Presentation Transcript
slide1

SERVOSTAR 600 PRODUCT ANNOUNCEMENTSSeptember 5 and 6, 2002George Ellis

Web-Cast Training For Best-In-Class Distributors

slide2

SERVOSTAR 600 Announcements

I Product offering

II Documentation

III New features

Web-Cast Training For Best-In-Class Distributors

slide3

SERVOSTAR 600 Announcements

  • I Product offering
    • Safety relay: non-AS vs. -AS options
    • Price list
    • New drive models: 10-30, 40, 70
    • Expanded accessories offering
    • Ordering non-standard firmware
    • Demonstration units
  • II Documentation
  • III New features

Web-Cast Training For Best-In-Class Distributors

slide4

SERVOSTAR 600 Announcements

  • Non-AS vs. -AS versions
    • The safety relay (AS) option of the SERVOSTAR 600 is a hardware safety function that is used in a minority of applications. When the SERVOSTAR 600 was introduced into North America, it was offered only with the -AS option.
    • The -AS option adds cost to the hardware. The non-AS version will be offered in North America as part of a price reduction program.

Web-Cast Training For Best-In-Class Distributors

slide5

SERVOSTAR 600 Announcements

  • Non-AS vs. -AS versions
    • The last digit of the model number indicates -AS option:Examples: -AS model: S60301 -non-AS model: S60300

Web-Cast Training For Best-In-Class Distributors

slide6

SERVOSTAR 600 Announcements

  • Non-AS vs. -AS versions
    • Beginning 9/02, the non-AS version of the SERVOSTAR 600 will be stocked in North America.
    • The AS-option will continue to be available.
    • Starting in 2003, it will not normally be stocked in North America. Delivery is expected to be 8 weeks.

Web-Cast Training For Best-In-Class Distributors

slide7

SERVOSTAR 600 Announcements

  • Non-AS vs. -AS versions
    • We need to inform key customers
      • We will provide a letter explaining the change
      • We need you to provide a list of key customers

Web-Cast Training For Best-In-Class Distributors

slide8

SERVOSTAR 600 Announcements

  • Price list
    • A new price list was released September 3, 2002 as part of QA.
    • Prices of the -AS option units are unchanged.
    • The non-AS versions of the SERVOSTAR 600 are offered at reduced prices.

Web-Cast Training For Best-In-Class Distributors

slide9

SERVOSTAR 600 Announcements

  • New: S610-30 amplifiers
    • Beginning 9/02, we will offer the 10-30 amplifier:
      • Continuous current of 10A RMS
      • Peak current of 30A RMS
      • Size same as 10A SERVOSTAR 600.
    • Consult the 601-620 Installation Manual for details.
    • Example model number (non-AS) S610-3000

Web-Cast Training For Best-In-Class Distributors

slide10

SERVOSTAR 600 Announcements

  • New: S640 and S670
    • The SERVOSTAR 640 (40A/80A, RMS peak/cont.) and 670 (70A/140A) are available as standard products.
    • At the time of this notice, the S640 and S670 drives with the Extended IO card (EI) are not UL Listed and cannot be sold as a unit. This should be resolved shortly.
    • See the 640/670 Installation Manual.

Web-Cast Training For Best-In-Class Distributors

slide11

SERVOSTAR 600 Announcements

  • Accessories
    • The SERVOSTAR 600 accessories stocked in North America have been expanded to include new parts:
      • Filters
      • Chokes
      • Connectors
      • CAN dongle and cable
    • Installation manuals indicate which parts are available in North America.

Web-Cast Training For Best-In-Class Distributors

slide12

SERVOSTAR 600 Announcements

  • Ordering non-standard firmware
    • Customers can specify previously-released versions of firmware for a charge of $75/unit.
    • Customers can download all versions of firmware at no charge.
    • Unless specified, all units are shipped with the latest released version of firmware.

Web-Cast Training For Best-In-Class Distributors

slide13

SERVOSTAR 600 Announcements

  • Demo units
    • Motor and drive
    • Control panel
      • 2 analog inputs
      • 6 digital I/O
    • Extended I/O card
    • 115VAC operation
    • Rugged carry case
    • $1995

Web-Cast Training For Best-In-Class Distributors

slide14

SERVOSTAR 600 Announcements

  • I Product offering
  • II Documentation
    • Manuals program
    • Compensation sets on the web
    • Current-loop tuning wizard
  • III New features

Web-Cast Training For Best-In-Class Distributors

slide15

SERVOSTAR 600 Announcements

  • Manuals
    • Starting 7/02, the European and North American manuals were combined into one manual set.
    • This change allows new functions to be documented and released quickly.
    • These manuals are available on the web.

Web-Cast Training For Best-In-Class Distributors

slide16

SERVOSTAR 600 Announcements

  • Manuals
    • All serial commands are now documented by the Windows HTML file ASCII Command Reference, available on the web.

Web-Cast Training For Best-In-Class Distributors

slide17

3.

Read

1.

Type

2.

Select

Web-Cast Training For Best-In-Class Distributors

slide18

SERVOSTAR 600 Announcements

  • Comps on the web
    • Starting 7/02, we have been listing the most up-to-date comp file on the web.
      • This is a complete listing, but it’s not convenient.
    • Starting 9/02, we will list all published systems that are not comped.
      • This should make it easy to avoid unknowingly selling uncomped systems.
      • Just because it’s in QA, doesn’t make it “published.”

Web-Cast Training For Best-In-Class Distributors

slide19

SERVOSTAR 600 Announcements

  • Current-loop tuning wizard
    • Allows tuning of current loops with no special lab equipment and without locking the rotor
      • In some cases, an inertia wheel is needed
    • Does not provide angle advance settings
    • Can be used to mate the SERVOSTAR 600 and non-standard motors
      • Has been used to mate SERVOSTAR 600 and PMA Motors (distributor took responsibility for cables).

Web-Cast Training For Best-In-Class Distributors

slide20

SERVOSTAR 600 Announcements

  • I Product offering
  • II Documentation
  • III New features
    • Rack-drive panel
    • DeviceNet beta program
    • Graphical Motion Tasking

Web-Cast Training For Best-In-Class Distributors

slide21

SERVOSTAR 600 Announcements

Left

Motor

Right

Motor

Rack

  • Rack Drive Panel
    • Standard after 9/02
    • Two motors, one load
    • Eliminates backlash, easy to control
    • We have good history, few competitors
    • Usually uses large motors and drives

Web-Cast Training For Best-In-Class Distributors

slide22

SERVOSTAR 600 Announcements

  • DeviceNet beta
    • DeviceNet for the S600 has been functioning for several months
    • We have passed almost all of our available software tests
    • Running with PLC
    • Beta period: 9/15/02 - 11/1/02

Web-Cast Training For Best-In-Class Distributors

slide23

SERVOSTAR 600 Announcements

  • Graphical Motion Tasking
    • Expands Motion Tasking
    • Graphical programming environment
    • Beta 8/1/02 - 9/15/02
    • Web cast planned for October

Web-Cast Training For Best-In-Class Distributors

slide24

SERVOSTAR 600 Announcements

Expanded product offering

Improved documentation

Enhanced feature set

Web-Cast Training For Best-In-Class Distributors
