A student in a physics class made a picture of this.

x. A stoplight 20 m to the west turns yellow. Your car is traveling west at 12 m/s. You hit the brakes and decelerate at a rate of 6.0 m/s 2 . Your car stops before it reaches the stoplight (which is considered to be at the origin). A student in a physics class made a picture of this.

piper
Download Presentation

A student in a physics class made a picture of this.

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. x A stoplight 20 m to the west turns yellow. Your car is traveling west at 12 m/s. You hit the brakes and decelerate at a rate of 6.0 m/s2. Your car stops before it reaches the stoplight (which is considered to be at the origin). A student in a physics class made a picture of this. to = 0 s xo = + 20 m vo = – 12 m/s a = – 6.0 m/s2 Which of the following is labeled wrong? Did the student mislabel anything? 1 xo 2 vo 3 a 4 a & vo 5 all of the values are correct

  2. A stoplight 20 m to the west turns yellow. Your car is traveling west at 12 m/s. You hit the brakes and decelerate at a rate of 6.0 m/s2. Your car stops before it reaches the stoplight (which is considered to be at the origin). x A student in a physics class made a picture of the situation but did not include the signs of the variables. to = 0 s xo = __ 20 m vo = __ 12 m/s a = __ 6.0 m/s2 What are the signs of the three missing variables? xovoa 1 + – – 2 + – + 3 + + – 4 + + + 5 – – +

  3. vfinal vinitial a x t 1 2 3 v v v t t t v 4 The motion of a car is represented with the motion diagram below. Which graph best matches the motion diagram? Construct a velocity versus time graph to best match the motion diagram and picture. • No graph represents the motion correctly

  4. 3 1 2 x x x t t t 4 x t A stoplight 20 m to the west turns yellow. Your car is traveling west at 12 m/s. You hit the brakes and decelerate at a rate of 6.0 m/s2. Your car stops before it reaches the stoplight (which is considered to be at the origin). Which graph is the best representation of the car’s motion? Construct a position versus time graph that is the best representation of the car’s motion. • No graph represents the motion correctly

  5. t v A bicycle is moving on the road. Its motion is described by the graph below. Below is a mathematical description of the same motion. What should the signs of vo and a be to be consistent with the above graphical description? voa 1 + – 2 + + 3 – + 4 – –

  6. A hot air balloon is stationary in the sky as seen in the picture. A person throws a ball up in the air at 5 m/s. Which set of mathematical representations best matches this process? Construct a mathematical representation that best matches this process. 1. Vf = (5.0 m/s) + (10 m/s2) t 2. Vf = ( - 5.0 m/s) + (10 m/s2) t 3. Vf = (5.0 m/s) + ( - 10 m/s2) t 4. Vf = ( - 5.0 m/s) + ( - 10 m/s2) t 5. Either 2 or 3 are correct

  7. 2 3 x 1 x x t t t 4 x t The mathematical representation seen below is in a physics textbook. Which graph best represents this situation? Construct a position versus time graph to best represent this situation. • Graphs 3 & 4 • Graphs 2, 3 & 4 • No graph represents the motion correctly

  8. Susy sees the mathematical representation below in her physics book. Which description best represents this situation? Construct a verbal description that best represents this situation. • This is a car that is moving to the right and is accelerating in the same direction. • A ball was thrown upwards in the air at a speed of 20 m/s. • A ball was thrown downwards at a height of 5 m at a speed of 20 m/s.

  9. v x t t Alan sees the following three diagrams next to each other in his physics book. a t A B C Are these three diagrams consistent with each other? • Yes, all three diagrams are consistent. • No, Diagram A is not consistent with the other two. • No, Diagram B is not consistent with the other two. • No, Diagram C is not consistent with the other two.

  10. vinitial vfinal x + A car is moving along the road as seen in the motion diagram below. Which mathematical representation below could match this process? Construct a mathematical representation that could match this process. 1. Vf = (5.0 m/s) + (10 m/s2) t 2. Vf = ( - 5.0 m/s) + (10 m/s2) t 3. Vf = (5.0 m/s) + ( - 10 m/s2) t 4. Vf = ( - 5.0 m/s) + ( - 10 m/s2) t 5. Either 2 or 3 are correct
