Presentation Transcript
cummins power generation
Cummins Power Generation
  • Cummins Power…A Leader In Innovation
  • Cummins Power Generation Advantage
  • Cummins Power Generation Range
  • Cummins Power Generation Products
    • 11 to 55 kVA
    • 55 to 250 kVA
    • 250 to 550 kVA
    • Above 550 kVA
    • X Range
    • Power Box
    • Power Rent
slide4
1940
  • The U.S. Antarctic Service explorer Snow Cruiser was the first of the giant diesel-electric vehicles. The unique GE drive system incorporated two Cummins H-6 engines with 300 hp installed power.
slide5
1952
  • Cummins Number 28 Diesel Special takes pole position at the Indianapolis 500 after breaking the qualifying lapspeed record at139 mph (224 kph). The 430-hp diesel was the first turbocharged engine at Indy.
slide6
1966
  • Cummins-powered Merry-Go-Round breaks the world water speed recordfor diesel poweron Southampton Water, UK at over 60 mph (96kph).
slide7
1995
  • The first Class 8 truck to ever race the 14,110-ft Pike’s Peak hill-climbin Colorado, Cummins Wild Thing II set a time under 17 minutes. It was poweredby a 525-hp N14.
slide8
1996
  • At 141 mph(227 kph), a Cummins ReCon®B Series powersa Dodge Ramto a world landspeed record for6-liter dieselsat BonnevilleSalt Flats, Utah.
slide9
1998
  • The CumminsC Series-powered Cable & Wireless Adventurer, breaks the record for the fastest powerboat circumnavigationof the world in under 75 days.
slide10
1999
  • A test run of the ICE TD train in Germany sets a record-breaking speed of 138 mph (222 kph) for a diesel-electric multiple unit, powered by four QSK19 underfloor engines.
slide11
2000
  • A Cummins Signature 600 diesel pulls the longest ever Australian Road Train into the record books with 79 trailers weighing 1072 tons.
slide12
2000
  • Powered by a Cummins QSK78, the 550-ton gvw Komatsu 930Eis the fastestmine truck in its class. The 78-liter engine is the first high-speed diesel to reach 3500-hp.
slide13
2001
  • Powered bya 185-hpCummins B5.9,the Australian Army HMEVis the world’sfastest backhoe loader with a top speed of 62 mph (100 kph).
slide14
2001
  • A Cummins M11, race-engineeredto 1600 hp, drives the EVS Team in Malta to a 1/4-mile record of 11.7 seconds for a Class 8-size diesel truck, with an exit speed of 122 mph(196 kph).
slide15
2002
  • Sidewinder breaks the world speed record for pickup trucks at 222 mph (357 kph), powered by an ISB dieselup-rated to 735 hp by Cummins and the Gale Banks Team.
slide16
2003
  • The world's most powerful Road Train in Australia, with a Cummins QSK19 and ISX providing 1000 hp installed power to shift 400 tons and roll 150 wheels.
slide17
2004
  • A 5.9-liter Cummins-powered dragster using biodiesel sets the fastest-ever time for a diesel covering 1/4 milein 7.98 seconds with the Bentz Racing Team at Pomona Raceway, California.
slide18
2004
  • A 5.9-liter Cummins-powered Steamliner achieves a speed of 292.7 mph(471 kph) on Bonneville Salt Flats to becomethe world's fastest-ever diesel vehicle.
slide19
2004
  • A Case STX Quadtrac in France sets a new world record by plowing 766 acres in24 hours powered by a 565-hp Cummins QSX.
slide20
2005
  • The Earthraceto breakthe record forthe fastest circumnavigationof the globe powered bytwo Cummins MerCruiser Diesel QSC 540 hp engines runningon 100% biodiesel.
product line breadth
Product Line Breadth

78L

QSK 78

3.3L

B Series

what cummins is known for
What Cummins is known for…
  • 80 years Engine Design and Manufacturing Experience
  • 250 million $US invested per year over the last 10 years
  • Excellent Durability
  • Excellent Reliability
  • Low Weight
  • Low Emissions
  • Low Fuel Consumption
  • Low Oil Capacity
  • Low Maintenance Costs
what cummins is known for26
What Cummins is known for…

Technology Leadership

Cummins Leadership In Critical Technologies:

  • Electronic engine management andinformation systems
  • High pressure fuel systems
  • Low emission designs

The world’s largest manufacturer of heavy-duty electronic diesels.

Proven technology now extending across the engine range.

Highly advanced design and manufacturing by Cummins Fuel Systems Division.

Goal: first to market with all new emissions certified engines.

Technology platforms established for well beyond 2005.

cummins a leader in emissions
Cummins… …A Leader In Emissions
  • Technologies
    • Cooled EGR (Exhaust Gas Recirculation)
    • Internal EGR
    • Advanced Combustion
      • Cummins In Cylinder Advanced Combustion
      • Cummins quantum Fuel Systems
      • Cummins Electronic Control
    • Aftertreatment
slide28

Diesel Genset Product Range

    • 11kVA – 3300kVA

QSK78

QSK60

QSK50 & KTA50

QST30 & KTA38

QSK23 & VTA283

QSK19 & K19

QSX15

QSM11

N Series

QSL Series

C Series

B Series

X Series

Kubota

11kVA

Cummins Power Generation

3325 kVA

model nomenclature 50 hz
Model Nomenclature - 50 Hz

45 kVA Standby market node, three Phase

The actual output may be 42 kVA

Model name relates to the closest market kVA node

Data Sheets will provide the genset output

  • C45D5

Cummins

50 HZ

Diesel

product range
Product Range
  • 11 to 55 kVA
  • 55 to 250 kVA
  • 250 to 550 kVA
  • 650 to 1100 kVA
  • 1 to 3.5MVA
  • X Range
  • Power Box
  • Power Rent
