  1. MSCUSMC Mobile Facility UnitsOVERVIEWUNCLASSIFIED

  2. Overview • This briefing provides an overview of the MSC Mobile Facility Units.

  3. Capabilities • Provides UHF & VHF Communications. • SHF Communications • PBX Telephone • INMARSAT B • BEST • C-LAN • TVDTS • LST-5 TRIVAC SYSTEM

  4. Systems Integration & Management • Provide design, drawing and engineering support • Equipment rack installation • UHF / VHF Comms. • PBX telephone • C-LAN • TVDTS • LST-5 TRIVAC ANTENNA COMMS

  5. UHF / VHF Equipment • 2 EA URC 200 UHF/VHF Radios • C-10315 Mini-SAS Patch Panel • TA-970 RED Phone • LS-474/U Loudspeaker • AM-3729/SR Amplifier • PDU • 2 EA. KY-58 Crypto • TA-970 Red Phone Located in Helo Control • TA-970 Red Phone Located on Bridge • 2 EA. SB-4124/C Mini Patch Black Panels

  6. C-LAN Equipment Provides Classified Message Delivery • HP Proliant DL-380 Server • PDU • APC 1500 UPS • Black Box 16 Port Modular Switch • WYSE Terminals

  7. PBX Equipment MITEL SX-2000 • Provides connectivity to SHF Timeplex / FCC-100 Pots lines • Provides connectivity to INMARSAT B • Providing 250 Phone Drops to Ship with Voice Mail Capability • 10 Digital Base Stations • 2 SX-1000 Main Control Units located in Mobile Shelter and Secure Comms.

  8. TVDTS Equipment • Provides Digital Television Service Through Seatel Antenna • Installation includes 14 Viewing Stations with 5 60” Plasma Displays

  9. TVDTS Equipment Installation

  10. Team Resources SIM Inc. – Shelter / Racks / HM&E / PBX / C-LAN / UHF – VHF / TVDTS with SEATEL Antenna LST-5 Relocation MITEL – SX-2000 PBX ISS – BEST / C-LAN / U-LAN MILCOM – SHF Unified Radio Services - TVDTS

  11. Shelter POA&M

  12. SIM Site PBX POA&M

  13. Wright PBX POA&M

  14. TVDTS POA&M

  15. URC-200 POA&M

  16. C-LAN POA&M

  17. Equipment Racks, Front View

  18. Equipment Racks, Rear View

  19. SHF Power Control Assy

  20. SHF Waveguide Termination

  21. SHF Waveguide Termination

  22. Workstation Bench

  23. Points of Contact • MSC • Gary Davis, PM3 Program Office, 202-685-5077 • Ken Toy, N62 C4I Systems, 202-685-5317 • Dave Chapman, ISS Project Mgr, 202-685-5055 • Ron Boustedt, ISS LAN, 757-321-9120 • SPAWAR • Dennis Scherf, MSC Rep, 757-558-5321 • Ron Puett, WSC-6 Engineer, 757-558-6857 • Dwayne Hardman, SIM, 757-410-0746

  24. Issues • Still need information on routers being provided by the Marines for SHF installation? • Marines need to provided operators/technicians for training on SX-2000 PBX system from May 10 through May 14th. • When are the Marines going to provided lab-tops 9ea for Mobile Facility Units? • Marines should be providing the ARC-210 UHF/VHF equipment for installation into Mobile Facility Units. • Who is providing LST-5D equipment?

  25. QUESTIONS?
