The management of empyema the practical vs. ideal approach. R. Masekela University of Pretoria . Case presentation. Patient A.K 11 month old baby boy Main Complaint : Coughing - two weeks non productive Fever - two weeks Vomiting - after coughing

loader
I am the owner, or an agent authorized to act on behalf of the owner, of the copyrighted work described.
capcha
Download Presentation

PowerPoint Slideshow about 'The management of empyema the practical vs. ideal approach' - Lucy


An Image/Link below is provided (as is) to download presentation

Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.


- - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - -
Presentation Transcript
slide3

Patient A.K

11 month old baby boy

Main Complaint :

Coughing - two weeks non productive

Fever - two weeks

Vomiting - after coughing

Diarrhoea - one week, brown and loose no blood noted in stool

3 weeks before admission to primary care hospital was seen with a cough and fever and treated with Amoxycillin and Paracetamol. Did not improve after a week and was taken back.

slide4

Diagnosis with bronchopneumonia and a pleural effusion Ampicillin and Amikacin for 6 days

  • Vancomycin for 2 days
  • PMH : No previous admissions, healthy
  • Family history : no atopy, no asthma
  • No TB contacts
slide5

On Examination

Mass 10kg, 100% expected

Length 78cm, 100% expected

Vitals : RR 60, Pulse 110, Temp 37.5, BP 90/40 Sats 90%

5% dehydrated

Chest: Grunting, Nasal flaring, subcostal recessions, bilateral scattered crepitations, decreased air entry right lower lobe and stony dullness right base

slide8

Pleural pus specimen - 31/05/07

Cultured Staph. Aureus

R - Penicillin/ampicillin

R - Erythromycin

R - Clindamycin

S - Cloxacillin

history
HISTORY
  • 460 BC
  • Em=within
  • Pyema=accumulation of pus
  • Hippocratic physicians recommended treating empyema with open drainage
  • “those diseases that medicines do not cure are cured by the knife”
history cont d
HISTORY cont’d
  • 1876- Hewitt described a method of closed drainage of the chest in which a rubber tube was placed into the empyema cavity and drained via the water seal drainage
  • Early 20th century introduction of surgical therapies for empyema
    • thoracoplasty, decortication.
empyema
Empyema
  • Empyema: presence of pus in the pleural space
  • Boys affected more than girls
  • First world 0.6-3% bacterial pneumonias

Megan et al Curr Opinion Pediatr 2007

  • HIV positive 8% of South African children Zar et al. Acta Paediatrica 2001
normal pleural fluid
Normal pleural fluid
  • Pleural space potential space 10-24µm
  • 0.1-0.2 ml/kg pleural fluid
  • Starlings forces: filtration and reabsorption
  • pH 7.6
light s criteria
Light’s criteria
  • Pleural fluid protein: serum protein > O.5
  • Pleural fluid : serum LDH >0.6
  • Pleural fluid LDH > 2/3 upper limit of serum LDH

Light R. Chest 1995;108:299-301

other minor criteria
Other minor criteria
  • Cholesterol > 45mg/dl
  • Protein content > 3.0 g/dl
  • pH <7.2
  • Glucose < 50% serum
parapneumonic pleural effusions
Parapneumonic pleural effusions
  • 3 groups or stages based on pathogenesis:
  • Uncomplicated parapneumonic effusion
  • Complicated parapneumonic effusion
  • Thoracic empyema.
exudative stage
Exudative stage
  • Sterile pleural fluid accumulates in pleural space.
  • Pleural fluid originates in lung interstitial spaces and in capillaries of visceral pleura due to increased permeability.
  • Pleural fluid ↓ WBC ↓ LDH level, glucose and pH levels are normal
  • Effusions resolve with antibiotic therapy.
fibropurulent stage
Fibropurulent stage
  • Bacterial invasion of the pleural space occurs → accumulation of neutrophils, bacteria and cellular debris
  • Deposition of fibrin loculations
  • Pleural fluid pH <7.2 , glucose levels ↓, LDH level >1000IU/l
organizational stage
Organizational stage
  • Fibroblasts grow into the exudates from both the visceral and parietal pleural surfaces
  • They produce an inelastic membrane called pleural peel.
  • Thick pleural fluid
complications
Complications
  • Dissect into lung parenchyma→ bronchopleural fistulas and pyopneumothorax
  • Dissection through chest wall (empyema necessitatis) RARE
  • Dissection into abdominal cavity
organisms
Organisms
  • Strep. pneumonia
    • HIV infection 41X risk of invasive disease and more resistance Mahdi et al PIDJ 2000
    • Incidence increasing in developing world
  • S. aureus
    • Increasing incidence CA-MRSA in HIV-infected children 50% in Natal blood culture positive. McNally et al. Lancet 2007
    • 67 of 100 empyema. Goel et al. J Tropical Peadiatr 1999
  • H. influenza type b
  • Gram negatives
    • Pseudomonas
    • Klebsiella
    • E.coli
organisms1
Organisms
  • Tuberculosis
    • Rare cause but common PPE
  • Fungi
  • Viral
  • Atypical organism
    • Mycoplasma
clinical manifestations
Clinical manifestations
  • Aerobic bacterial pneumonia
    • An acute febrile illness with chest pain, sputum production, and leukocytosis.
    • A complicated parapneumonic effusion with presence of a fever lasting more than 48 hours after initiation of antibiotic therapy.
clinical manifestation
Clinical manifestation
  • Anaerobic bacterial infection
    • Usually presents with subacute illness.
    • symptoms persisting for more than 7 days.
    •  60% of patients have weight loss.
    • Poor oral hygiene
    • Factors predisposing to recurrent aspiration.
chest x rays
Chest x-rays
  • PA and lateral decubitus
  • Adult studies sensitivity 67% and specificity 70%

Heffner JE. Clinics Chest Med 1999;20:607-622

  • PA at least 400ml fluid vs. 50ml lateral decubitus
  • Assess for loculations
ultrasound
Ultrasound
  • Classification
    • Stage 1: anechoic fluid
    • Stage 2: loculations
    • Stage 3: solid peel
  • Guide placement of intercostal drain

Hogan MJ, Cooley BD. Paediatric Resp Reviews 2008;9:77-84

ultrasound1
Ultrasound
  • Size of effusion
  • Differentiate consolidation from empyema
  • Unreliable predictor of disease severity
ct scan
CT scan
  • Anatomical
    • Parenchymal lesions
    • Endobronchial lesions
    • Mediastinal lesions
    • Lung abscess
management
Management
  • IV antibiotics and intercostal drainage
  • Fibrinolytics
  • Video -Assisted Thoracoscopic Surgery (VATS)
  • Open thoracotomy and decortication
management1
Management
  • Supportive
      • Bed rest
      • Analgesia
      • Oxygen
      • Fluids
  • Identify the cause
      • Malnutrition
      • TB
      • HIV
antibiotic therapy
Antibiotic therapy

Zampoli M, Zar H. SAJCH 2007;1(3):121-8

fibrinolytics
Fibrinolytics
  • Degrade fibrin, blood clots and pleural loculi in pleural space
  • Streptokinase: 15 000U/kg in 20-50ml saline once daily for 3 days (vial 750 000U R1400, 1 million units R2700)
  • Urokinase: 40 000u in 40ml saline (> 1 year) or 10 000 in 10 ml BD for 3 days(< 1 year)
  • tPA 0.1mg/kg in 10-30ml saline dwell time 1 hour (50mg vial R3100)
fibrinolytic therapy versus conservative managements cochrane review
Fibrinolytic therapy versus conservative managements: Cochrane review
  • Seven studies 761 participants
  • No significant difference in risk of death (RR 1.08;95% CI 0.69-1.68)
  • Reduction in risk of treatment failure (RR 0.63;95% CI 0.46-0.85)
  • Fibrinolytics confer significant benefit and reduce requirement for surgical intervention (in early studies published)

Cameron R, Davies HR. Cochrane review April 23 2008 Issue 2

slide35
VATS
  • Can be done as primary procedure
  • Experienced surgeon necessary
  • Benefits
    • lower mortality
    • Re-intervention
    • Reduced length of hospital stay
    • Reduced hospital costs
thoracotomy
Thoracotomy
  • Treatment of choice if no experience or success with VATS
  • Early and accurate diagnosis and therapy
  • Attempt “mini” vs. full procedure
  • Mortality reduced
ideal approach
Ideal approach

Fuller MK, Helmrath MA. Curr Opinion Pediatrics 2007;19:328-332

practical
Practical
  • Early diagnosis
    • CXR include lateral decubitus
    • Early antibiotics
    • Early chest drainage
  • Loculations
    • Early referral
    • Thoracotomy if no improvement with ICD placement and correct antibiotics
prognosis
Prognosis
  • Favourable in patients started on appropriate antibiotic
  • Early chest tube drainage is beneficial.
  • Decortication or open drainage has decreased mortality and morbidity.
prognosis1
Prognosis
  • Mortality 6-12%
  • Complications
    • Bronchopleural fistula
    • Tension pneumatocoele
    • Fibrothorax
acknowledgements
Acknowledgements
  • Prof R Green
  • Dr O Kitchin
  • Dr S Risenga
  • Dr Moodley
  • ICU staff
