Reciprocal: HCP

(rotated)

1 st brillouin zone of fcc lattice
1st Brillouin Zone of FCC Lattice

Direct LatticeReciprocal Lattice

slide15

MeasuredPhonon Dispersion Relations in Si

(Inelastic, “Cold” Neutron Scattering)

Normal Mode Frequencies(k)

Plotted for kalong high symmetry directions in the 1st BZ.

1st BZ for the

SiLattice

(diamond; FCC, 2 atoms/unit cell)

ω

k

normal modes of silicon
Normal Modes of Silicon

L = Longitudinal, T =Transverse

O =Optic, A =Acoustic

slide17

Theoretical (?)Phonon Dispersion

Relations in GaAs

Normal Mode Frequencies(k)

Plotted for kalong high symmetry directions in the 1st BZ.

1st BZ for the

GaAsLattice

(zincblende; FCC, 2 atoms/unit cell)

ω

k

slide18
For Diamond Structure materials, such as Si, & Zincblende Structure materials, such as GaAs, for each wavevector q, there are

6 branches (modes) to the

“Phonon Dispersion Relations”ω(q)

slide19
For Diamond Structure materials, such as Si, & Zincblende Structure materials, such as GaAs, for each wavevector q, there are

6 branches (modes) to the

“Phonon Dispersion Relations”ω(q)

  • These are:3 Acoustic Branches

1 Longitudinal mode: LA branch or LA mode

+ 2 Transverse modes:TA branches or TA modes

In the acoustic modes, the atoms vibrate

in phase with their neighbors.

slide20
For Diamond Structure materials, such as Si, & Zincblende Structure materials, such as GaAs, for each wavevector q, there are

6 branches (modes) to the

“Phonon Dispersion Relations”ω(q)

  • These are:3 Acoustic Branches

1 Longitudinal mode: LA branch or LA mode

+ 2 Transverse modes:TA branches or TA modes

In the acoustic modes, the atoms vibrate

in phase with their neighbors.

and

3 Optic Branches

1 Longitudinal mode: LO branch or LO mode

+ 2 Transverse modes: TO branches or TO modes

In the optic modes, the atoms vibrate

out of phase with their neighbors.

slide21

MeasuredPhonon Dispersion Relations inFCC Metals

(Inelastic, “Cold” Neutron Scattering)

Pb

1st BZ for the

FCCLattice

Cu

slide22

MeasuredPhonon Dispersion Relations inFCC Metals

(Inelastic X-Ray Scattering)

Al

Unit Cell for

the FCC

Lattice

1st BZ for the

FCCLattice

slide23

Measured Phonon Dispersion Relations for C in the

Diamond Structure (Inelastic X-Ray Scattering)

1st BZ for the

DiamondLattice

slide24

Measured Phonon Dispersion Relations for Ge in the

Diamond Structure (Inelastic “Cold” Neutron Scattering)

1st BZ for the

DiamondLattice

L

slide25

MeasuredPhonon Dispersion Relations for KBr

in the NaCl Structure (FCC, 1 Na & 1 Cl in each unit cell)

(Inelastic, “Cold” Neutron Scattering)

1st BZ for the

DiamondLattice

L

slide26

Measured & CalculatedPhonon Dispersion Relations

for Zr in the BCC Structure(Inelastic, “Cold” Neutron Scattering)

Data Points, 2 Different Theories: Solid & Dashed Curves)

1st BZ for the

BCCLattice

slide27
Models for Normal Modes ω(k)in 3 Dimensions Outline of Calculations withNewton’s 2nd Law Equations of Motion

Assuming the Harmonic Approximation

(r) Interatomic Potential

s Displacements from Equilibrium

In the harmonic approximation, expandin a

Taylor’s series of displacements s aboutthe

equilibrium positions.Cut off the series at the

term that is quadratic in the displacements.

The following illustrates this procedure:

nth unit cell

N unit cells, each with n atoms means that there are

3Nn Coupled Newton’s 2nd Law Equations of Motion

lattice dynamics in 3 dimensions outline calculations of k in the harmonic approximation
Lattice Dynamics in 3 Dimensions - Outline Calculations of ω(k) in the Harmonic Approximation

(r) Interatomic Potential

s Displacements from Equilibrium

Expand  in a Taylor’s series in displacements s about equilibrium. Keep only up to quadratic terms:

nth unit cell

Hamiltonian in the Harmonic Approx.

 “Force Constant” Matrix

Analogous to 1 d

F = -(d/dx)

Resulting Newton’s 2nd LawEquation of Motion

N unit cells, each with n atoms means that there are

3Nn Coupled Newton’s 2nd Law Equations of Motion

force constant matrix properties
Force Constant Matrix Properties

Analogous to the 1d

Harmonic Oscillator

Analogous to the 1 d

Spring Constant

Schematic view

of the lattice.

Various symmetries of the

Force Constant Matrix

formally solve the equations of motion use a spatial fourier series approach
Formally Solve the Equations of Motion – Use a Spatial Fourier Series Approach

After some work, the equations of motion become:

slide31
So, the mathematics of

All ofFORMAL Lattice Dynamics can

be summarizedas finding solutions to

  • The remainder is the use of various models & theories for the “force constants” which enter the force constant matrix Ф & thus the dynamical matrix D.
slide32
There are many different models & theorieswhich were designed to determine the force constants which enter the dynamical matrix D. These can broadly be divided into 4 groups:

1.Force Constant Models

2.Shell Models

3.Bond Models

4.Bond Charge Models

  • Within each group, there are MANYvariations on these models!
  • Going down the list: The models get more complex & (in my opinion) harder to understand in terms of the physics behind them.
slide33
Common Features of All Models

(or Theories):

1. All model the ion-ion interactions with some parameters in the force constant matrix .

2.All find these parameters by fitting to various experimental quantities.

A few of the many quantities used to do the fitting are:

Bulk Modulus; Shear Modulus; BZ center LO, TO, LA, & TA frequencies; BZ edge LO, TO, LA, TA frequencie

+ Many Others

Since the goal was to explain neutron scattering data, people tried to use non-neutron scattering data to fit the parameters.

3. All used thefitted parameters in the matrix  to compare to neutron scattering data & to predict

results of neutron scattering experiments.

force constant models
Force Constant Models
  • These models are the crudest approach taken & the closest in spirit & actual calculationsto the 1d models we discussed.
  • They model the force constant matrix with as few parameters as possible & fit to data mentioned.
  • Assumption:The atoms (the ion core + valence electrons) are HARD SPHERES, coupled by “springs”, characterized by spring constants (~ like the 1d models)
  • They include short range forces only. But have no Coulomb forces!
  • There are various types of “springs”:

1st, 2nd, 3rd, 4th, 5th, … neighbor coupling!!

  • The spring forces have directional dependences, with

different spring constants for

coupling in different directions.

slide35
The “best” force constant models require 12 to 20DIFFERENTforce constants per material!

A Rhetorical Question:

Is this physically reasonable & satisfying?

  • Such models give good (q)for the

Group IV covalent solids:

C (diamond), Si, Ge, α-Sn

  • But, they FAIL for many covalent & ionic compounds, such as

The III-V & II-VI materials, GaAs, CdTe, etc.

  • This happens because

Coulomb (ionic) forces are ignored!

  • Also, the bonds in these compounds are partially ionic (there is a charge separation).
slide36
A Rhetorical Question!!

Is a 15 to 20 adjustable parameter “theory”

REALLY A THEORY?

  • A quote in several references:

“The parameters are not easily understood from a physical point of view.”

(In my opinion, this is putting it mildly!)

  • Often, these models need up to

5th & 6th neighbor (or higher)

force constants!

slide37
A physically realistic qualitative expectation for relative size of the force constants connecting neighbors at various distances is:

The force constant size should decrease as the distance increases.

  • However, it’s been found that, in order to get a good fit to data, some of these models require instead that the size of some force constants must increase with increasing distance!! For example:

Φ4nn > Φ1nn

& other, absurd, completely unphysical results!

slide38
In addition, no matter how many force constants are assumed, these models cannot explain a lot of data!
    • For example, the flattening of TAnear the BZ edges.
  • Often, these models were found to work ok for purely covalent solids like

C (diamond), Si, Ge,…

but to do a poor job on ionic compounds in which Coulomb Effects are important!

  • To deal with these problems, “better” theories or models were introduced. One such group of models is called

The Shell Models

shell models
Shell Models
  • The force constant models all assume “hard sphere” atoms(ion core + valence electrons). From our discussion of bonding & from electronic properties studies, we know that this is a

Very BAD assumption for covalently bonded solids as well as for many other solid types!

  • Our knowledge of bonding & electronic properties tells that:

The valence electrons are NOTrigidly attached to the ions!

The Main Idea of the Shell Model:

Each atom is modeled as a rigid ion core plus an “independent” valence electron shell.

Also, the valence electron shell AND the ion core can move.

That is, the Atoms are Deformable!

slide40
So, in the extensions of the force constant models to the Shell Models,

the atoms are deformable!

That is,

The ions & valence electron shells are all moving.

  • Also, Coulomb Interactions are included by putting charges on the shells & the ion cores.
  • In these models, the atomic displacements induce dipole moments on the atoms.

So, there are dipole-dipole interactions between unit cells as well as force constants to couple the cells.

slide41
Best Shell Model results for (q)
  • Ge -A good fit to neutron data is found with only 5 parameters!
  • GaAs & other Compounds -

A good fit to neutron data is found with

~ 10 - 12 parameters.

  • That is, the combined force constant shell model doesn’t do much better than pure force constant models!

Physics Criticisms

1. The valence electrons in covalent materials are NOT in the shells around the ion cores!

2. The valence electrons in these materials ARE in the covalent bonds between the cores!

3. The fitting parameters are ~unphysical & have limited use for modeling properties other than (q).

slide42
Other Physics Criticisms
  • These models make an artificial divisionof valence electrons between atoms which are covalently bonded together.
  • Actually, these valence electrons are shared in the covalent bonds!
  • So, people introduced “better” theories or models, such as the Bond Models.
slide43

Bond Models

  • In covalent materials, the valence electrons are in the covalent bonds between the atoms & along the directions from an atom’s near neighbors.
  • Bond models: Extend the “Valence Force Field” Method to covalent solids.
  • Valence Force Field Method (VFFM):
  • Used in theoretical molecular chemistry to explain vibrational properties of covalent molecules.
  • In this model, the vibrations are analyzed in terms of “valence forces” for bond stretching & bending.
slide44
VFFM Advantages:
  • The force constants for bond stretching & bending are ~ characteristic of particular bonds & are transferable from one molecule to another, which contains same bond (e.g. the force constants for a C-C bond are ~ the same no matter what solid it is in!

Bond Models:

  • The force constants are ~ the same for an A-B bond in a solid as they are in molecules.
slide45
Extension of the VFFM to covalent solids, 2 atoms / unit cell.
  • The bond potential energy V is expanded about equilibrium positions for all possible degrees of freedom of bending, stretching, etc. of bond.
  • Expansion stopped at 2nd order in deviations from equilibrium.

Simple harmonic oscillators in all degrees of vibrational freedom!

slide46
Disappointment!
  • Despite the greater physical appeal & (hopefully) the better physical realism of such models, to get good fits to ω(q)(neutron scattering data), the bond models need ~ a similar number of parameters as the shell models!

So, after all the work on the Bond Models, it turns out that there is no real advantage of them over the shell models!

slide47
The Keating Model ≡ The VFFM with 2 or 3 parameters + a charge parameter.
  • Good for elastic properties at long wavelengths (later).
  • BAD for frequencies!

Other models & extensions of the VFFM:

5 or 6 parameters

  • Often do well for trends in frequencies & BAD for other vibrational properties (like elastic properties)!
  • So, people introduced “better” theories (models) like the

Bond Charge Models

bond charge models
Bond Charge Models
  • The most difficult part of modeling the force constant matrix is accurately including the long-range (Coulomb) electron-ion interaction.
  • The Shell Models + charges: Attempts to simulate this. However, fails to account for dielectric screening. Also, for covalent bonds, charge is not on atoms, but between them!
  • The Bond Models: Account for covalent bonding, but neglects Coulomb screening.
slide49
Review of Screening:
  • Look at a specific ion at origin.
  • Let the Coulomb interaction with one electron

 Vo(r).

  • But, the presence of other electrons reduces this:
  • The presence of all other charges (ions & electrons) near ion of interest causes effective interaction to be reduced.
  • It is shown in EM courses that the true potential is of form

V(r)  Vo(r)exp(-r/ro)

  • Usually, this is simulated in simpler way:

V(r)  Vo(r)/ε

Here, ε =dielectric constant

slide50
Screening in classical E&M:

V(r)  Vo(r)/ε

ε = dielectric constant:

Really, ε = ε(q,ω) but neglect this.

  • This is too simple to work well for vibrational

spectra! Reason: the implicit assumption is that

valence electrons are “free” , except for Coulomb

interactions with ion of interest.

  • We could treat Coulomb effects (ion with charge Ze) by

V(r)  -(Ze2)/(εr),

but this is too crude.

  • Instead, localize some of valence electrons on the bonds, so that some screen in this way & others don’t.
slide51
Bond Charge Model
  • A portion of valence electron charge is localized on bonds (between atoms).
  • Another portion is “free” & contributes to screening.
  • The portion which contributes to screening is an empirical, adjustable parameter.

NOTE!

  • This is a model! Don’t it take too seriously or literally. It is designed to simulate actual effects. It’s physical significance is questionable.
slide52
In this model, the valence electrons are divided into two parts:

1. “Free” charge which contributes to screening

2. Localized chargein the bonds between atoms

  • The fraction of the valence electron charge which is localized on bonds is an adjustable parameter,
  • The bond charge fraction Zbis defined by

Zbe  -2e/ε

  • This is the theory definition.

In practice, Zbis an adjustable parameter

slide53
The bond charge fraction:

Zbe  -2e/ε

  • When Zbis determined, often it is found that

Zbe < 1.0e !

  • Don’t take this too seriously!! Remember that

It is a crude MODEL!

  • In addition, there must be spring-like force constants for coupling between the ions.
slide54
Bond Charge Model Results for Si

Zbe  0.35 e (< 1.0e)

  • This actually compares favorably to the Sicharge density calculated by state of the art electronic structure (pseudopotential) codes.
  • It also compares favorably with X-Ray experiments on the Sicharge density.
  • Both show a build-up of  0.4 e per bond betweenSi atoms!
slide55
Bond Charge Model Results for Si

Zbe  0.35 e (< 1.0e)

  • The 4 valence electrons from each atom are divided into

1. Bond Charges localized on each bond

Zbe  0.35 e.

Point charges are assumed. In reality the bond charge is spread out over a volume.

2. “Free” Chargeswhich screen.

Each Si contributes Zbe/2 to the bond charge and (4-2Zb)e to the free charge.

  • In addition, this has to be combined with force constants to couple ions.
slide56
The Bond Charge Modelcombines the “best” of force constant, shell, & bond models!
  • A further refinement:

Adiabatic Bond Charge Model

(ABCM).

  • Allows bond charges to follow motion of ions so that they are not located exactly in middle of bond.
  • Gets good ω(q) for Si & other materials with only 4 parameters!
