1. Cell Structure Chapter 3 (Part I)
2. Morphology of Prokaryotic Cells Prokaryotes exhibit a variety of shapes
Most common
Coccus
Spherical
Bacillus
Rod or cylinder shaped
Cell shape not to be confused with Bacillus genus
3. Other shapes
Coccobacillus
Short round rod
Vibrio
Curved rod
Spirillum
Spiral shaped
Spirochete
Helical shape
Pleomorphic
Bacteria able to vary shape
4. Pairs or chains of cells
Pairs = diplo
Example: Neisseria gonorrhoeae
Chains = strepto
Example: Streptococcus pyogenes
5. Clusters of cells
Clusters = Staphylo
Example: Staphylococcus aureus
6. Bacteria form multicellular associations
myxobacteria
These organisms form a swarm of cells
Allows for the release of enzymes which degrade organic
material
biofilms
A biofilm can be defined as an aggregation of bacteria, algae, fungi and protozoa enclosed in a matrix consisting of a mixture of polymeric compounds, primarily polysaccharides, generally referred to as extracellular polymeric substance (EPS).
Vu et al., 2009.
Organisms in biofilms are frequently resistant to antibiotics
7. Structural Features of Bacteria Cytoplasmic membrane
Thin fluid mosaic structure
Surrounds cytoplasm of cell
Defines boundary
Serves as a semi permeable barrier
8. Structure is a phospholipid bilayer with embedded
proteins
9. Membrane is embedded with numerous proteins
Numerous proteins are present
Proteins function as receptors and transport gates
Provides mechanism to sense surroundings
Proteins are not stationary (fluid mosaic model)
10. Cell Wall Bacterial cell wall
Rigid structure
External to- and surrounds cytoplasmic
membrane
Determines shape of bacteria
Prevents cell from bursting (physical strength)
Unique chemical structure
Distinguishes Gram-positive cells from Gram-negative cells
11. Rigidity: peptidoglycan (PTG)
Compound found only in bacteria
Basic structure of peptidoglycan:
Alternating series of two subunits
N-acetylglucosamine (NAG)
N-acetylmuramic acid (NAM)
Joined subunits form glycan chain
Glycan chains held together by string
of four amino acids (tetrapeptide chain)
12. Peptidoglycan Structure
13. Gram positive cell wall
Relatively thick layer of PTG
As many as 30, regardless of thickness, PTG is permeable to
numerous substances
Teichoic acid component of PTG
14. Gram-negative cell wall
More complex than G-positive cell walls
Contain thin layer of PTG
PTG sandwiched between outer membrane and cytoplasmic membrane
Region between outer membrane and cytoplasmic membrane is called
Periplasm
Lipoproteins link O.M. to PTG
15. Outer membrane
Constructed of lipid bilayer
Much like cytoplasmic membrane but outer leaflet made of
lipopolysaccharides not phospholipids
Outer membrane also called the lipopolysaccharide LPS layer LPS
LPS severs as barrier to a variety of molecules
However, small molecules or ions pass through channels called porins
Portions of LPS are medically important
O-specific polysaccharide side chain
Lipid A
16. O-specific polysaccharide side chain
Directed away from membrane
Used to identify certain species or strains
E. coli O157:H7 refers to specific
O-side chain
Lipid A
Portion that anchors LPS molecule in lipid bilayer
17. Periplasm
Region between C.M. and O.M.
Filled with gel-like fluid (periplasm)
In Gram negative bacteria, the periplasm contains all secreted proteins unless they contain signals that allow them to be specifically translocated across the O.M.
Tremendous biological activity occurs in the periplasmic space
