1. KAMMPROFILE GASKET: A COMPREHENSIVE GUIDE www.pacificgaskets.com

2. Kammprofile Serrated Gaskets IDT-Kammprofile serrated gaskets are perfectly suited for secure sealing of flange connections in extreme operating conditions. They combine the specific properties of non-metallic gaskets [good elasticity to the flange surface] and metal gaskets [high stability and bursting strength]. The design allows high compression of the non-metallic layer, promoting low diffusion, and ensures that the serrated tips remain covered with non-metallic material, even in high surface pressure applications. In a compressed stage, the coverage of the serrated tip is still at approx. 0,1mm. Flange surface roughnesses of Rz <=80µm are recommended. Kammprofile gaskets are described in DIN EN 1514-6 with regards to base body profiling, thickness and material of the layers. It complies with TA Luft 2002 [VDI 2440/2200]; the calculatory leakage proof for VDI 2290 can also be supplied. LEARN MORE PAGE 01

3. Properties • Temperature resistance depending on non-metallic layer and selected metallic carrier material • Constant temperature range for graphite layer: -200 °C to approx. 450 °C; higher temperatures are possible depending on the design • Constant temperature range for PTFE layer:-200°C to approx.250 °C • • Very high operating pressures [400 bar] • Media resistance depending on non-metallic layer and selected metallic carrier material • High operational safety due to broad range of applications • Very low leakage rates for gases and liquids • Complies with TA Luft 2002[VDI 2440/2200] leakage requirements • Complies VDI 2290 [with calculatory leakage certificate following DIN EN 1591-1] 03 MORE INFORMATIONS PAGE 02

4. Fire Safe Test [Graphite • BAM-test report for liquid and gaseous oxygen [graphite] • Blow-out resistance [graphite] • No ageing and brittling even at high temperatures • Does not present a health risk • Very good handling during transport,installation and dismant-ling,mechanically stable • No excess pressing with standard tension devices • Individual labeling of every gasket on the centring ring • Use of low chloride graphite layers [chloride content < 25 ppm] and adhesive [chloride content < 12 ppm] allows the safe use of Kammprofile gasket even with parts made from austenitic materials PAGE 03

5. Materials used These gaskets are typically constructed from metallic cores such as stainless steel, carbon steel, or exotic alloys, while the facing material can vary based on the application requirements, including flexible graphite, PTFE, or compressed non-asbestos fiber. Advantages of Kammprofile Gaskets 1.High temperature resistance Kammprofile gaskets are designed to withstand extreme temperatures ranging from cryogenic conditions to high-temperature applications, making them ideal for use in demanding environments such as chemical processing plants and refineries. 2.Excellent sealing properties The serrated design of Kammprofile gaskets ensures a tight and uniform seal, minimizing the risk of leaks and fugitive emissions even under fluctuating pressures and temperatures. 3.Durability and longevity With their robust construction and superior materials, Kammprofile gaskets offer long-term reliability, reducing the frequency of maintenance and replacement cycles, thereby lowering operational costs. PAGE 04

6. Thank You Kammprofile gaskets offer unmatched sealing performance, durability, and reliability in a wide range of industrial applications. By understanding their design principles, advantages, installation procedures, and maintenance requirements, industries can maximize the efficiency and longevity of their sealing systems while minimizing costly downtime and repairs. REACH US SAN MATEO, CALIFORNIA 94010, USA +1 224 595 2699 INFO@PACIFICGASKETS.COM Back
