Presentation Transcript
How do we predict weather general weather information clouds rain thunderstorms etc l.jpg

How Do We Predict Weather?

General Weather Information

Clouds, rain, thunderstorms, etc.



Slide4 l.jpg

Organizational Structure…

U. S. Department of Commerce

(International Trade, US Business Growth, Aid in Technological Advancement)

National Oceanic and Atmospheric

Administration (NOAA)

(Climate, Ocean Life, Satellites, Research)

National Weather Service

(Forecasts, Warnings, River Data, Weather Safety)


Slide5 l.jpg

What We Do

Produce Weather, Water and

Climate Forecasts and Warnings

-For All Americans

-To Protect Life and Property

-To Enhance the National Economy

Data and Products:

-Government Agencies

-Private Sector

-The Public

-Global Communities

Weather and data are becoming more important to the economy and business decisions


Slide6 l.jpg

National Weather Service

Our Primary Mission:

The protection of lives and property

Watches, warnings, and advisories for:

-Severe Thunderstorms

-Floods

-Winter Storms

-Tornados

-Flash Floods


Slide7 l.jpg

Advisory: Just so you know…

Watch: Stay Alert!

Warning: Take Cover NOW!


National weather service l.jpg
National Weather Service

  • 122 Weather Forecast Offices (CONUS, AK, HI, Guam and Puerto Rico)



Weather forecasting l.jpg
WEATHER FORECASTING

This problem has two parts . . .

Analyze: What’s going on right now?

Forecast: What’s going to happen?


Slide12 l.jpg

Analyzing the Weather

Surface Observations . . .

mostly at airports . . .

can be taken by people

Or by machines such as the ASOS -

Automated

Surface

Observing

System


Cooperative observers l.jpg
COOPERATIVE OBSERVERS

  • Volunteer weather observers

  • Daily temperature and precipitation reports

  • River level reports

  • Important for ground truth


Slide14 l.jpg

Of course, we can’t forget radar!

It can see father - with greater detail and more power than any other weather radar in the world!!

So sensitive . . . it can detect birds . . . bats . . . bugs and pollen in the air . . . and leaves rustling on nearby trees.


Slide15 l.jpg

But observations are not limited to surface conditions. Aircraft reports of winds and weather are important.

And observations from upper air balloons launched twice a day at around 120 sites are the basis of upper air analysis.


Slide16 l.jpg

Dozens of satellites keep a constant watch over the earth each day. Some are geosynchronous (stay in the same position over the earth) while others orbit around the earth.


Slide17 l.jpg

FORECASTING each day. Some are geosynchronous (stay in the same position over the earth) while others orbit around the earth.

There are 3 basic methods of forecasting:

  • Persistence

  • Experience

  • Computer Modeling


Slide18 l.jpg

PERSISTENCE: each day. Some are geosynchronous (stay in the same position over the earth) while others orbit around the earth.

  • Not much is going to change.

  • Tomorrow will be like today.

  • Works great in summer.

  • Not so good the rest of the year.


Slide19 l.jpg

EXPERIENCE: each day. Some are geosynchronous (stay in the same position over the earth) while others orbit around the earth.

  • Forecast what was seen before to repeat.

  • This is good for 1 to 2 day forecasts.

  • Works great a lot of the time.

  • Problem when something new happens.


Slide20 l.jpg

MODELS: each day. Some are geosynchronous (stay in the same position over the earth) while others orbit around the earth.

  • They are better than people past 3 days.

  • Works great most of the time.

  • Problem when bad data gets put in or if something really new occurs.


Slide21 l.jpg

Let’s start with a question. . . Why do we have weather?

The Earth rotates on a tilted axis.

Due to the tilt, the equator is always heated more than either pole.


Slide22 l.jpg

The Result . . . weather?

Part of Earth’s atmosphere is too cold and dense and part of the atmosphere is much too warm and light

Somehow . . . this must all be balanced out.


Not just temperature differences l.jpg
Not just temperature differences… weather?

Air which stays over water for long periods of time absorbs some of the moisture through evaporation.



Clouds l.jpg
CLOUDS weather?

  • Cirrus

  • Stratus

  • Cumulus

  • Nimbus


Slide28 l.jpg

Cirrus Clouds weather?

  • High-level clouds

  • Usually only ice crystals

  • Generally in fair weather


Stratus clouds l.jpg
Stratus Clouds weather?

  • Base is usually only a few hundred feet above the ground

  • Little to no vertical development

  • Can cover entire sky


Cumulus clouds l.jpg
Cumulus Clouds weather?

  • Base is at low level, but tops can reach 60,000 feet (11 miles) high

  • Made of both ice and water droplets

  • Puffy like cotton balls


Nimbus clouds l.jpg
Nimbus Clouds weather?

  • Generally form 7,000 to 15,000 feet (1 to 3 miles) above ground

  • Steady precipitation


Precipitation l.jpg
PRECIPITATION weather?

Two basic ways precipitation forms:

  • “Collision” process (warm clouds)

  • “Ice Crystal” process (cold clouds)



Ice crystal process l.jpg
“Ice Crystal” Process weather?

Easier for water vapor to deposit directly onto ice crystals. Crystals then grow heavy enough to start falling.


Rain or snow l.jpg
Rain or Snow?? weather?


Thunderstorms l.jpg
THUNDERSTORMS weather?

  • Moisture

  • Instability

  • Lifting

In order to form, thunderstorms need:


Slide37 l.jpg

Mid and upper-level moisture can arrive from the Pacific. weather?

Low-level moisture comes from the Gulf of Mexico.


Instability l.jpg
INSTABILITY weather?

  • If air is stable, it will try to go back to where it was

  • If air is unstable, it will continue in the direction it was pushed


Slide39 l.jpg
LIFT weather?

  • Differences in heating

  • Terrain

  • Fronts, boundaries, drylines



Thunderstorm hazards l.jpg
Thunderstorm Hazards weather?

  • Hail

  • Damaging Winds

  • Tornados

  • Flash Floods


Slide42 l.jpg
HAIL weather?


Damaging winds l.jpg
DAMAGING WINDS weather?

Damage from

a tornado

Damage from

a downburst


Tornados l.jpg
TORNADOS weather?

F-Scale

  • Named after its creator, Dr. Fujita

  • Used to describe how fast winds in a tornado are

  • Actually goes all the way to F12, which is the speed of sound


Slide47 l.jpg

Minimal Tornado weather?

- F0, F1

- 67% of S.C. TX Tornadoes

- Causes 5% of all deaths

- Life span 1 to 2 minutes

- Path length less than 1 mile

- Path width less than 100 yards

- Wind speeds up to 110 mph


Slide48 l.jpg

Strong Tornado weather?

  • - F2, F3

  • - 30% of S.C. TX Tornadoes

  • - Causes 30% of all deaths

  • Life span 15 to 20 minutes

  • Path up to 15 miles

  • - Path width up to 500 yards

  • - Wind speeds up to 200 mph


Slide49 l.jpg

Violent Tornado weather?

- F4, F5

- 3% of S.C. TX Tornadoes

- Causes 65% of all deaths

- Life span to several hours

- Path length dozens of miles

- Path width to 1 1/ 2 miles

- Wind speeds over 300 mph



Flash flooding l.jpg
FLASH FLOODING weather?


Slide53 l.jpg

For each foot of rising water, a car weighs weather?1500 pounds less!

As little as 18 inches of water can float a truck! It takes only 12 to 14 inches of water to float a car!


Slide54 l.jpg

Tire 8” wide, weather?

30” diameter

floats 816 lbs

of car weight

Tire 12” wide,

30” diameter

floats 1225 lbs of car weight


Slide56 l.jpg

For Current Weather Information: weather?

NOAA Weather Radio

Or:

www.weather.gov

Clickable map of the entire U.S.

www.srh.noaa.gov/ewx

NWS Austin/San Antonio’s Homepage


Questions l.jpg
QUESTIONS? weather?

Marianne Sutton@noaa.gov

National Weather Service

Austin/San Antonio

2090 Airport Road

New Braunfels, TX 78130
