KammProfile Gasket

A Kammprofile Gasket is a top-notch sealing solution crafted for those tough environments where pressure and temperature can really push the limits. It boasts a solid metal core with concentric serrations on both sides, all wrapped up in a soft sealing material like graphite, PTFE, or mica. This clever design not only delivers outstanding sealing performance but also protects flange surfaces from wear and tear. Renowned for its ability to keep a tight seal even during thermal cycling and pressure changes, the Kammprofile Gasket finds its place in various industries, including oil & gas, petroc

Goodrich2
Download Presentation

KammProfile Gasket

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. An Informational Overview by Goodrich Gasket KammProfile Gasket

  2. What is a KammProfile Gasket? • A KammProfile Gasket is a metal gasket with serrated grooves on a solid core, covered by a soft sealing material. It provides excellent sealing in high-pressure and high-temperature conditions.

  3. Key Features • • • • • - Excellent blowout resistance - High compressibility and recovery - Suitable for fluctuating conditions - Minimal flange damage - Reusable in some cases

  4. Construction & Materials • Built from a serrated stainless- steel core, faced with materials like graphite, PTFE, or mica. These materials enhance sealing and chemical resistance.

  5. Applications • • • • • - Heat exchangers - Flanged joints - Boilers - Pressure vessels - Tank covers

  6. Industries Served • • • • • - Oil & Gas - Petrochemical - Power Generation - Chemical Processing - Marine & Offshore

  7. Advantages • - Withstands temperatures up to 1000°C - Handles pressures up to 500 bar - Tolerant of bolt torque variations - Low fugitive emissions • • •

  8. Types of KammProfile Gaskets 1 2 3 - Type PN: Soft layer on both faces - Type ZA: Loose centering ring - Type ZG: Integral centering ring

  9. Why Choose Goodrich Gasket? • Goodrich Gasket provides high- quality, custom-engineered sealing solutions that meet global standards and are trusted across industries.

  10. CONTACT US: +91-44 61373700 Contact WEBSITE: WWW.GOODRICHGASKET.COM
