Hybrid Propellant Module

Future Assumptions: 2015 and Beyond. Low Earth Orbit (LEO)

ajay
Download Presentation

Hybrid Propellant Module

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

    23. Hybrid Propellant Module Power System Performance Guidelines Power Generation: 3.1 kW required at 100% duty cycle During LEO to Earth-Moon L1 transfer and return Energy Storage: Provide required power during shadow/chemical rocket use Cross-use capability Operating Life: 10 year system lifetime (~ 5 round trips) Preliminary Configuration PV Arrays: Rigid Planar structures Stowed on exterior of HPM Arrays retracted during chemical rocket firing Energy Storage: Flywheel systems 5.1 kWh capacity required Sharing functions with attitude control system

    24. Hybrid Propellant Module Power System RESULTS Technologies selected: Advanced crystalline multi-band gap photovoltaics 47% eff. @ AM0, 135 W/kg @ panel Flywheel energy storage 5.1 kWh capacity, 3.3 kW delivered, 89% DOD Advanced power processing 95% eff., 670 W/kg

    25. Hybrid Propellant Module Power System Technology Requirements my preliminary guesses - will fill out with better info
