slide1

TURKEY REPUBLIC

MINISTRY OF ENVIRONMENT AND FORESTRY

TURKISH STATE METEOROLOGICAL SERVICE

DIRECTORY OF METEOROLOGICAL INSTRUMENTS AND CALIBRATION

CALIBRATION

CENTER

KALMER

Calibration Center - Ankara 2010

slide2

Calibration Center

At the Calibration Center: Automated Weather Observing System's sensors that is installed to all around the Türkiye are calibrated by applying the 17025 standards.

CalibrationCenter is accreditedforthecalibrations of tempetature, relativehumuidity, airpressureandwindspeedsensors.

Calibration Center - Ankara 2010

slide3

CALIBRASTION CENTER ORGANIZATIONAL CHART

Calibration Center - Ankara 2010

slide4

DIRECTORY OF METEOROLOGICAL INSTRUMENTS and CALIBRATION

PRECIPITATION

WIND

CalibrationCenteroperatesunder

MeteorologicalInstrumentsandCalibrationDivision.

TEMP&HUM

SOLAR RADIATION

Mr. Nur DOĞAN

Director of MeteorologicalInstruments

andCalibrationDivision

PRESSURE

Calibration Center - Ankara 2010

slide5

QUALITY MANAGER

On behalf of the management: Responsible for the operation of the Calibration Center in accordance with the rules of the 17025 standards.

Mr. Yusuf Ö. CANDEMİR

QUALITY MANAGEMENT PERSONNEL

Calibration Center - Ankara 2010

slide6

CALIBRATION CENTER UNITS

  • InstrumentAcceptance, Registration and Archive,
  • Temperature & Humidity Calibration Laboratory,
  • Pressure Calibration Laboratory,
  • Wind Speed Calibration Laboratory,
  • Radiation Calibration Laboratory,
  • Precipitation Calibration Laboratory.
  • Mr. Tekin SOYLU
  • Seniorchief of theLaboratories

CalibrationCenter - Ankara 2010

slide7

CALIBRATION CENTER

PERSONNEL CHART

Calibration Center - Ankara 2010

slide8

INSTRUMENT ACCEPTANCE & REGISTRATION AND ARCHİVE

Instrumentsacceptedtothe Calibration Center are registeredandrelateddocumentsarearchivedin accordance with the rules of 17025 standards.

Calibration Center - Ankara 2010

slide9

CALIBRATION CENTER

ENVIRONMENTAL CONDITIONS OF THE LABRATORIES

Environmental conditions of theLaboratories are controlled by using precisionair-conditioner. The measured data of temperatureandhumuidity are automatically displayed and stored.

Calibration Center - Ankara 2010

slide10

CALIBRATION CENTER

ENVIRONMENTAL CONDITIONS OF THE LABRATORIES

Devices to control the laboratory environmental conditions:

Fluke Hart Scientific 1620A

Measuring, displaying and recording.

LiebertHiross HPM PrecisionAir conditioner

Calibration Center - Ankara 2010

slide11

TEMPERATURE & HUMIDITY LABORATORY

The thermometer typesto be calibrated:

Liquid glass thermometers,

Resistance thermometers,

Analog output thermometers,

Thermometerswithdisplay.

All typesof relative humidity sensors are calibrated.

Calibration Center - Ankara 2010

slide12

TEMPERATURE & HUMIDITY LABORATORY

Scope of Accreditation

Calibration Center - Ankara 2010

slide13

TEMPERATURE & HUMIDITY LABORATORY

Reference devices for relative humidity calibration:

Thunder Scientific 2500 Humidity Generator.

Operation range: -10˚C / +70˚C

10%RH / 90%RH

Vaisala HMP76

Calibration Center - Ankara 2010

slide14

TEMPERATURE & HUMIDITY LABORATORY

Climate provider forRelative Humidity Calibration:

Weiss SB22 500

Climate Chamber.

Operation Range:

-50˚C / +50˚C

10%RH / 90%RH

Calibration Center - Ankara 2010

slide15

TEMPERATURE & HUMIDITY LABORATORY

Reference devices forTemperature Calibration:

Isotech 909Q Standard Platinum Resistance Thermometer

Hart Scientific 5615 Platinum Resistance Thermometer

Calibration Center - Ankara 2010

slide16

TEMPERATURE & HUMIDITY LABORATORY

Climate provider forTemperature Calibration:

Weiss SB22 500

Climate Chamber.

Operation Range: -50˚C / +50˚C

10%RH / 90%RH

Fluke 7381 Liquid bath.

Operation range:

-80˚C /+110˚C

Calibration Center - Ankara 2010

slide17

TEMPERATURE & HUMIDITY LABORATORY

Secondarydevices forTemperature & Humidity Laboratory:

Fluke PRT measuring unit, Zeno 3200 Data Logger and Fluke 8846A 6 ½ digit multimeter are used to measure the data.

Calibration Center - Ankara 2010

slide18

TEMPERATURE & HUMIDITY LABORATORY

Calibration at The Triple Point of Water (TPW)

and

Ice Point Calibration :

Calibration Center - Ankara 2010

slide19

PRESSURE CALIBRATION LABORATORY

Pressure sensors typesto be calibrated:

Frequency output barometers,

Digital output barometers,

Barometerswith digital display,

Mechanical barometers.

Calibration Center - Ankara 2010

slide20

PRESSURE CALIBRATION LABORATORY

Scope of Accreditation

Calibration Center - Ankara 2010

slide21

PRESSURE CALIBRATION LABORATORY

Reference device for Pressure Calibration:

Parosceintific 785 digiquartz barometer

Calibration Center - Ankara 2010

slide22

PRESSURE CALIBRATION LABORATORY

Climate providers forPressure Calibration:

Fluke PPC4-ui A100K Calibrator.

Dry air are used (Azoth gas).

Pressure Chamber

Calibration Center - Ankara 2010

slide23

PRESSURE CALIBRATION LABORATORY

Secondary devicesof Pressure Laboratory:

Druck DPI 145

Measurement device for frequency output barometer.

Measurementdevice for digital output barometer.

Calibration Center - Ankara 2010

slide24

PRESSURE CALIBRATION LABORATORY

Secondarydevices of the Pressure Laboratory:

Paroscientific 765 digiquartz barometer.

Ruska 6200 barometer.

Calibration Center - Ankara 2010

slide25

WIND SPEED CALIBRATION LABORATORY

WindSpeed sensor typesto be calibrated (Cup, hotwire, ultrasonic, pitot, propeller):

Electronics wind speed sensors,

Mechanical wind speed sensors.

Calibration Center - Ankara 2010

slide26

WIND SPEED CALIBRATION LABORATORY

Scope of Accreditation

Calibration Center - Ankara 2010

slide27

WIND SPEED CALIBRATION LABORATORY

Reference devicesfor Wind Speed Calibration:

Furness Control FCO510 Micromanometer and Pitot tube.

Thies 2D 4.3810.00.340 Ultrasonic wind speed sensor

Calibration Center - Ankara 2010

slide28

WIND SPEED CALIBRATION LABORATORY

Medium provider for Wind Speed Calibration:

Wind Speed Tunnel is the Göttinger type, closed loop and open test area ( 0 – 40 m/s).

Calibration Center - Ankara 2010

slide29

WIND SPEED CALIBRATION LABORATORY

Devicesof the Wind Speed Calibration Laboratory:

Hotwire Testo 435 Wind Speed Sensor.

Druck PTX7517-1 Pressure (600–1100mbar)

PR 5333A Temperature (0-40ºC) sensors.

Calibration Center - Ankara 2010

slide30

WIND SPEED CALIBRATION LABORATORY

Devicesof the Wind Speed Calibration Laboratory:

Vaisala WMS302M and WAA151, ThiesClima 4.3303.22.007, Qualimetrics ECN4738, Siaphandel type, Vector İnst. A100M/HE-1 and Lastem DN002 Wind Speed sensors are used.

Calibration Center - Ankara 2010

slide31

RADIATION CALIBRATION LABORATORY

Pyranometers are calibrated at the Radiation Calibration Laboratory under the constant irradiance and new sensitivity coefficients forthecalibratedsensorsare calculated.

Calibration Center - Ankara 2010

slide32

RADIATION CALIBRATION LABORATORY

Scope of theCalibration

Calibration Center - Ankara 2010

slide33

RADIATION CALIBRATION LABORATORY

Reference device for Pyranometer Calibration:

Kipp&zonen CMP22 Pyranometer

Calibration Center - Ankara 2010

slide34

RADIATION CALIBRATION LABORATORY

Medium provider forPyranometers Calibration:

Kipp&Zonen Calibration Facility for Pyranometers.

Indoor Pyranometer Calibration System under constant irradiance light (500W/m² - 700W/m²).

Calibration Center - Ankara 2010

slide35

RADIATION CALIBRATION LABORATORY

Devicesof the Pyranometers Calibration Laboratory:

Kipp&Zonen CMP21 Pyranometer

Keithley 2000 6 ½ digit multimeter

Calibration Center - Ankara 2010

slide36

PRECIPITATION CALIBRATION LABORATORY

Precipitation (Rain Gauge) sensors typesto be calibrated:

Tipping bucket rain gauges,

Weighing type rain gauges.

Calibration Center - Ankara 2010

slide37

PRECIPITATION CALIBRATION LABORATORY

Scope of calibration

CalibrationCenter - Ankara 2010

slide38

PRECIPITATION CALIBRATION LABORATORY

Reference devices forRain Gauges Calibration:

Mettler Toledo XP4002S

Precision ElectronicBalances

800 gr. / 4100 gr.

Baykon F1 Class Weigths

1 gr / 2 kg

Calibration Center - Ankara 2010

slide39

PRECIPITATION CALIBRATION LABORATORY

Medium provider for Rain Gauges Calibration:

Precipitation simulation is prepared by using the Watson Marlow 520Du peristaltic pump which calculates the necessary amount of water for the desired amount of Rain İntensity.

Calibration Center - Ankara 2010

slide40

PRECIPITATION CALIBRATION LABORATORY

Secondarydevices of the Precipitation Laboratory:

Zeno 3200 Data Logger

Caps and tubeswithdifferent type and dimensions.

Calibration Center - Ankara 2010

slide41

THANK YOU

FOR YOUR INTEREST

Calibration Center - Ankara 2010
