  1. Pathology Quiz - Liver Chris Kwan PBL28

  2. Healthy Liver • Smooth capsule • Normal size • Hepatic vein not obstructed, normal size • Even colouration • No fibrosis

  3. Fatty liver

  4. Fatty liver

  5. Hepatic Steatosis (Fatty Liver) • Two types of fatty liver: • Alcoholic steatohepatitis • NASH (Non-Alcoholic Steatohepatitis) • Looks paler than the healthy liver • Greasy feel • Lots of lipid droplets amongst hepatocytes • Initially, centrilobular. Eventually entire lobule involved • Normally reversible. However, chronic exposure  perivenular fibrosis (not reversible)

  6. Cirrhosis (alcoholic)

  7. Cirrhosis from acute hepatitis

  8. Cirrhosis • Cirrhosis = loss of normal liver architecture and presence of hepatocyte nodules • Usual causes of cirrhosis • Alcohol and other drugs • Inflammation (e.g. viruses, autoimmune) • Biliary disorders • Inherited diseases (e.g. haemochromatosis) • Vascular diseases (e.g. thrombosis) • Cryptogenic • An Indian Bit Into Vegetable Curry

  9. Cirrhosis (cont.) • Sometimes can determine cause based on nodule size • Macronodular • Viral hepatitis • Micronodular • Alcohol • Haemochromatosis

  10. Alcoholic Hepatitis • Liver is mottled, normal sized • Microscopic contents: • Mallory Bodies (M) • Neutrophil infiltration (N) • Hepatocyte swelling (H) • Fine subsinusoidal fibrosis (esp. if turning into cirrhosis) • Fatty changes

  11. Mallory Bodies • Consists of hyaline • Has a ropy appearance

  12. Alcoholic Cirrhosis • Resembles viral hepatitis • Shrunken, brown • Microscopic contents: • Parenchymal nodules (N) • Fibrous septaearound nodules (F) • Ischaemic necrosis • Bile stasis • No Mallory Bodies

  13. Haemosiderosis

  14. Haemosiderosis

  15. Haemosiderosis (Haemochromatosis) • Liver looks like milk-chocolate • Caused by deposition of haemosiderin(cellular Fe storage) • Hepatocytes appear brownish too • Excess Fe causes collagen formation • Will see micronodular cirrhosis, which eventually turns into fibrosis • Pancreas also undergoes fibrosis

  16. Random Unrelated Pic

  17. Cell apoptosis in viral hepatitis

  18. Acute Viral Hepatitis • Liver is enlarged and red. May turn greenish if cholestasis is present • Ballooning degeneration of hepatocytes • Inflammation • Regenerative changes • Necrosis and apoptosis of hepatocytes

  19. Chronic viral hepatitis

  20. Chronic Viral Hepatitis • Same features as for acute viral hepatitis, PLUS • Lymphoid aggregation + bile duct damage in portal tracts • Steatosis • Interface hepatitis + bridging necrosis  fibrosis

  21. Massive necrosis (probably from viral hepatitis)

  22. Liver abscess

  23. Disseminated TB  caseous nodules and granulation

  24. Hydatid cysts (from tapeworm)

  25. Nutmeg liver (from right-sided congestive heart failure)

  26. Liver infarctions (from thrombosis of hepatic artery and portal vein)

  27. Cardiovascular Diseases • Thrombosis and congestive heart failure can contribute to liver pathology • Thrombosis can  ischaemia • Congestive heart failure causes blood to pool in liver  makes liver heavy and mottled (nutmeg liver)

  28. Hepatic carcinoma

  29. 1° cholangiocarcinoma and biliary obstruction

  30. Cancer • Variable appearance but it does appear white • Concomittanthaemochromatosis does not colour the cancers • Can appear as a unifocal mass, multifocal nodules or diffusely infiltrative • Can either be well-differentiated or anaplastic • Can metastasise via venous invasion

  31. Normal biliary system

  32. Cholestasis (look for green-brown spots in the canaliculi)

  33. Primary sclerosingcholangitis (concentric fibrous restructuring of intra- and extrahepatic bile ducts)

  34. Polycystic kidney disease (PKD) that manifested in liver  cysts

  35. Biliary Disease • Bile duct destruction • Heavy lymphocyte infiltration in portal tracts • Epithelioid cell granulomas also seen • Tends to present with jaundice

  36. THE END
