1. Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers Stephen Hines, David Whalley and Gary Tyson Computer Science Dept. Florida State University October 23, 2006

2. Instruction Packing • Store frequently occurring instructions as specified by the compiler in a small, low-power Instruction Register File (IRF) • Allow multiple instruction fetches from the IRF by packing instruction references together • Tightly packed – multiple IRF references • Loosely packed – piggybacks an IRF reference onto an existing instruction • Facilitate parameterization of some instructions using an Immediate Table (IMM) Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

3. insn3 insn4 insn2 insn3 insn2 insn4 imm3 imm3 IRF IMM Instruction Cache insn1 insn1 Execution of IRF Instructions Instruction Fetch Stage First Half of Instruction Decode Stage IF/ID PC packed instruction packed instruction To Instruction Decoder IRWP Executing a Tightly Packed Param4c Instruction Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

4. Outline • Introduction • Improved Promotion to the IRF • Compiler Optimizations • Instruction Selection • Register Re-assignment • Instruction Scheduling • Experimental Evaluation • Conclusions & Future Work Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

5. Improved Promotion to the IRF • Different classes of instructions can consume 1 – 5 slots • More accurately model the benefits of promoting from one class of instruction to another • Original IRF papers did not promote multiple I-type instructions with different default immediate values • addi $3, $3, 4 and addi $3, $3, 1 would not both reside in the IRF, no matter how frequently they occurred Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

6. Mixed Profiling • Static profiling is best for decreasing code size • Dynamic profiling is best for reducing energy consumption • Can simultaneously weight static and dynamic profile data to obtain a mixed result that has both good code compression and reduced energy consumption • Can obtain most of the benefits of individual static/dynamic profiling Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

7. Compiler Optimizations • Instruction Selection • Choose beneficial encodings for increasing redundancy • Register Re-assignment • Attempts to rename registers such that instructions can be accessed via IRF • Instruction Scheduling • Intra-block – focus on reordering instructions so that dense packs are formed (both tight and loose) • Inter-block – attempt to move instructions between blocks to fill up packs ending with branches/jumps • Code duplication • Predication Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

8. 5 5 4 2 1 1 4 4’ 4’ 2 3 3 Intra-block Instruction Scheduling Without Instruction Scheduling With Instruction Scheduling 3 1 2 1 2 4 5 4’ 5 4 5 Instruction Dependence DAG Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

9. 2 3 3’ 4 4’ Code Duplication to Reduce Code Size W • • • X Y 5 c 5’ a b 6 slots is too many to fit in a single packed instruction … Z 1 1 3 4 3’ 4’ but we can duplicate a single instruction … resulting in the ability to pack the remaining 5 slots together. Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

10. 2 3 b 2’ 4 4’ Predication – Forward Branches X • • • Cond Branch a Fall-through Instructions packed after forward branches will only be executed when the branch is not taken Y 1 2 3 4 4 2’ 4’ 4’ Branch taken path Z • • • Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

11. Predication – Backward Branches • • • a b c Instructions packed after backward branches will only be executed when the branch is taken 1 1 2 2 2’ 2’ Branch offset Branch d e f • • • Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

12. Predication Advantages with IRF • IRF facilitates a form of predication for the MIPS – a baseline architecture that traditionally does not support predication • No need to waste instruction encoding space specifying predicate bits for most/all instructions (even ARM traded away general predication for reducing code size with Thumb and Thumb2) • No need to fetch, decode and possibly execute instructions that are annulled after the branch within a pack (reducing energy consumption and execution time) Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

13. Experimental Evaluation • MiBench embedded benchmark suite – 6 categories representing common tasks for various domains • SimpleScalar MIPS/PISA architectural simulator • Out-of-order, single issue embedded machine with 8KB 4-way set associative L1 instruction and data caches and 128-entry bimodal branch predictor • Wattch/Cacti extensions for modeling energy consumption (inactive portions of pipeline only dissipate 10% of normal energy when using cc3 clock gating) • VPO – Very Portable Optimizer targeted for SimpleScalar MIPS/PISA Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

14. Energy Consumption Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

15. Static Code Size Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

16. IRF Promotion with Mixed Profiling Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

17. Conclusions & Future Work • Compiler optimizations targeted specifically for IRF can further reduce energy (12.2%15.8%), code size (16.8%28.8%) and execution time • Unique transformation opportunities exist due to IRF, such as code duplication for code size reduction and predication • As processor designs become more idiosyncratic, it is increasingly important to explore the possibility of evolving existing compiler optimizations • Register targeting and loop unrolling should also be explored with instruction packing • Enhanced parameterization techniques Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

18. Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers

19. Tightly Packed Instruction Format • New opcodes for this T-format of MISA instructions • Supports sequential execution of up to 5 RISA instructions from the IRF • Unnecessary fields are padded with nop • Supports up to 2 parameters replacing instruction slots • Parameters can come from 32-entry IMM • Each IRF entry also retains a default immediate value as well • Branches use these 5 bits for displacements • R-type RISA instructions can use parameter to replace RD field Adapting Compilation Techniques to Enhance the Packing of Instructions into Registers
