  1. DATA CONVERTER IC

  2. DATA CONVERTER IC 74 LS 155- dual 2-line to 4-line decoder/demultiplexer

  3. DATA CONVERTER IC 74 LS 155- dual 2-line to 4-line decoder/demultiplexer • The 74LS155 is a high-speed Dual 1-of-4 Decoder/Demultiplexers. These devices have two decoders with common 2-bit Address inputs and separate gated Enable inputs. • Decoder “a” has an Enable gate with one active HIGH and one active LOW input. • Decoder “b” has two active LOW Enable inputs. If the Enable functions are satisfied, one output of each decoder will be LOW as selected by the address inputs.

  4. DATA CONVERTER IC ADC 0800

  5. DATA CONVERTER IC ADC 0800 • Digital to Analog Converter IC for Micro-controller Project -CNB644. • The ADC0800 is an 8-bit monolithic A/D converter using P-channel ion-implanted MOS technology. It contains a high input impedance comparator, 256 series resistors and analog switches, control logic and output latches. • Conversion is performed using a successive approximation technique where the unknown analog voltage is compared to the resistor tie points using analog switches.

  6. +91 86066 50999 www.tomsonelectronics.com
