Presentation Transcript
Slide1 l.jpg

Database Security

Kennesaw State University

Overview l.jpg

1) Introduction

2) DB Security Plan

3) Database Access Control

4) DBMS Security: Patching

5) DB Application: SQL injection, Inference Threats

6) Virtual Private Databases

7) Oracle Label Security

8) Inference Threats

9) Encryption

10) Auditing

11) Datawarehouse

12) Security Animations

1 introduction motivation l.jpg
1) Introduction - Motivation

  • “Securing the DB may be the single biggest action an organization can take to protect its assets”

    David C. Knox

    “Effective Oracle Database 10g Security by Design”, McGraw Hill, 2004.

    ISBN 0-07-223130-0

1 introduction scope l.jpg
1) Introduction - Scope

  • Database system security must worry about DB + …

    • Secure Database

    • Secure applications

    • Secure DBMS

    • Secure operating system in relation to database system

    • Secure web server in relation to database system

    • Secure network environment in relation to database system

1 introduction product specific books l.jpg
1) Introduction – Product Specific Books

  • Oracle Advanced Security (previously Advanced Network Option), contains network encryption tools. Depending on the version of Oracle, it is available for no extra cost. It is for the enterprise edition.

  • Best literature for OAS is Oracle Security Handbook by Marlene Theriault and Aaron Newman, McGraw-Hill.

2 db security plan l.jpg
2) DB Security Plan

2 db security plan8 l.jpg
2) DB Security Plan

Which is the most complex program/form to implement?

If a data type is changed in the Customers table, what programs/forms may need modification?

The Orders form accesses how many tables?

The Employees table is accessed by how many programs/forms?

2 db security plan9 l.jpg
2) DB Security Plan

  • DAC Versus MAC

  • Access Matrix Model: Harrison-Ruzzo-Ullman

    • Authorized state: Q = (S, O, A)

    • Conditions (dependent)

      • Data

      • Time

      • Context

      • History

Subjects Objects

2 db security plan document user administration l.jpg
2) DB Security Plan - Document User Administration

  • Part of the administration process

  • Reasons to document:

    • Provide a paper trail

    • Ensure administration consistency

  • What to document:

    • Administration policies, staff and management

    • Security procedures

    • Procedure implementation scripts or programs

    • Predefined roles description

3 db access control l.jpg
3) DB Access Control

  • Default Users and Passwords

    • Users, Passwords

      • Default users/passwords

        • sys, system accounts – privileged, change default password

        • Sa (MS-SQL Server)

        • scott account – well-known account/password, change it

        • general password policies (length, domain, changing, protection)

  • People Having too many privileges

    • Privileges, Roles, Grant/Revoke

      • Privileges

        • System - actions

        • Objects – data

      • Roles (pre-defined and user-defined role)

        • Collections of system privileges (example: DBA role)

      • Grant / Revoke

        • Giving (removing ) privileges or roles to (from) users

3 db access control default passwords l.jpg
3) DB Access Control - Default Passwords

  • Easiest way to log into an Oracle database is to use a default account with a known password [Finnigin]


  • This site has scripts that will identify all default users and lets you know if they still have their default passwords. You may download these scripts.

3 db access control password cracking l.jpg
3) DB Access Control - Password Cracking

  • At there are tools that you can download to crack the passwords. You need to verify this against the DB, because you can be sure that the hacker has these tools.

3 db access control find all privileges l.jpg
3) DB Access Control - Find all Privileges


  • Script to find which privileges have been granted to a particular user. This scripts lists ROLES, SYSTEM privileges and object privileges granted to a user. If a ROLE is found -- then it is checked recursively.

  • Output can be directed to the screen or to a file.

3 db access control check for dba role l.jpg
3) DB Access Control - Check for DBA Role

3 db access control how are privileges granted l.jpg
3) DB Access Control - How are privileges granted

  • DBMS like Oracle has pre-defined roles (ex: DBA)

  • You may also have user defined roles


    1) Create Role AcctDept;

    2) Grant Select, Update on Orders to AcctDept;

    3) Grant AcctDept to Smith, Jones;

    4) Grant DBA to Smith;

    Grant all privileges on Orders to Smith;

    Grant select on Orders to Public;

    Revoke delete on Orders from smith;

3 db access control disable account l.jpg
3) DB Access Control - Disable Account

CREATE USER smith identified by s9 default tablespace users;

ALTER USER scott ACCOUNT LOCK -- lock a user account


ALTER USER scott PASSWORD EXPIRE; -- Force new pwd

3 db access control launch oem l.jpg
3) DB Access Control - Launch OEM

  • Choose stand-alone for personal Oracle and login to oracle using a dba user/password

3 db access control connect to a database l.jpg
3) DB Access Control - Connect to a Database

  • On the left side of the screen, double click Network and then Databases to connect to the database you want o manage.

3 db access control maintain user accounts l.jpg
3) DB Access Control - Maintain User Accounts

  • Once you login, you may create users, roles and profiles as well as granting privileges to them through a GUI interface.

3 db access control profiles l.jpg
3) DB Access Control - Profiles

  • PROFILE clause: indicates the profile used for limiting database resources and enforcing password policies. Example:




    CPU_PER_CALL 3000





    COMPOSITE_LIMIT 5000000;

  • CREATE USER sidney

    IDENTIFIED BY out_standing1


    QUOTA 10M ON demo


    QUOTA 5M ON system

    PROFILE app_user


3 db access control security ms access l.jpg
3) DB Access Control - Security MS-Access

  • Two methods for securing a database:

    • set password to open a database (system security);

    • user-level security, to limit the parts of the database that a user can read or update (data security).

3 db access control system level open exclusive l.jpg
3) DB Access Control - System Level: Open Exclusive

3 db access control system level security cont l.jpg
3) DB Access Control - System Level Security (cont.)

User is prompted

every time he/she opens the DB

DBA Sets password

3 db access control ms access user level l.jpg
3) DB Access Control - MS-Access: User Level

Slide26 l.jpg


  • Possible Holes in DBMS

    • (50+ listed)

    • Buffer overflow problems in DBMS code

    • Miscellaneous attacks (Denial of Service, source code disclosure of JSPs, others)

  • Need for continual patching of DBMS

    • Cost of not patching

      Worms, virus, etc. SQL slammer worm

5 db applications l.jpg
5) DB Applications

  • “75 percent of hacks happen at the application” – Gartner “Security at the Application Level”.

  • “The main battlefield between hackers and security professionals have moved from the network layer to the web applications”

    Eric Marvets, “Microsoft Security Summit”, April 13, 2006, Atlanta, Georgia

5 db applications sql injection l.jpg
5) DB Applications - SQL Injection

  • Web Application where

    1) User inputs text into a textbox

    2) Text used to build SQL Query dynamically

    3) Malicious input changes the nature of the query

    Example: user inputs names into textbox

    Name: Benjamin Franklin ' OR 1=1;


    WHERE EMPLOYEE.Name = ” + userInput



    'Benjamin Franklin' OR 1 = 1;

    • Result: every row of the EMPLOYEE table will be returned

Sql injection solution l.jpg
SQL Injection - Solution

  • Similar to Buffer overflow:

    validate user input.

6 virtual private databases l.jpg
6) Virtual Private Databases

  • May be implemented through Views in most DBMS

  • In Oracle, you may create a policy that will be fired when an operation (Insert, Update, etc.) is performed by a certain user on a certain object.

Slide33 l.jpg

Virtual Private Database Technology

Virtual Private Database Technology

  • Data access via Virtual Private Database will perform the following five steps:

  • User sends SQL to the database server.

  • The associated table triggers a pre-defined security policy.

  • The security policy returns a predicate.

  • The SQL statement is modified according to the security policy.

  • Secured data returns to user.

  • Data access via Virtual Private Database will perform the following five steps:

  • User sends SQL to the database server.

  • The associated table triggers a pre-defined security policy.

  • The security policy returns a predicate.

  • The SQL statement is modified according to the security policy.

  • Secured data returns to user.

6 vpd grant execute on dbms rls l.jpg
6) VPD - Grant Execute on DBMS_RLS


    SQL> connect sys as sysdba

    Enter password: ******


    SYSDBA creates a user called SECMAN (Security manager)

    SQL> create user secman identified by s default tablespace users;

    SYSDBA GRANTS EXECUTE ON DBMS_RLS TO SECMAN so this user can create the VPD

    SQL> grant dba to secman;

    SQL> grant execute on dbms_rls to secman;


    SQL> connect secman/s;

Vpd definition l.jpg
VPD - Definition

Ex.: SELECT * FROM Emp; -- becomes

SELECT * FROM Emp where Emp.Name = User;

Slide36 l.jpg

Virtual Private Database Technology

A VPD security model uses the Oracle dbms_rls package (RLS stands for row-level security) to implement the security policies and application contexts. This requires a policy that is defined to control access to tables and rows

6 vpd update example l.jpg
6) VPD – Update Example

Connecting Policy, Table and Function

UPDATE mn668b14.Employees set ext = 777;

1 row updated.

6 vpd security policy l.jpg
6) VPD - Security Policy

-- create security policy



(object_schema => 'MN668B14',

object_name => ' EmployeeUpdateOrderView',

policy_name => 'EMP_UPDATE_ORDERS_POLICY');



dbms_rls.add_policy (

object_schema => 'MN668B14',

object_name => ' EmployeeUpdateOrderView ',

policy_name => 'EMP_ORDERS_UPDATE__POLICY’,

function_schema => 'MN668B14',

policy_function => 'EMPUSER_ONLY',

statement_types => 'SELECT,UPDATE,INSERT,DELETE',

update_check => TRUE



6 vpd summary l.jpg
6) VPD - Summary

  • VPD security provides a new way to control access to Oracle data.

  • One Schema, several virtual schemas.

  • Dynamic nature of a VPD. At runtime, DBMS modifies SQL statement to add security.

    Burleson, Donald (2003), "Establish security policy with Oracle virtual private database",

7 oracle label security ols l.jpg
7) Oracle Label Security (OLS)

  • simulates multilevel db.

  • Adds a field for each row to store the row’s sensitive label.

  • Access is granted (or denied) comparing user’s identity and security clearance label with row’s sensitive label.

7 ols and multilevel security l.jpg
7) OLS and Multilevel Security

  • Information has different classifications

  • Users have different security clearances

  • Purpose: separate data based on its classification

  • Mandatory Access Control (MAC): security enforced by system and not by the user.

  • Polyinstantiation: multiple rows with same PK. Instances distinguished by security level.

7 problem with multilevel security l.jpg
7) Problem with Multilevel Security

  • It is really multiple instantiations of single-level DBMS, which strongly degrades performance.

  • Examples: Trusted Oracle, DB2 for z/OS, Informix OnLine/Secure, Sybase secure system

7 oracle label security l.jpg
7) Oracle Label Security:

  • simulates multilevel db.

  • Adds a field for each row to store the row’s sensitive label.

  • Access is granted (or denied) comparing user’s identity and security clearance label with row’s sensitive label.

  • Label contains LEVEL, GROUP and COMPARTMENT

7 ols vpd l.jpg
7) OLS & VPD

  • Like VPD, OLS creates Policies

  • A policy is a name that associates labels, rules, and authorizations.

  • DBA defines a set of labels for data and users, along with authorizations for users and program units, that defines all access to objects.

7 ols label has 3 components l.jpg
7) OLS LABEL has 3 Components

  • level : mandatory, simple hierarchy

  • compartment optional, non-hierarchical

  • group optional, tree level hierarchy

  • OLS compares the user security clearance with the sensitivity label assigned to the data.

  • IF a label contains all 3 components, THEN

    the security clearance of the user >= the data sensitivity level, contain all compartments and at least one group.

7 ols more on 3 components l.jpg
7) OLS - More on 3 components

  • label has 3 components:

    • a single level (sensitivity) ranking

    • zero or more horizontal compartments

    • zero or more hierarchical groups

7 ols column added l.jpg
7) OLS – Column added

  • When an Oracle Label Security policy, a column is added to the table that is protected by the policy. This policy label column contains the label information for each data row.

  • DBA can choose to display or hide this column

7 ols levels l.jpg
7) OLS - Levels

7 ols compartments l.jpg
7) OLS - Compartments

7 ols groups l.jpg
7) OLS - Groups

7 ols vpd51 l.jpg
7) OLS & VPD

  • FGAC = Fine Grained Access Control (A mechanism to implement Row level security in Oracle Database)

  • OLS and VPD are the utilities which are used for FGAC.

  • OLS: GUI tool


  • COLUMN LEVEL SECUITY in Oracle 9i, neither. use views. in Oracle 10g you can o column masking with VPD, but not with OLS.

7 ols conclusion l.jpg
7) OLS Conclusion

  • Built on top of VPD

  • Higher Level, more refined than VPD

  • Built around Row Level Security, Not much for Column Level Security

8 inference threat l.jpg
8) Threat

9 encryption overview l.jpg
9) Encryption: overview

  • Encrypting Data-in-transit

    As it is transmitted between client-server

  • Encrypting Data-at-rest

    Storing data in the database as encrypted

    Encrypting of Data is another layer of security (security in depth). It does not substitute other DB security techniques such as strong password.

9 encrypting data in transit l.jpg
9) Encrypting Data-in-transit

For a Hacker to eavesdrop on a conversation and steal data, two things may occur

1) Physically tap into the communications between

the db client & the db server

2) Hacker must understand the communication stream in order to extract sensitive data.

In order to do this, what does the Hacker need ?

Tools for packet sniffing l.jpg
Tools for packet sniffing

the Hacker needs to have

  • With a minimum understanding of TCP/IP +

  • Use one of many network protocol analyzer that are freely available.

  • Packet (formatted block of data transmitted by a Network).

  • Sniffing: capturing and analyzing package

    (like dog sniffing).

Minimum understanding of tcp ip l.jpg
Minimum Understanding of TCP/IP

  • Network Security book.


    Roberta Bragg, Mark Rhodes-Ousley and Keith Strassberg, Network Security; The Complete Reference.

  • TCP/IP is well documented all over the web.

  • Documentation describes the headers of the packet.

9 encryption where to run network analyzer packet l.jpg
9) Encryption - Where to run Network Analyzer Packet ?

  • Client Machine that has access to the Database server

  • Database Server

Network protocol analyzer examples l.jpg
Network Protocol Analyzer: examples

  • Tcpdump: utility available as part of installation on most UNIX systems. Can be downloaded from

  • (windump). Windows counterpart. Available on some systems. Can be downloaded from

  • Wireshark(

    world’s most famous NP Analyzer. Formerly Ethereal (

Implement encryption data in transit l.jpg
Implement Encryption,data-in-transit

Fortunately there are also many encryption techniques for data in transit:

  • Database-specific features such as Oracle Advanced Security

  • Connection-based metods (such as SSL)

  • Secure tunnels (such as SSH)

  • Relying on the operating Systems (IPSec Encryption)

Secure socket layer ssl l.jpg
Secure Socket Layer (SSL)

  • cryptographic protocols that provide secure communications on the Internet for such things as web browsing, e-mail, Internet faxing, instant messaging and other data transfers.

  • You may enable SSL from within a DBMS.

  • SQL-Server for example: Programs -> Microsoft SQL Server -> Server Network Utility, check the Force protocol Encryption checkbox. Then Stop and start SQL Server.

  • Server also must be informed how it will derive encryption keys

  • Note: make sure that your version of SSL is compatible with your version of MySQL (like in ODBC or JDBC).

Ssh tunnels l.jpg
SSH Tunnels

  • SSH used in many applications. Example: Substitute for FTP with encryption.

  • From most DBMSs, you can set up SSH tunnels to encrypt database traffic by port forwarding (Encrypted session between client and server).

  • Example: to connect Linux client machine of IP CCC.CCC.C.CCC to a MySQL instance installed on a server with IP address of SSS.SSS.S.SS listening in on port 3306 (default MySQL port).

  • Ssh –L 1000:localhost:3306 SSS.SSS.S.SS –l mylogin –I ~/ .ssh id –N -g

  • -L=port forwarding, Any connection attempted on port 1000 on the local machine should be forwarded to port 3306 on the server. Therefore any connection on port 1000 will go through encryption.

Ipsec l.jpg

  • Another Infrastructure option that protects the DB with encryption tools.

  • IPSec is done by the OS so you need to encrypt all communications (can’t be selective).

  • It operates at layer 3 of the OSI network (lower level).

    Installing IPSec on Windows/XP

  • install IP Security Policy manager. Then from Control Panel -> Administrative Tools, select IPSec

Encrypting data at rest l.jpg
Encrypting Data-at-rest

  • There are two reasons to do this

    • Protect it from DBAs.

    • Protect from File or Disk Theft.

Encrypting data at rest65 l.jpg
Encrypting Data-at-rest

  • Encrypting at Application Layer

    Must do it at multiple locations from within app.

    Data can only be used from within application

  • Encrypting at File System/Operating System Layer

    less flexible. Requires you to encrypt everything.

    Performance degrades

    Weak for handling Disk Theft problem.

  • Encrypting within Database

    • Usually, most practical option

Encrypting at application layer l.jpg
Encrypting at Application Layer

  • Application Developers use a cryptographic library to encrypt such as Java Cryptographic Extensions (JCE) – set of APIs in the and java.crypto packages

Encryption at os layer l.jpg
Encryption at OS layer

  • Windows implements the Encrypted File System (EFS) and you can use it for MS-SQL Server.

  • Disadvantages ?

Encryption within database l.jpg
Encryption within Database

  • SQL Server 2005 you can access Windows

    CryptoAPI through DB_ENCRYPT and DB_DECRYPT within T-SQL (similar to PL/SQL)

    Can use DES, Triple DES and AES

    (symmetric keys)

  • In ORACLE, you can access

    • DBMS_OBFUSCATION_TOOLKIT package that implements DES and Triple DES

Summary l.jpg

  • DB Encryption can be divided into Data-in-transit and Data-at-rest

  • Encryption is useful as a last layer of defense (defense in depth). Should never be used as an alternative solution

  • Encryption should be used only when needed

  • Key Management is Key

10 auditing l.jpg
10) Auditing

  • Need to be selective

2 main types of auditing l.jpg
2 main types of auditing:

  • Oracle-supplied auditing using AUDIT command. Results go to AUD$

  • Trigger-based DML auditing

  • Either way, DBA must monitor auditing table.

    Auditing examples/scripts:



Example of audit command l.jpg
Example of Audit command

  • Must have audit system privileges

  • Only tracks in subsequent user sessions

  • Creates records in table AUD$ owned by sys

    • You don’t query this table, you query

      • Views such as DBA_AUDIT_TRAIL

  • SQL> AUDIT Delete any table;

  • SQL> NOAUDIT delete any table;


  • SQL> AUDIT create session;

When to audit l.jpg
When to audit

  • When should we audit Oracle users ?

    • Basic set of auditing measures all the time

    • Capture user access, use of system privileges, changes to the db schema (DDL)

      If company handles sensitive data (financial market, military, etc.) OR

      If there are suspicious activities concerning the DB or a user, specific actions should be done.

Audit w triggers generic solution l.jpg
Audit w/ Triggers (generic solution)

  • Create a table that will contain audit information

  • Create a trigger that inserts a row into the table every time a certain operation is created such as


11 datawarehouses l.jpg
11) Datawarehouses

  • Traditionally queried only by upper management

  • Encryption has not been an option due to performance implications

  • Designed as Open systems, permitting exploratory approach

  • Optimization techniques for quick responses

Datawarehouse trends problems l.jpg
Datawarehouse Trends & Problems

  • Range of potential users are rapidly increasing

  • Number of security breaches are rapidly increasing

  • Legislation is addressing issue to protect personal information

  • Statistical Databases and Inferences

    User is allowed to see aggregate

    data, but not individual rows. With malicious input, user infers the value of individual rows.

Db security animations l.jpg
DB Security Animations

  • -> Advanced Concepts -> Security

    Referential Integrity

    Security Matrix

    Row level Security

    SQL Injection

    Database Inference

    Database Auditing


End of lecture l.jpg
End of Lecture
