d istortional b uckling o f c a nd z m embers i n b ending
DISTORTIONAL BUCKLING OFCAND ZMEMBERSIN BENDING

Progress Report to AISI

Cheng Yu, Benjamin W. Schafer

The Johns Hopkins University

August 2004

overview
Overview
  • Test Summary
  • Finite Element Modeling
  • Extended FE Analysis
  • Stress Gradient Effects
  • Conclusions
test summary
Test Summary
  • 5 more tests were performed since last report in February 2004
  • Total 24 distortional buckling tests have been done. All available
  • geometry of sections in the lab have been tested.

Comparison with design methods

slide6

Test Summary -

Performance of Direct Strength Method

Test results vs. Direct Strength predictions

finite element modeling
Finite Element Modeling
  • Shell element S4R for purlins, panel and tubes, solid element C3D8
  • for transfer beam.
  • Geometric imperfection is introduced by the superposition of local
  • and distortional buckling mode scaled to 25% or 75% CDF.
  • Residual stress is not considered.
  • Stress-strain based on average of 3 tensile tests from the flats of every specimen
  • Modified Riks method and auto Stabilization method in ABAQUS were considered for the postbuckling analysis. The latter has better results and less convergence problems therefore the auto Stabilization is used.
  • The FE model was verified by the real tests.
slide8

Finite Element Modeling -

Comparison with test results

On average:

FEM-to-test ratio= 106% for 25% CDF; 93% for 75% CDF --- local buckling tests

FEM-to-test ratio= 109% for 25% CDF; 94% for 75% CDF --- distortional buckling tests

slide9

Extended Finite Element Analysis

FEA results vs. Direct Strength predictions

slide10

p

Moment diagram

Stress Gradient Effect on Thin Plate -

Moment gradient on beams

compression

Stress diagram of top flange

Stress diagram of bottom flange

tension

slide11

Stress Gradient Effect on Thin Plate -

Plate buckling

Hat section

C section

Buckling of uniformly compressed rectangular plates

slide12

Stress Gradient Effect on Thin Plate –

Analytical model

Stiffened element

Stress distribution:

Deflection function:

(by Libove 1949)

slide13

Stress Gradient Effect on Thin Plate –

Analytical model

Unstiffened element

Stress distribution:

slide14

Stress Gradient Effect on Thin Plate –

Analytical model

Finite element analysis by ABAQUS is used to verify these 3 deflection functions.

Bucking shape by FEA

Bucking shape by analytical model

Average analytical result-to-FEA ratios are

Deflection function 1: 102.4%

selected

Deflection function 2: 99.7%

Deflection function 3: 99.6%

slide15

Stress Gradient Effect on Thin Plate –

Stiffened Element Results

kmax vs. plate aspect ratio (β) for ss-ss stiffened element

(recalculation of Libove’s equations 1949 )

slide16

Stress Gradient Effect on Thin Plate –

Unstiffened Element Results

kmax vs. plate aspect ratio (β) for ss-free unstiffened element

slide17

Stress Gradient Effect on Thin Plate –

(r=0) Results

0

Comparison of stiffened and unstiffened elements subject to stress gradient r=0

kmax= buckling coefficient at the maximum stress edge

k0= buckling coefficient for plates under uniform compression stress

slide18

Stress Gradient Effect on Thin Plate –

Ultimate strength

Winter curve ---

ABAQUS r=1 --- plate under uniform compression stress

ABAQUS r=0 --- plate under stress gradient, stress is only applied at one end

conclusions
Conclusions
  • Tests that separate local and distortional buckling are necessary for understanding bending strength.
  • Current North American Specifications are adequate only for local buckling limit states.
  • The Direct Strength expressions work well for strength in local and distortional buckling.
  • Nonlinear finite element analysis with proper imperfections provides a good simulation.
  • Extended finite element analysis shows that DSM provides reasonable predictions for strengths in local and distortional buckling.
slide20

Conclusions - continued

  • An analytical method for calculating the elastic buckling of thin plate under stress gradient is derived and verified by the finite element analysis.
  • Plate will buckle at higher stress when stress gradient exists. The stress gradient has more influence on the unstiffened element than stiffened element.
  • Study on the ultimate strength of plate under stress gradient has been initialized. Up-to-date results show Winter’s curve works well for stiffened element under stress gradient.
  • More work on restraint and influence of moment gradients will be carried out by the aid of the verified finite element model.
acknowledgments
Acknowledgments
  • Sponsors
    • MBMA and AISI
    • VP Buildings, Dietrich Design Group andClark Steel
  • People
    • Sam Phillips – undergraduate RA
    • Tim Ruth – undergraduate RA
    • Jack Spangler – technician
    • James Kelley – technician
    • Sandor Adany – visiting scholar
slide22

Stress Gradient Effect on Thin Plate –

Energy method

Total potential energy:

+

( term for the elastic restraint if exists)

When buckling happens:

  • Need two assumptions to solve the elastic buckling stress:
  • the stress distribution in plate:
  • the deflection function:
slide23

Stress Gradient Effect on Thin Plate –

Analytical model

3 deflection functions are considered for the unstiffened element:

1.

2.

3.

slide24

Stress Gradient Effect on Thin Plate –

Analytical model

The coefficients in the assumed deflection function are determined by applying to

the 6 boundary conditions:

1.

2.

3.

(no deflection)

(no moment)

4.

5.

6.

(no shear force)
