Hematology-analyzer

DESCRIPTION

Hematology analyzer is a mini 5-part analyzer with a display of 10.4 TFT touch screen which is useful to the customers who have <br>day-to-day samples in small amounts. This analyzer is compact size and can be operated without external operator. The storage is <br>up to 50000 sample data and the results can include both numerical and graphical. This analyzer can process 60 samples per hour. <br>It has the capability to measure 27 types of parameters as per useru2019s requirement.

Download Presentation

Hematology-analyzer

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

Playing audio...

  1. Hematology analyzer www.labmate.com | info@labmate.com

  2. Overview Hematology analyzer is a mini 5-part analyzer with a display of 10.4 TFT touch screen which is useful to the customers who have day-to- day samples in small amounts. This analyzer is compact size and can be operated without external operator. The storage is up to 50000 sample data and the results can include both numerical and graphical. This analyzer can process 60 samples per hour. It has the capability to measure 27 types of parameters as per user’s requirement. Specifications : Principles Impedance method for RBC and PLT counting Cyanide free reagent for hemoglobin test Flow Cytometry (FCM) + Tri-angle laser scatter method for WBC 5-part differential analysis and WBC counting Parameters 27 parameters: WBC, Lym%, Mon%, Neu%, Bas%, Eos%, Lym# ,Mon#, Neu#, Eos# , Bas#, RBC, HGB, HCT, MCV, MCH, MCHC,RDW-CV, RDW- SD, PLI, MPV, PDW, PCT, LIC%, LIC#, ALY%, ALY# 3 histograms for WBC, RBC and PLT 3 DIFF scatter grams and 1 BASO scatter gram Reagent DIL-C Diluent, LYC-1 LYSE, LYC-2 LYSE, CLE-P

  3. Linearity Range WBC (0.00-300.00)X 10%/L RBC (0.00-8.50)X1012/L HGB (0-250)G/L PLT (0-3000)X 10%/L HCT 0.0-67.0% Repeatability WBC≤2.0% RBC≤1.5% HGB≤1.5% PLT≤4.0%MCV≤1.0% Display 10.4 inch TFT Touch Screen Throughput 60 samples per hour Language English Data Storage Capacity Up to 50,000 results including numeric and graphical Communication LAN port supports HL7 protocol Interface 4 USB Ports, 1LAN port Printout External Laser printer / Inkjet printer, various printout formats and user-defined formats Dimensions (L×W×H) mm 364 x 431x 498 Net Weight 26.5kg Features : -It gives accurate results and compact structure -It contains of strong and durable air pump -It also provided an advantage of 2 types of printing options -They can store up to 50000 results including numerical and graphical -It follows 3 methods to analyze the components in the blood -The user can conveniently view the results in 10.4 inch TFT touch screen -The connection between the computer and the instruments is

  4. supported by 4 USB ports and 1 LAN Applications : Hematology analyzers are used to run tests on blood samples. They are used in the medical field for white blood cell counts, complete blood counts, reticulocyte analysis, and coagulation tests. Labmate Scientific Email: info@labmate.com | Website: www.labmate.com
