1. Cardiovascular System Nursing 1120
By: Diana Blum RN MSN
Metropolitan Community College 1
2. Objectives Describe the normal anatomy and function of the heart
Describe the blood flow through heart to lungs and body
List the data to be obtained in the client with a cardiac disorder
Define Age Related Changes
Explain the nursing consideration for clients having selected diagnostic procedures to detect or evaluate cardiac disorders
2
3. Objectives Continued Discuss CAD etiology and risk factors commonly collected, treatments prescribed, and related nursing interventions.
Discuss the following common cardiac therapeutic measures: medications, diet, 02, exercise program, pacemaker, automatic implantable cardiac defibrillator (AICD), cardiac surgery, EP study with Ablation, CPR
3
4. Objectives continued Discuss the disease condition MI by describing etiology, risk factors, data commonly collected, treatments prescribed and related nursing interventions
Describe the complications which may occur following a MI
Discuss CHF including the definition, etiology, assessments, treatments, and common nursing interventions.
Define types of cardiac arrhythmias and name 5 common HTN as related to blood pressure by identifying the types, S/S, and discussing treatment and related nursing observations and interventions.
Describe the following valvular disorders: Mitral stenosis, insufficiency, and prolapse, Aortic stenosis and Aortic insufficiency
4
5. Objectives continued Compare and contrast the following inflammatory conditions of the heart including, definition, data collection, medical treatment and interventions:
Endocarditis
Myocarditis
Pericarditis
Discuss the nursing process as it relates to the cardiovascular system 5
6. Cardiac Function Primary function : to pump blood through the pulmonary and systemic circulations
This is accomplished by a continual repeating pattern of contractions and relaxation (lub dub)
6
7. 3 Layers of Cardiac tissue Endocardium : innermost layer of the heart-(lines the heart)
Myocardium: middle layer made up of muscle fibers and is responsible for the pumping action of the heart
Epicardium: the outermost layer and is the visceral pericardium. The coronary arteries are embedded in this layer
7
8. 8
9. Blood Flow Right Atrium: receives blood from vena cava and from coronary arteries
Tricuspid Valve: passes blood from right atrium to right ventricle
Right Ventricle: bottom chamber of the heart that contracts (systole) and pushes blood through pulmonic valve and into pulmonary artery
9
10. Blood Flow Continued Pulmonary artery: carries blood to the lungs
Pulmonary veins: carry the newly oxygenated blood back to the heart
Left Atrium: accepts blood from pulmonary veins
Mitral Valve: moves blood from left atrium to left ventricle
Left Ventricle: thickest and strongest muscle
Cone shaped and contains apex of heart
When the LV contracts (Systole) blood is ejected into aorta and out to Body
10
11. 11
12. Coronary Arteries Two major coronary arteries
arise from the aorta beyond the aortic valve.
Blood flows to the coronary arteries during diastole
Left main, LAD, Circumflex feeds most of Left side of the heart
Right feeds SA node, AV node, RA, RL
12
13. 13
14. Conduction System SA node: (pacemaker)
initiates the impulse
travels thru atria to the AV node, located on the floor of the RA
Impulse is delayed at AV node, then transmitted to bundle of His
Then moves down R and L ventricles to Purkinje fibers 14
15. Conduction Continued 15
16. Cardiac Cycle Contraction and relaxation of the heart: lub dub or 1 heart beat
Diastole: ventricles at rest and filling up with blood coming from the atria (Dub)
Systole: Once the Ventricle is filled with blood and the electrical impulse has reached the terminal fibers of the conduction system, the Ventricle contract and eject blood into the pulmonary artery from the RV and into the aorta from the LV (Lub) 16
17. Video Mysterious Heart Volume 2 chapter 3 17
18. Cardiac Output the volume of blood ejected by the heart each minute and is determined by stroke volume and the heart rate.
Normal stroke volume is 60-100 ml
Normal cardiac output is 4 to 8 L / min
(CO = HR X SV) 18
19. Factors affecting Stroke Volume Preload: the amount of blood remaining in the ventricles at the end of diastole or the pressure generated at the end of diastole
Contractility: is the ability of the cardiac muscle fibers to shorten and produce a muscle contraction. (Inotropic, + or -)
Afterload: amount of pressure the Ventricle must overcome to eject blood volume out
19
20. Heart Rate SA node : pacemaker of heart 60-100 bpm
AV node : 40 -60 bpm, if SA node fails
Heart is innervated by sympathetic and parasympathetic nervous system
Sympathetic: speeds HR, and increases force of contraction
Parasympathetic: slows HR and force 20
21. Heart Tones Murmur: Produced by turbulent sounds across valves
Rub: inflamed pericardium-best heart along left sternal border
S3 murmur: sounds like Kentucky
S4 murmur: sounds like Mississippi
http://www.blaufuss.org/
http://www.med.ucla.edu/wilkes/Rubintro.htm 21
22. Health History 22
23. Present Illness Fatigue
Edema
Palpitations
Pain
Aggravating and relieving factors
23
24. Past Medical History HTN
renal disease
pulmonary disease
DM
CVA
rheumatic fever
streptococcal sore throat
scarlet fever
previous cardiac disease or conditions
currents meds and allergy
24
25. Family History: CAD
HTN
DM 25
26. Review of systems weight gain
fatigue
dyspnea
cough
orthopnea
palpitations
chest pain
fainting
concentrated urine
edema
26
27. Functional assessment effects of illness on ADLs and rest patterns
smoker
diet
stress
coping 27
28. Physical Assessment General: Apparent distress
Height and weight
VS: orthostatic bp in both arms, apical rate and rhythm
peripheral pulses: rate, rhythm, quality, equality
respiratory rate and effort
Skin: color hair distribution, cap refill, temp
Thorax: heart sounds, lung sounds, sputum
Extremities: pulses, color, temp, edema
28
29. Age Related Changes Heart less able to adapt to changing needs related to activity
Valves thicken and stiffen
# of pacemaker cells decrease
Nerve fibers decrease
Frequent dysrhythmias 29
30. Diagnostic Tests EKG: rate, rhythm, ischemia (T-inverted), injury (ST segment elevation), arrhythmias, strain, infarction (q wave)
Echocardiogram: (TEE) sound wave test detects size of chambers, valve integrity, flow, wall motion, Cardiac Output
30
31. Diagnostic Tests Continued Biomarkers:
Troponin will show elevation 1hr after MI
<0.10 is negative
0.10-0.60 is intermediate and may indicate injury
>0.60 is positive evidence of MI
Myoglobin doubles in 2 hr after MI
CPK-MB will show increase 4 hrs after MI
BNP can be elevated 48 hrs after MI which indicates heart failure
31
32. Diagnostic Tests Continued CBC: anemia
CMP: screening K+, etc
PT, INR
PTT
Lipid profile: see next 2 slides 32
33. 33
34. 34
35. Diagnostic Tests Continued ABG: assess acid/base levels
Pulse Oximetry: generally >92%
Holter monitoring: 24+ hr of EKG + events
Stress test: treadmill or pharmacological
Cardiac Catheterization: invasive, NPO 6-8h, consent. Visualizes chambers, valves, arteries, pressures, CO
Heart-CT scan: assesses CAD, MRI
Nuclear scans: assess heart muscle viability
EPS: NPO, consent, IV, assess electrical activity 35
36. 36
37. http://preop.medselfed.com/asp/center.asp?centerId=heart&partnerId=preop&id=&cachedate=&emailId=&affId=&campId=&hideNav= 37
38. CAD
Video-mysterious heart volume 3 chapter 2 38
39. Etiology of CAD CAD occurs when the intimal lining of the coronaries begin to plaque resulting in jagged edges and narrowed passageway for blood flow
Atherosclerosis results in impaired blood flow to the heart muscle
39
40. Risk Factors for CAD Non-controllable-
Age
Gender
Family/personal history of DM and heart disease
Controllable-
smoking, elevated cholesterol, HTN, sedentary, increased weight, stress
40
41. s/s of CAD Angina which results from a lack of 0xygen to the heart muscle
4Es=exercise, eating, emotion, exposure to cold
Weakness, diaphoresis, SOB
N/V 41
42. MI: Myocardial Infarction Occlusion of a coronary artery resulting in necrosis of the heart muscle.
Risk factors: same as for CAD
Pathophysiology: AMI-over 4-6 hrs ischemia injury and infarction develop. Ischemia=lack of 02 to heart muscle, if not relieved=injury. After 20 min of ischemia=infarction
Main S/S: chest pain and accompanying S/S
42
43. Within 24 hours after infarction, healing begins, collateral circulation begins.
10-14 days after MI=extension of MI may occur due to myocardial tissue vulnerability to stress
Complete scar formation and healing takes about 6 weeks
Video- mysterious heart volume 1 chapter 2
43
44. Data Collection Same as for CAD but will assess symptom of chest pain with accompanying s/s
May have EKG changes with or with-out ST-T wave changes or Q wave changes
Cardiac Bio-markers (Troponin, Myoglobin, CPK, CKMB)
May proceed with Echocardiogram to assess if wall motion sluggish
May go to cath lab
44
45. Angina or MI Angina without MI} often relieved with rest and NTG
Angina with MI } may be relieved with rest, NTG, 02, MS, rescue angioplasty, etc.
Think MONA
Morphine
Oxygen
Nitroglycerin
Aspirin
http://www.youtube.com/watch?v=4GlQmTlP2jE&feature=related 45
46. Treatment continued
video mysterious heart volume 3 chapter 3-7 ASA: to prevent platelet aggregation
MS: to treat pain associated with MI, <02 consumption, <BP, Pulse & reduces anxiety
Beta-blocker: to < workload of heart muscle and <pulse and preload
ACE inhibitor: if CHF present to prevent ventricular remodeling and progression of failure
46
47. Treatment continued May need antiarrhythmic meds
Stool softeners to reduce valsalva maneuver and prevent constipation r/t narcotic use and bed rest
Treat: HTN, DM other co-morbid illnesses
Cardiac Rehab to follow
47
48. Treatments Low fat low cholesterol diet
Prescribed exercise program 5-7 days a week
Knows correct use of NTG for angina
Management of DM, HTN
Stop smoking
Medications to reduce work load or dilate
48
49. Low salt diet (<2000mg) does not include: Soups: canned, freeze dried, broth
Sauces
Snacks: processed chips, nuts
Smoked meat and fish
Sauerkraut
Seasonings
Sodium-processed cold cuts 49
50. Low fat <30% Low cholesterol <200mg Lean meat: skinless
Dairy limited: egg beaters, skim milk
Olive oil, canola oil
Avoid: fried, fatty or heavily marbled meats, sausage, lunch meat, spareribs, frankfurters, salt pork, canned fish in oil, yolks, duck. Cream sauces, gravy, buttered vegetables, sweet rolls, other processed foods 50
51. Exercise 5-7 X week is goal to include stretches with warm-up, progressive walking program, light weights, stretches with cool down.
Strengthens heart muscle, reduces BP, BS, weight, stress, tension, appetite, LDLs.
Increases HDLs, energy and self esteem and improves immune system
51
52. Principles of Exercise Practice on regular basis
Know how to do own pulse
Strive for target heart rate
Stop if chest pain occurs
Complications: CHF & Dysrhythmias
52
53. Nursing interventions for MI Comfort measures
Freq VS, cardiac monitoring, I&O, CMS checks, spacing activities
Heart & lung sounds, assess fluid volume status, IV responsibilities, note BP & Pulse prior to heart meds!!
Client education r/t diet, meds, pulse taking activity, elimination, reporting chest pain and correct use of nitro products for angina
53
54. Medications for Heart Disease Anti-Anginal: nitrates, beta blocker, ca channel blocker
Anti-Hypertensive: ACE inhibitors, beta blocker ca channel blocker, diuretics, other vasodilators
Anti-Arrhythmic: Rhythmol
Cardiac glycoside: Lanoxin
54
55. Medication continued Thrombolytic: Streptokinase, Betapace
Anti-coagulant: Heparin, Coumadin, lovenox
Anti-platelet aggregate: ASA, Plavix
Lipid-Lowering agents: Statins, zetia
Diuretics: Lasix, demadex
Electrolyte replacement: K+, magnesium
55
56. Medication continued 02 to maintain 02 sat > 92% to reduce chance of angina/ischemia
If Angina the nurse needs to have the client lie down, take VS then report to charge nurse unless nitro ordered.
Instruct client: If develops chest pain, sit down take 1 nitro every 3- 5 min x 3. If chest pain not relieved call 911
56
57. POST MI Complications 57
58. 90% will develop complication and 80% will demonstrate arrhythmia which is the most common cause of death in clients in the pre-hospital period. (VT>>>VF)
CHF and severe Left ventricular failure
Papillary muscle dysfunction
Pericarditis
Thromboembolism
Ventricle rupture
58
59. Nursing Diagnosis Decreased cardiac output r/t Dysrhythmias
Pain r/t lack of 02 to myocardium
Anxiety r/t to feeling of doom, lack of understanding of medical diagnosis
59
60. Surgical Procedures 60
61. New in 1958 having purpose to restore the regular rhythm and to improve tissue perfusion and cardiac output.
Temporary / permanent
Single chamber or double chamber
Teach client how to take 1 min pulse, s/s to report to MD-dizzy, angina, dyspnea
Carry card and know precautions 61
62. Video- mysterious heart volume 2 chapter 4 62
63. AICD Implantable defibrillator to correct a life threatening rhythm disturbance.
Has pacemaker back-up.
Client can feel shock, check battery q2months
Instruct on how to take pulse for 1 min
s/s to report to MD: firing, s/s of dizziness, dyspnea, weakness, carry card and wear bracelet, CPR for family. Know precautions
63
64. Nursing care for client with newly implanted pacemaker or AICD.
Assess cardiac monitor for capture/pacing (pacer)
VS post-op then q 4 hours, IV, bed rest till am
Dressing dry and intact until AM then often may remove. Increase activity progressively
Instruct client not to raise arm above shoulder for 5days. May shower in 5 days
64
65. Angioplasty with Stent Procedure done at the time of cardiac cath.
Balloon angioplasty is accomplished to widen or open specific coronary vessel-stent is inserted to maintain patency of the vessel.
pre-procedure Plavix given with follow up Plavix
65
66. EP with Ablation Mapping of myocardial tissue to determine irritable focus.
Low voltage current delivered to ablate tissue causing SVT or VT
90% effective
http://video.google.com/videoplay?docid=5590000557631435292
66
67. Nursing Care NPO prior
Coumadin stopped 4 days prior, Heparin 4 hours prior
Post procedure same as heart cath
Cardiac monitoring
CMS and groin checks
VS
Ambulate prior to discharge 67
68. Cardiac Surgery Coronary artery bypass graft- done after confirmation with cardiac catheterization.
Re-route blood vessels using mammary or saphenous v from aorta around block in coronary artery.
Valve replacement or repair
Septal repair and other congenital repairs
CCU post op, chest tubes
Pre-op teaching with post op expectations
See client teaching for CABG, Valve repair/replacement, care of PTCA, MI
68
69. http://preop.medselfed.com/asp/center.asp?centerId=heart&partnerId=preop&id=&cachedate=&emailId=&affId=&campId=&hideNav= 69
70. Congestive Heart Failure Video..the mysterious heart volume1 chapter 3 70
71. 71
72. DEFINITION:EF < 35% or when the myocardium is no longer able to pump efficiently and fluid accumulates in the lungs and or selected areas of the body as a result
72
73. Systolic failure= most common
Left ventricle loses its ability to generate enough pressure to eject blood forward through the aorta resulting in a decrease in the CO which is measured by the EF (ejection fraction)=total Ventricle filling volume that is ejected during Ventricular contraction. 50%=normal
73
74. Causes of CHF CAD, advancing age
HTN is a major factor > CHF x 3
DM, Smoking, Obesity
Valvular incompetency, alcohol or other chemicals, idiopathic,(unknown)
74
75. S/S of Left Sided CHF Fatigue
Angina
Tachycardia
Cool extremities
Hacking cough
Crackles
Frothy sputum
Gallop
75
76. S/S of Right Sided CHF Jugular distention
Anorexia/nausea
Dependent edema
Distended abdomen
Weight gain
BP problems 76
77. Assessment Findings C/O SOB, weakness, dry cough, fatigue, can not lie down must sit up to breath, has gained weight
Auscultation of the heart} rapid HR, extra heart sounds
Auscultation of the lungs} rales, wheezing
Examination of the extremities for peripheral edema
77
78. 78
79. System Compensation Mediated thru Sympathetic Nervous System: as CO drops, baroreceptors alert brain>>>signals adrenal glands to release catecholamines{norepinephrine and epinephrine}
This causes stimulation Beta 1=>>HR
Stimulation Beta 2= bronchodilation
Activate Alpha receptors peripherally=constriction=>>bp
79
80. Compensation Causing S/S of CHF because:
Contractility decreases
Stroke volume and CO continue to decrease
Afterload (pressure on the other side of the aorta) increases
Preload ( pressure caused by increase volume to heart creating an exaggerated stretch in the muscle) increases
80
81. Renal Compensation CO drops initiating renin-angiotensin mechanism
Results in powerful vasoconstrictor angiotensin II,>> aldosterone (hormone) which causes kidneys to retain Na and H20 which increases blood volume
81
82. Ventricular Hypertrophy The heart enlarges which results in strain
The increase in volume causes the ventricles to dilate
Eventually remodeling will occur
82
83. Diagnostic Tests H&P
Chest x-ray: see size of heart and fluid in lungs
EKG: strain, MI
Echocardiogram: size of heart and CO
CBC: anemia
CMP: screening
Thyroid function
ABGs
BNP=B type natriuretic peptide= hormone released in response to Ventricular stretch ( CHF peptide)
Nuclear studies to determine heart function, EF, tissue viability
Cardiac Cath to determine exact nature of heart function
83
84. 84
85. CHF Management Directed at: Improving LV function (Contractility) by decreasing intravascular volume and decreasing vascular resistance
Decreasing venous return (Preload)
Decreasing BP (Afterload)
Improving gas exchange and 02
Increasing the CO and reducing anxiety
85
86. continued ACE inhibitors to < afterload by dilating vessels and < BP (ARBs)
Beta blockers to < 02 demand by reducing the contractility of the heart and HR (not given in acute period)
Diuretics <preload by reducing volume returning to the heart-Lasix & (Aldosterone Antagonists) K+ supplement
86
87. continued ASA in low doses or Plavix to help prevent blood clot formation
Anticoagulants for those with poor EFs to prevent CVA
Antiarrhythmics to control ectopy
Biventricular pacing (CRT=cardiac resynchronization therapy) to improve CO
Digoxin to increase contractility of myocardial fibers and improving cardiac output. +inotropic agent
87
88. Treatment of CHF Treat underlying cause
Rest and hi Fowlers to reduce work load and improve ventilation
02 at 2-6 L/min with 02 sats >92% to increase available 02 and prevent hypoxemia
Freq VS and cardiac monitoring
88
89. Treatment continued I & O q shift
Daily am weights before breakfast and after voiding. 2-3# weight gain in 1-4 days call MD
Sodium restricted diet
Medications: to decrease intravascular volume thus reducing venous return, dilate and reduce BP and improve contractility
http://chfsolutions.com/zip_how_aquapheresis_works.html# 89
90. Educating the CHF Client Education re: heart failure
Explanation of heart failure
Expected S/S and when to call MD
Self monitoring of daily weights
Know medications and need to take them
2000mg sodium restricted diet
Importance of low level daily exercise program (energy conservation)
Prognosis / advanced directives
90
91. Lead Placement 91
92. A dysrhythmia is a disturbance of the rhythm of the heart caused by a problem in the conduction system.
Categorized by site of origin: atrial , AV nodal, ventricular
Blocks are interruptions in impulse conduction: 1st, 2nd type 1&2, 3rd or complete heart block
92
93. To map= to determine if regular or irregular 93
94. P-wave = atrial electrical activity
QRS= ventricular electrical activity
T wave= resting phase of ventricle
94
95. 95
96. P wave 96
97. 97
98. QT Wave 98
99. Heart rates NSR: heart rate is 60-100bpm
ST: heart rate 101-180 bpm
SB: heart rate <60 bpm
99
100. NSR 100
101. Sinus rhythm PR interval- 0.12-0.20sec
QRS-0.06-0.10sec
QT segment 0.36-0.44 sec
Heart rate 60-100 101
102. Sinus arrythmia Hr= 60-100 bpm
On strip it looks regular but does not map out
PR interval= 0.12-0.20 102
103. Junctional escape rhythm 103
104. SB 104
105. Sinus Bradycardia All criteria same except rate < 60bpm
S/S: dizziness, syncope, angina, hypotension, sweating, nausea, dyspnea
Sometimes no S/S
Treat underlying cause
IV atropine, pacemaker
105
106. ST 106
107. Sinus Tachycardia All criteria same as with NSR except rate >100
Causes: fever, dehydration, hypovolemia, increased sympathetic nervous system stimulation, stress, exercise, AMI
S/S: Palpations #1, angina and < CO from < V filling time
Treatment: correct cause, eliminate caffeine, nicotine, alcohol. Beta blockers may be ordered
107
108. First degree heart block 108
109. 109
110. Second degree heart block type 1 110
111. 111
112. Second degree heart block type 2 112
113. 113
114. 3rd degree heart block of complete heart block 114
115. 115
116. Atrial Fibrillation 116
117. A fib continued Atrial rate > 400 bpm with a varying Ventricular rate
Overall rhythm irregular
No P waves, unable to measure PR interval
QRS=normal: Twave undeterminable
Causes: Rheumatic fever, mitral valve stenosis, cad. HTN, MI, hyperthyroidism, COPD, CHF see pp. 604
117
118. A fib continued Concern with A fib is the development of atrial thrombus and loss of atrial kick from ineffective atrial function.
Treatment: Ca channel blockers and anti- arrhythmics to convert, beta blockers to < HR, anticoagulants to prevent embolization.
Synchronized cardioversion
118
119. Atrial flutter 119
120. Paced beat 120
121. Premature ventricular conduction (PVC) 121
122. 122
123. Ventricular tachycardia 123
124. Torsades de pointe 124
125. Ventricular Fibrillation 125
126. Vtach/Vfib Both can be life threatening
VT= V HR 100-250 bpm
Causes: AMI, CAD, hypokalemia, dig toxic
S/S: palpitations, dizzy, angina, <LOC
Treatment: assess for pulse, if none, defib
VF=Rate undeterminable Cause: same
Treatment: CPR
126
127. 127
128. Hypertension 128
129. HTN is described as persistent elevation of arterial blood pressure greater than 140/90 on at least 2 or more readings on different dates.
The Joint National Committee, Detection, Evaluation, and Treatment of High Blood Pressure defines normal:
BP as S < 120 mm Hg and D < 80 mm Hg
PreHTN: SBP 120-139 DBP 80-89
Stage 1: SBP 140-159 DBP 90-99
Stage 2: SBP >160 DBP >100
129
130. Types of Hypertension Essential HTN: (Primary) which is the most common 90-95% of population
Secondary HTN: is a result of another disease, kidney, pregnancy.
130
131. Factors that determine arterial pressure Cardiac output which is the volume of blood pumped by the heart in 1 minute
Peripheral vascular resistance which is the force in the peripheral blood vessels that the left ventricular must overcome to eject blood out of the heart
131
132. Possible Causes of PVR Narrowing of blood vessels, PVD, CAD, kidney disease: > renin/angiotensin =vasoconstriction
Release of catecholamine (epinephrine and adrenalin) = vasoconstriction
> blood volume= more work to pump
> Blood viscosity=harder to pump
Ability of blood vessel to stretch
132
133. Causative Factors of HTN Hyperlipidemia Obesity
Atherosclerosis Sedentary
DM Family Hx
Cigarette smoking
Age > 60
Men
Post menapausal women
133
134. S/S Often none
Occipital headache more severe on rising
Lightheadedness
Epistaxis
Known as the Silent Killer 134
135. Complications Damage to blood vessels of the eyes, heart, kidney, brain resulting in:
Stroke
CHF
AMI
Renal failure
Blindness
135
136. Lifestyle Change Education Exercise, dash diet, stop smoking, weight management and control, stress reduction, medications and recording BP frequently
Avoid OTC meds
Instruct on how to do postural BPs
136
137. Valvular Disorders 137
138. STENOSIS: narrowing of the opening of the valves
INSUFFICIENCY: inability of the valves to close
138
139. Stenosis Narrowing of the opening of the valves. Limits the amount of blood which is ejected from one chamber to the next.
i.e., the L A would not empty completely into the L V when it contracts. Result in an increased amount of blood remaining in the L A after contraction has occurred
139
140. 140
141. Mitral Stenosis Mitral valve leaflets become thickened and fibrotic. Affect women age 20-40
CHF may develop
TX if failure develops: Digoxin, Lasix, beta blockers, and anti arrhythmics, lo Na diet, etc
Will monitor with yearly echocardiogram
Surgery if worsens
Prophylactic antibiotics prior to invasive procedure or dental work
141
142. Insufficiency (Also referred to as regurgitation)
The inability of the valves to close completely.
Allows the blood to backflow.
i.e., After the L A has contracted some of the blood will flow back into the L A
Mitral valve is the most commonly affected 142
143. 143
144. Mitral Insufficiency Often accompanies mitral stenosis as a result of rheumatic fever.
Valve leaflet become rigid and shorten, prevents closure of valve.
Hypertrophy of Left Atrium and Ventricle = L sided heart failure occurs
Murmur heard. F/U with echocardiogram
TX: vasodilators, same as for stenosis
144
145. Mitral Valve Prolapse When the Left ventricle leaflets become enlarged, and protrude into the left atrium during systole.
Benign but may progress to Mitral insufficiency
More common in women age 20-55 145
146. S/S of mitral prolapse Often none
Others experience chest pain, palpitations, dizziness, syncope, dysrhythmias
Monitor with echocardiogram
May do heart catherization
Manage stress, beta blockers if tachycardia
146
147. Aortic Stenosis Occurs when valve cusps become fibrotic and calcify.
Most commonly caused by aging and atherosclerosis.
Occurs most predominantly in men
Untreated will lead to Left sided CHF
147
148. Aortic Insufficiency Caused primarily by rheumatic fever
May also be caused by chronic HTN
Predominantly in men
Hypertrophy of the Left ventricle and eventually to left sided CHF
Blood may eventually back up into the pulmonary system and lead to Right Ventricle failure
148
149. S/S and Treatment Aortic murmur, tachycardia, palpitations, CHF with fatigue, SOB, ascites
Monitored with echocardiogram assessing L ventricular dilatation
Chest X-ray-enlargement of heart
May do cardiac cath
May need valve repair or replacement 149
150. Inflammatory Diseases of the Heart 150
151. Inflammation of the heart most often results from systemic infections and may include any layer of the heart:
Endocardium
Myocardium
Pericardium 151
152. Endocarditis Inner layer: tends to affect the valves (Mitral=L). Organisms (Bacterial or fungal) present in blood stream and collect (colonize) on the valves: Rheumatic heart disease, congenital defects or mitral valve prolapse
IV drug users or invasive procedures
152
153. Clients with known valvular disease need to be treated with prophylactic antibiotics prior to any invasive procedure including dental. Immunosuppression and any source of contamination places clients at risk
153
154. Pathophysiology Bacteria may enter blood stream: staph, strep, E coli.
Bacteria collect on valves and vegetate
Vegetation may break off with blood flow and cause emboli
Complications: Ventricular septal defect, CHF(#1 cause of death) and embolization
154
155. S/S Fever- (99-105)
Chills and night sweats may accompany
Malaise, fatigue and weight loss
Appearance of petechiae in the mouth, conjunctiva and legs
Chest and abdominal pain indicating embolization 155
156. Treatment and Diagnostics H&P and Lab tests
CBC with diff with leukocytosis, > sed rate, blood cultures
May have heart murmur Echocardiogram to visualize valves and vegetation
Chest x-ray: CHF
Long term antibiotics, rest, limited activity, prophylactic anticoagulants, valve replacement after inflammation treated
156
157. Nursing Assessment Frequent VS and assess for fever
Assess for heart murmur
Note cough
Assess peripheral edema
Rest with limited activity, administer meds in a timely manner
157
158. Nursing Diagnosis Decreased CO r/t impaired valve function
Pain r/t tissue inflammation
Ineffective tissue perfusion r/t embolization
Activity intolerance r/t fatigue and bed rest
Knowledge deficit r/t lack of information regarding illness and management 158
159. myocarditis 159
160. Muscle layer: Local or diffuse inflammation of the myocardium. May be viral or bacterial, an autoimmune process or drug toxicity.
May result in cardiomyopathy=enlarged heart.
160
161. Pathophysiology Characterized by degeneration and necrosis of myocardial tissue that is different of that caused by MI
Tissue next to necrosed area hypertrophies, loses elasticity, results in CHF and arrhythmias
161
162. S/S Asymptomatic
May have fever, fatigue, sore throat, dyspnea, muscle aches
Lymph nodes may be enlarged
Chest pain 7-10 days after virus
CHF S/S
162
163. Diagnosis Based on Hx, S/S, and testing-enzymes>
May hear friction rub, rales
Jugular vein distention
Chest x-ray, echocardiogram=hypertrophy
EKG=arrhythmias
Biopsy (RV) shows lymphatic infiltration and cell necrosis
163
164. Treatment Bed rest
02
Meds: cardiac glycoside-Lanoxin, anticoagulants, antiarrhythmic, antibiotics, steroids
Cardiac monitoring
NI same as for endocarditis
ND same as for endocarditis 164
165. Pericarditis 165
166. Outer-surrounds heart
Inflammation of the pericardium.
Primary or secondary
Acute or chronic
Acute: virus, bacteria, fungi, chemotherapy, MI
Chronic: TB, radiation or metastases
166
167. Pathophysiology Inflammation causes an increase in the amount of pericardial fluid and inflammation of surrounding tissues.
Fluid accumulates in the pericardial space
Adhesions may occur which causes loss of elasticity which causes constriction and prevents adequate filling of ventricles.
May lead to tamponade==pericardiocentesis
167
168. Tamponade 168
169. S/S Chest pain is hallmark
Most severe on inspiration, sharp, stabbing, or dull and burning.
Pain is relieved by sitting up or leaning forward
Dyspnea, chills and fever
169
170. Diagnosis WBC elevated
Serial EKG show that ST segment increases and resolves in several weeks. A fib may occur
QRS = low voltage
Echocardiogram to see pericardial thickening and effusion
Enzymes can be increased
Blood cultures to ID organism
170
171. Treatment Analgesics
Antipyretics
Anti-inflammatory agents
Antibiotics
May need OR to create a pericardial window to allow for drainage of fluid
NI and ND same as for endocarditis
171
172. Nursing the Heart Client 172
173. Assessment Heart rate and rhythm, color, temperature, cognition
Circulation: peripheral CMS checks
Vital signs to include 02 saturations and telemetry interpretation
Subjective: c/o chest pain, SOB, fatigue, lightheadedness, dizziness
173
174. Nursing Diagnosis Activity intolerance
Ineffective airway clearance
Ineffective breathing patterns
Cardiac output, decreased
Tissue perfusion, altered, coronary
Fatigue
174
175. Ekg practice 175
176. 176
177. 177
178. 178
179. 179
180. 180
181. 181
182. 182
183. References
www.mirule.com retrieved on 4/8/07.
Images found at www.aol.com. Retrieved on 4/8/07.
Aehlert, B. RN BSPA (2006). EKGs Made Easy. Mosby (3rd ed). St Louis. 183
184. The End 184 Refer to handout: Determining Nutrition Health from NURS 1510 for Low fat, low cholesterol and low sodium diet instructions for clients with heart disease
Refer to handout: Determining Nutrition Health from NURS 1510 for Low fat, low cholesterol and low sodium diet instructions for clients with heart disease
