  1. Summary and conclusions of the mini workshop on laser based alignment systems GUILLAUME STERN

  2. OUTLINE • Overview of the workshop • Presentations given during the workshop • Conclusion

  3. Introduction • CLIC project has very tight tolerances for the alignment of beam-related components • Requirement: 10 μm (at 1 σ) over a slidingwindow of 200 m • Solution based on stretched wires has some drawbacks (difficult implementation, cost) • Idea: replace stretched wire by laser beam

  4. Workshop goals • Many institutes throughout the world work on laser based alignment systems • Workshop goals • Reviewing existing systems • Sharing experience, problems • Talking about on-going developments, perspectives • Improving collaboration between institutes

  5. Workshop organisation • Participants (around 25 persons) • CERN • DESY (Germany) • KEK (Japan) • SPring 8 (Japan) • JINR (Russia) • ETHZ (Switzerland) • Agilent (Switzerland) • Program • Thursday 30th: Introduction + presentations • Friday 31st: Visit on CERN site + brainstorming + conclusion

  6. Presentation: Chao Zhang, Developing an Iris Diaphragm Laser Alignment System for Spring 8 Storage Ring Magnets • Principle: observing diffraction pattern of an iris • Goal: accuracy of 10 μm (at 2σ) over 10 m • Alreadyachieved: pointingstability of 8 μm (at 2σ) over 10 m

  7. QPre Ab Ae Laser Collimator Laser spot Presentation: Mikhail Lyablin, A Laser Based Fiducial Line For High-Precision Multipoint Alignment System • Principle: observing laser spot when laser beam propagates in a tube with atmospheric air • Goal: accuracy of 10 μm (at 1 σ) over a slidingwindow of 200 m • Already achieved: pointing stability of 1.5 μm (at 1σ) over 70 m Tube with atmospheric air Transparent windows

  8. Presentation: Tsuyoshi Suwada, Propagation and Stability Characteristics of a 500m Long Laser Based Fiducial Line For High-Precision Alignment of Long Distance Linear Accelerators stopper QPD sensor • Principle: observing laser spot with quadrant photodectectors (QPD) that are mechanically switched across the laser beam propagating in vacuum pipe • Goal: accuracy of 100 μm (at 1σ) over 500 m • Already achieved: pointing stability of 40 μm, estimatedaccuracy of 100 μm (at 1σ) over 500 m QPD sub-holder 130mmϕ QPD holder signal pick-up

  9. Presentation: Johannes Prenting, Status Report on the laser based Straight Line Reference System at DESY • Principle: observing diffraction pattern of spheres • Goal: accuracy of 300 μm (at 1σ) over 150 m • Estimated achievable accuracy: 100/200μm (at 1σ) over 150 m

  10. Original direction of the reflected beam QPR Laser Direction the reflected beam after tilt base θ ψ Base The surface of the liquid in case of horizontal basis Cuvette with a liquid The surface of the liquid with tilt base Presentation: Mikhail Lyablin, The Search For And Registration of the Superweak Angular Ground Motions • Principle: observing laser spot with quadrant photoreceiver (QPR) after reflection on water surface • Resolution: 5 nrad

  11. Presentation: Guillaume Stern, Laser Alignment Multipoint Based – Design Approach (LAMBDA project) • Principle: observing laser spot with camera/shutter assemblies that are mechanically switched across the laser beam • Goal: accuracy of 10μm (at 1σ) over 200 m • Already achieved: pointing stability of 10μm (at 1σ) over 3 m

  12. Presentation: SébastienGuillaume, Validation of Laser Alignment Systems by Systems Referred to Gravity • Many alignment systems refer to gravity (e.g. Hydrostatic Levelling Systems) • PhD thesis: determining the equipotential of gravity with respect to a straight line (part of the work: development of the deflectometer) • Possibility of performing inter-comparison between different alignment systems

  13. Conclusion • Two very intense days • Many institutes working on laser based alignment systems, though each of them with a different approach • So far, no institute has been able to meet CLIC requirements in terms of accuracy or resistance to radiation • Brainstorming highlighted following aspects • Necessity to work under vacuum • Quality of laser beam profile very important to guarantee a straight reference • Validation of the beam straightness through dedicated benches and through inter-comparison with other alignment systems • Collaborations for future work
