Dew Point Transmitter

Dew Point Transmitter is designed to measure the performance of drying systems for air, nitrogen, and other compressed gases. This Model is ideal for monitoring medical, commercial, and industrial applications including plastics resin dryers, breathing air, pneumatic tools, instrument air, and spraying/coating applications. It measures dew point by utilizing microprocessor circuitry to convert the sensor signals by the use of psychometric equations. Assembled in a rugged hand held IP-65 with quick disconnect tubing coupling and an internal sensor manifold. An orifice maintains line pressure for true pressure dew point readings.

vasthiinstruments
Download Presentation

Dew Point Transmitter

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Dew Ponit Transmitter www.vasthi.com

  2. TOPICS FOR DISCUSSION 1 2 DEW POINT TRANSMITTER ABOUT VASTHI INSTRUMENTS 3 CONTACT

  3. Introduction VASTHI INSTRUMENTS Our brand name ‘VASTHI’ had proven its credibility & reliability in Process Industry,by delivering zero flaw devices. VASTHI make measuring & safety instruments are installed at thermal power plants, petrochemicals, Fertilizer, cement, refineries, Steel and other process industries. Our company employees distinguish themselves through their strong commitment to customer service and dedication in executing their requirements. We work together with our customers to create value in the fields of industrial and social systems. We strive to develop products and solutions that best meet client’s expectations and needs.

  4. COST QUALITY TECHNOLOGY PARTNER Vasthi for years of relentless research can able to develop impeccable technological knowledge this made vasthi to depend less on expensive outsourced technologies which ultimately helped vasthi to promise matchless prices in the industry. Vasthi which always strives for perfectionism have taken a bold step of setting a flaw identity mechanism first time in India. This is a module where every equipment from vasthi was subjected to rigorous environmental conditions this type of practice enables to deliver zero flaw equipment. In a market where only fittest survive we endeavored into a venture with all world renowned sensor manufacturers for getting 100% accuracy in analytical systems. The pivot of any industrial analytical equipment is the sensor. We are always ahead of all our competitors and also first in India to deliver any latest updates regarding sensor technology from every nook of the world this always made vasthi the only one stop for all your industrial necessities. industrial working TIME Swiftness is the hallmark of vasthi in deference to the exigency of industries we are only one who can provide your desired equipment in least possible time. 1.Industrial safety and quality monitoring systems 2.Economical and user-friendly. 3.Installation maintenance and repairing.

  5. PRODUCT Dew Ponit Transmitter

  6. Dew Ponit Transmitter Relative humidity, Temperature Moisture in PPM and Dew point Measurement with one instrument. Vasthi Instruments are global leaders in manufacturing of Dew point transmitter and have been supplying instruments to customers worldwide, Our multidisciplinary team of scientists, physicians, engineers, and regulatory consultants with decades of global experience brings you the quintessential mechanism that provides complete safety accuracy and durability. Vasthi Instruments was formed with visionary thinking and innovative ideas resulting in innovative products and solutions. We enhance our product quality by the continuous process of research and development. We have WIDE range of models to suite various site conditions and processes

  7. FEATURES OF DEW POINT TRANSMITTER : Analog output 4-20 mA for dew point • Condensation insensitive • Fast adjustment time • Pressure resistant up to 350 bar(special version) • RS485 RTU interface • Higher resolution of the sensor signal history graphical data • Sensor diagnosis on site with mobile device. • Readable via Modbus: Pressure dew point [°Ctd.] Temperature [° C] Rel. humidity [% RH] Moisture content V / V [ppmV / V]

  8. TECHNICAL SPECIFICATION Measure range: -80…30°Ctd, -60, -30, -40, -30 Accuracy: ± 1°C to 50…-20°Ctd ± 2°C to -20…-50°Ctd ± 3°C to -50…-80°Ctd Pressure range: -1…50 bar special version up to 350 bar Power supply: 24 VDC (16…30 VDC) Protection class: IP 65 EMV: according to DIN EN 61326-1 Operating temp.: -20…70 °C Connection: M12, 5-pole PC connection Modbus-RTU interface (RS-485) Analog output 4-20 mA = -80…20°Ctd 4…20 mA = -20…50°Ctd FA 510: 4…20 mA (3-wire) FA 515: 4…20 mA (2-wire) Burden for analog output:<500 Screw-in thread: G 1/2“ optional: UNF 5/8“, NPT 1/2“ Dimensions: Ø 30 mm, length approx.130 mm Via service software:Choose units % RH, °Ctd, g/m³, mg/m³,ppm V/V Scaling change 4…20 mA

  9. CONTACT US VISAKHAPATNAM GUNTUR Hyderabad VASTHI INSTRUMENTS Pvt LtdPlot No. 21 & 22, Block No. 24, Phase –4, AutoNagar, Guntur – 522001.Andhra Pradesh. Phone : +91 8374372209,9347176523 Mobile No : +91 7337418685,Mobile No : +91 7382708685Web : www.vasthi.com Email-ID : info@vasthi.com Sales : Sales@vasthi.com VASTHI INSTRUMENTS Pvt LtdD No. 9-9–35/1/53,FF-B Poosapati Tower,Near Visakha Eye Hospital,Visakhapatnam-530 017Andhra Pradesh Mobile No : +91 7337418685 Mobile No : +91 7382708685, Mobile No : +91 9581678685 Web : www.vasthi.com Email-ID : info@vasthi.com Sales : Sales@vasthi.com VASTHI INSTRUMENTS Pvt LtdManjeera Trinity Corporate,Plot No-112, Survey No:1050,JNTU,Hitech city Rd, KPHB ColonyKukatpally,Hyderabad- 500072Mobile No : +91 7337418685 Mobile No : +91 7382708685, Mobile No : +91 9581678685 phone : +91 6302677968 Web : www.vasthi.com Email-ID : info@vasthi.com Sales : Sales@vasthi.com

  10. Thank you for ! Have a great day ahead.
