Presentation Transcript
slide1

GROSS ANATOMY

RADIOLOGY IMAGING MODALITIES

OF THE SPINE

CERVICAL SPINE IMAGES

  • CERVICAL PLAIN FILMS
  • CERVICAL MYELOGRAM
  • CERVICAL CT
  • CERVICAL MRI
slide2

CERVICAL SPINE

“AP” VIEW

MASTOID AIR CELLS

FACETJOINTS

FACET JOINTS

C-4

AIR IN TRACHEA

SPINOUS PROCESS

PEDICLES

CLAVICLES

slide3

CERVICAL SPINE

LATERAL VIEW

DENS

SPINOUS PROCESS

C-4

DISC SPACE

C-7

TRACHEA

slide4

CERVICAL SPINE

OBLIQUE VIEW

FACET JOINTS

PEDICLES

FORAMINA

C-5

TRACHEA

T-1

slide5

CERVICAL SPINE

OBLIQUE VIEW

SKULL

FORAMINA

FACET JOINTS

PEDICLES

C-7

FIRST RIB

TRACHEA

slide6

“AP”ODONTIOD VIEW

LATERAL MASS OF C-1

DENS

MANDIBLE

C-2

slide7

CERVICAL MYELOGRAM

AP VIEWc

IODINATED CONTRAST IN THE THECAL SAC

MANDIBLE

POST OP- PLATE

NERVE ROOTS

CORD

THECAL SAC

slide8

CERVICAL MYELOGRAM

LATERAL VIEW

IODINATED CONTRAST

IN THECAL SAC

C-2

C-3-4 DISC

THECAL SAC

POST OF FUSION

C-5-6

slide9

CT- CERVICAL SPINE

C-1 SECTION

ARCH OF C-1

DENS

BASE OF SKULL

MASTOID

AXIAL

SAGITTAL

slide10

CT-- CERVICAL SPINE

C-2 SECTION

C-2 BODY

DEGENERATED

C6-7

C-2 SPINOUS PROCESS

AXIAL

SAGITTAL

slide11

CT– CERVICAL SPINE

C2-3 INTERVERTEBRAL DISC

FORAMEN

DISC

FORAMEN

FACET JOINT

FACET JOINT

SPINOUS PROCESS

AXIAL

SAGITTAL

slide12

CT– CERVICAL SPINE

C- 3 SECTION

PEDICLE

PEDICLE

LAMINA

AXIAL

SAGITTAL

slide13

MRI– CERVICAL SPINE

AXIAL

THECAL SAC

CORD

slide14

MRI– CERVICAL SPINE

AXIAL

FORAMEN

FORAMEN

DISC

FACET JOINT

FACET JOINT

SPINOUS PROCESS

slide15

MRI CERVICAL SPINE

AXIAL

CORD

LAMINA

slide16

MRI—CERVICAL SPINE

SAGITTAL-midline

THECAL SAC

SPINAL CORD

DISC

slide17

MRI–CERVICALSPINE

SAGITTAL-midline

C-7

T-1

slide18

MRI—CERVICALSPINE

SAGITTAL-lateral

FACET JOINTS

slide19

THORACIC SPINE IMAGES

  • THORACIC PLAIN FILMS
slide20

THORACIC SPINE

AP VIEW

CLAVICAL

PEDICLE OF T-7

PEDICLE OF T-7

SPINOUSPROCESS

DISC SPACE

T-11

12 th rib

slide21

LATERAL THORACIC SPINE

CLAVICAL

PEDICLE

DISC SPACE

VERTEBRAL BODY

RIB

SPINOUS PROCESS

slide22

SKULL

THORACIC SPINE

SWIMMERS VIEW

C-1

HEAD OF HUMERUS

C-4

C-7

CLAVICAL

slide23

LUMBAR SPINE IMAGES

  • LUMBAR PLAIN FILMS
  • LUMBAR MYELOGRAM
  • LUMBAR CT— POST MYELOGRAM
  • LUMBAR MRI
slide24

LUMBAR SPINE

AP VIEW

T-12

RIB

L-1

PEDICLES

TRANSVERSE PROCESS

DISC SPACE

SPINOUS PROCESS

S-I JOINTS

SACRUM

slide25

LUMBAR SPINE

LATERAL VIEW

RIB

L-1

FORAMEN

DISK SPACE

FACET JOINT OF L-3 – L-4

L-5

SACRUM

slide26

LUMBAR SPINE

SPOT VIEW

L-5

SACRUM

DISC SPACE

slide27

LUMBAR MYELOGRAM

AP VIEW

IODINATED

CONTRAST IN

THECAL SAC

THECAL SAC

NERVE ROOTS

slide28

LUMBAR MYELOGRAM

LATERAL VIEW

IODINATED

CONTRAST IN

THECAL SAC

DISC

Thecal sac

L-5

S-1

slide29

CT- LUMBAR SPINE

POST MYELOGRAM

DISC

SPINOUS PROCESS

slide30

CT- LUMBAR SPINE

POST MYELOGRAM

FORAMEN

FORAMEN

slide31

CT-LUMBAR SPINE

POST MYELOGRAM

THECAL SAC

LAMINA

LAMINA

slide32

CT- LUMBAR SPINE

POST MYELOGRAM

FACET JOINTS

slide33

CT- LUMBAR SPINE

POST MYELOGRAM

PEDICLE

PEDICLE

NERVE ROOTS

slide34

MRI – LUMBAR SPINE

AXIAL VIEW

DISC

FACET JOINTS

LAMINA

slide35

MRI – LUMBAR SPINE

AXIAL VIEW

THECAL SAC

NERVE ROOTS

slide36

MRI – LUMBAR SPINE

AXIAL VIEW

NERVE ROOTS

FORAMEN

slide37

MRI– LUMBAR SPINE

SAGITTAL

SPINAL CORD

BULGING DISC

slide38

MRI- LUMBAR SPINE

SAGITTAL

L-3 – L-4

DISC

L-4 - L-5 DISC

L-5

S-1
